Module Interfaces - Cabletron Systems 9F426-03 Appendix

9F426-03 Module Specific
Information
Introduction
This appendix contains local management information that is specific to the
9F426-03 FDDI Switch Module.

Module Interfaces

The 9F426-03 FDDI Switch Module has 8 interfaces. Table 1 lists the identifying
number, name, and description of each interface.
Interface
Number
Table 1. 9F426-03 FDDI Switch Module Interfaces
Interface
Name
1 SMB1
2 SMB10
3 HOST
4 CONTROL
5 INB
6 FRONT1
7 FRONT2
8 FRONT3
Interface
Description
1 Mbps System Management Bus
10 Mbps System Management Bus
i960 Host
i960 Data Controller
Internal Network Bus
FDDI Front Panel Port 1
FDDI Front Panel Port 2
FDDI Front Panel Port 3
Appendix
1
