Module Interfaces - Cabletron Systems SmartSwitch 9000 Appendix

9F426-02 Module Specific
Information
Introduction
This appendix contains local management information that is specific to the
9F426-02 FDDI Switch Module.

Module Interfaces

The 9F426-02 FDDI Switch Module has seven interfaces. Table 1 lists the
identifying number, name, and description of each interface.
Interface
Number
1
2
3
4
5
6
7
Use the numbers listed in Table 1 to configure the module's default interface (see
General Configuration Screen).
Table 1. 9F426-02 FDDI Switch Module Interfaces
Interface
Name
SMB1 1 Mbps System Management Bus
SMB10 10 Mbps System Management Bus
HOST i960 Host
CONTROL i960 Data Controller
INB Internal Network Bus
FRONT1 FDDI 1 Front Panel Port
FRONT2 FDDI 2 Front Panel Port
Appendix
Interface
Description
1
