- Page 1 SmartSwitch 9000 9C500 Plus Power Box Installation Guide 9031344-02...
- Page 3 Notice Notice Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.
-
Page 4: Fcc Notice
Notice FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. -
Page 5: Declaration Of Conformity Addendum
Declaration of Conformity Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Mr. - Page 6 Notice...
-
Page 7: Table Of Contents
Chapter 1 Installing the 9C500 Plus Power Box Getting Help ... 1-2 Installation... 1-2 Installing the Power Box ... 1-3 Connecting Auxiliary Power Cord... 1-3 Attaching Terminator ... 1-5 Installing Power Supplies ... 1-6 Powering Up Power Supplies ... 1-7 Replacing Power Supplies ... - Page 8 Contents...
-
Page 9: Installing The 9C500 Plus Power Box
Chapter 1 Installing the 9C500 Plus Power Box The 9C500 Plus Power Box (power box) is installed in a standard 19 inch equipment rack near the SmartSwitch 9000 9C114 Chassis (chassis) only after two power supplies (9C214-1 AC or 9C214-2 DC) have been attached directly to the chassis. -
Page 10: Getting Help
1. Install the power box in a standard 19 inch equipment rack. 2. Connect the auxiliary power cord from the power box to the chassis. 3. Attach the terminator (if only one power box is being added) to the chassis. 4. Install the power supplies in the power box. -
Page 11: Installing The Power Box
If the connection is made to the right auxiliary power source connector (Figure 1-1), the power supply in the right side of the power box is number 3 and the power supply in the left side is number 4. - Page 12 4. Secure the plug to the power box by inserting the captive screw attached to the bracket on the power cord in the hole in front of the power cord connection on the power box and tightening the screw.
-
Page 13: Attaching Terminator
Figure 1-1. Connecting Auxiliary Power Cord Attaching Terminator If you are connecting only one power box to a chassis, the unused auxiliary power source connector on the rear of the chassis must be terminated. To complete the termination, use the terminator included in the auxiliary power cord accessory package and follow the steps below. -
Page 14: Installing Power Supplies
Power supplies are installed from the rear of the power box (looking from the back of the power box to the front refer to Figure 1-2). The first power supply is installed in the right side of the power box, the second is installed in the left side. -
Page 15: Powering Up Power Supplies
Turn on the power supply using the switch located near the power cord. The power supply uses a soft start feature and does a pre-power diagnostic check. Outputs become enabled within five seconds of power on. Installing the 9C500 Plus Power Box Slide this end in toward front of... -
Page 16: Replacing Power Supplies
1. Loosen the two screws on the top of the power supply. 2. Press down firmly on the ejector tab on the rear of the power box to unseat the power supply. 3. Grasp the top and bottom handles of the power supply, lift up and remove. -
Page 17: Operating Specifications
• IEC 801-4 EFT SmartSwitch 9000 Chassis Dimensions 76.2 H x 48.3 W x 49.3 D centimeters (30 H x 19 W x 19.4 D inches) Weight Unit: 19.96 kilograms (44 pounds) Shipping: 24.95 kilograms (55 pounds) Installing the 9C500 Plus Power Box... -
Page 18: Plus Power Box
Installing the 9C500 Plus Power Box Plus Power Box Dimensions 22.22 H x 48.3 W x 56.52 D centimeters (8.75 H x 19.0 W x 25.25 D inches) Weight Unit: 5.40 kilograms (12 pounds) Shipping: 6.75 kilograms (15 pounds) 1-10...
