Cabletron Systems SmartSwitch 9000 Appendix page 7

FNB Resource Configuration Codes
Table 2 lists and describes the FDDI connections from which you can select.
Configuration
1
2
3
4
5
6
7
Table 2. 9F426-02 FDDI Switch Modules FNB Resource Configuration Codes
ID
FNB1 <-> FNB2
FNB1 <-> FRONT2
FNB2 <-> FNB1
FRONT1 <-> FNB1
FNB2 <-> FRONT2
FRONT1 <-> FNB2
FRONT1 <-> FRONT2
9F426-02 Module Specific Information
FDDI
Connections
Description
The two FDDI Networks on the
backplane (FNB-1 and FNB-2) are
connected to the same
bridge/switch.
The FNB-1 on the backplane and
the FDDI-2 port on the module's
front panel are connected to the
same bridge/switch.
The two FDDI Networks on the
backplane (FNB-1 and FNB-2) are
connected to the same
bridge/switch.
The FDDI-1 port on the module's
front panel and the FNB-1 on the
backplane are connected to the
same bridge/switch.
The FNB-2 on the backplane and
the FDDI-2 port on the module's
front panel are connected to the
same bridge/switch.
The FDDI-1 port on the module's
front panel and the FNB-2 on the
backplane are connected to the
same bridge/switch.
The module's two front panel
ports (FDDI-1 and FDDI-2) are
connected to the same
bridge/switch.
5
