FNB Resource Configuration
The 9F426-02 FDDI Switch Module is capable of bridging/switching any three, of
five possible interfaces, depending on the way you configure the module. The
module's INB connection is fixed (not user-configured).
The FNB Resource Configuration Screen (Figure 2) allows you to connect both
front panel ports, both FNB ports, or one front panel and one FNB port to the
bridge/switch. Redirecting one or both of the module's front panel FDDI
interfaces to the FNB backplane creates an INB to FNB bridge/switch product
that allows migration from FNB modules to INB modules.
The SmartSwitch 9000 FNB backplane is composed of two FDDI Networks (FNB-
1 and FNB-2). The FNB Resource Configuration Screen lists all possible
connections a module can support on the FNB, displays the current connection,
and allows you to change the connection.
Module Name: 9F426-02
Slot Number: 6
Current FDDI Con: (#2)
Config ID
1
2
3
4
5
6
7
SAVE
Figure 2. FNB Resource Configuration Screen (9F426-02 FDDI Switch Module)
SMARTSWITCH 9000
FNB Resource Configuration
FNB1<->FRONT2
FDDI Connections
FNB1 <-> FNB2
FNB1 <-> FRONT2
FNB2 <-> FNB1
FRONT1 <-> FNB1
FNB2 <-> FRONT2
FRONT1 <-> FNB2
FRONT1 <-> FRONT2
9F426-02 Module Specific Information
LOCAL MANAGEMENT
Firmware Revision: 02.00.03
BOOTPROM Revision: 00.00.04
RETURN
