Avaya AP-3 User Manual

Access point

Hide thumbs Also See for AP-3:

User manual (425 pages)

,

Manual (6 pages)

,

Configuration and deployment manual (3 pages)

Table Of Contents

Table of Contents

Advertisement

Quick Links

Download this manual

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the AP-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Avaya AP-3

Page 2 Copyrights • Avaya is a registered trademark of Avaya Inc. • Microsoft Windows is a registered trademark of the Microsoft Corporation. • All trademarks mentioned herein belong to their respective owners. Publication Information © Copyright 2004 Avaya, Inc. All rights reserved.
Page 3: Regulatory Information
See the Regulatory Flyer that came with your AP-3 unit or go to the CD- ROM to view the information. Warranty Avaya Inc. provides a limited warranty on this product. Refer to your sales agreement to establish the terms of the limited warranty. In addition, Avaya’s standard warranty language as well as information regarding...
Page 4 Customers may experience differences in product performance, reliability and security depending upon network configurations/design and topologies, even when the product performs as warranted. To order copies of this and other documents For the most current versions of documentation, go to the Avaya support Web site: http://www.avaya.com/support.
Page 7: Table Of Contents
ScanTool ......... . . 2-21 Avaya Wireless AP-3 User’s Guide...
Page 8 Wireless (802.11b/g) ........4-44 Avaya Wireless AP-3 User’s Guide...
Page 9 Configure Multiple SSID/VLAN/Security Mode Entries ..4-135 Typical VLAN Management Configurations....4-143 Avaya Wireless AP-3 User’s Guide...
Page 10 Update AP by Using TFTP........6-7 Avaya Wireless AP-3 User’s Guide...
Page 11 Important Terminology........A-4 Avaya Wireless AP-3 User’s Guide...
Page 12 DHCP Server Commands ....... . . A-43 Avaya Wireless AP-3 User’s Guide...
Page 13 IP Access Table Commands ....... A-64 IP Access Table Parameters ......A-64 Avaya Wireless AP-3 User’s Guide...
Page 14 SNMP Parameters........A-86 Avaya Wireless AP-3 User’s Guide...
Page 15 Syntax Examples........A-114 Avaya Wireless AP-3 User’s Guide...
Page 16 802.11g Channel Frequencies ......C-14 Wireless Communication Range ......C-16 Avaya Wireless AP-3 User’s Guide...
Page 17 Before You Seek Help ........D-1 Avaya Wireless AP-3 User’s Guide...
Page 18 Avaya Wireless AP-3 User’s Guide...
Page 19: Introduction
The AP-3 is a Dual-radio AP. • An 802.11a AP is an Access Point that supports the IEEE 802.11a standard. • An 802.11b AP is an Access Point that supports the IEEE 802.11b Avaya Wireless AP-3 User’s Guide...
Page 20: Introduction To Wireless Networking
Wireless devices can • connect to a single Access Point, or • move between multiple Access Points located within the same vicinity. As wireless clients move from one coverage cell to another, the devices maintain network connectivity. Avaya Wireless AP-3 User’s Guide...
Page 21: Site Survey
Introduction to Wireless Networking Site Survey To determine the best location for an Access Point, Avaya recommends conducting a Site Survey before placing the device in its final location. For information about how to conduct a Site Survey, contact your local reseller.
Page 22: Guidelines For Roaming
An AP can only communicate with client devices that support its wireless standard. For example, an 802.11a client cannot communicate with an 802.11b AP and an 802.11b client cannot communicate with an 802.11a AP. However, both 802.11b and 802.11g clients can communicate with an 802.11b/g AP. Avaya Wireless AP-3 User’s Guide...
Page 23 2.4 GHz frequency band; the 802.11a AP operates in the 5 GHz band. Products that operate in the 2.4 GHz band offer greater range than products that operate in the 5 GHz band. Avaya Wireless AP-3 User’s Guide...
Page 24: Ieee 802.11 Specifications
GHz frequency band. This standard includes provisions for three radio technologies: direct sequence spread spectrum, frequency hopping spread spectrum, and infrared. Devices that comply with the 802.11 standard operate at a data rate of either 1 or 2 Megabits per second (Mbits/sec). Avaya Wireless AP-3 User’s Guide...
Page 25 2.4 GHz frequency band using OFDM to achieve data rates of up to 54 Mbits/sec. In addition, 802.11g devices are backwards compatible with 802.11b devices. Available Frequency Channels vary by regulatory domain and/or country. See 802.11g Channel Frequencies details. Avaya Wireless AP-3 User’s Guide...
Page 26: Management And Monitoring Capabilities
AP in a secure fashion by using Secure Socket Layer (SSL) over port 443. The AP supports SSLv3 with a 128-bit encryption certificate maintained by the AP for secure communications between the AP and the HTTP client. All Avaya Wireless AP-3 User’s Guide...
Page 27: Command Line Interface
How To Access the CLI You access the CLI over a HyperTerminal serial connection or via Telnet. During initial configuration, you can use the CLI over a serial port connection to configure an Access Point’s IP address. Avaya Wireless AP-3 User’s Guide...
Page 28: Snmp Management
The AP supports several Management Information Base (MIB) files that describe the parameters that can be viewed and/or configured over SNMP: • MIB-II (RFC 1213) • Bridge MIB (RFC 1493) • Ethernet-like MIB (RFC 1643) • 802.11 MIB • Avaya Wireless Enterprise MIB 1-10 Avaya Wireless AP-3 User’s Guide...
Page 29 Management and Monitoring Capabilities Avaya provides these MIB files on the CD included with each Access Point. You need to compile one or more of the above MIBs into your SNMP program’s database before you can manage an Access Point using SNMP.
Page 30 HTTP Web interface or the CLI interface. For information on how to manage devices using SNMP, refer to the documentation that came with your SNMP program. Also, refer to the MIB files for information on the parameters available via SNMP. 1-12 Avaya Wireless AP-3 User’s Guide...
Page 31: Getting Started
Additional Hardware Features Prerequisites Before installing an AP, you need to gather certain network information. The following section identifies the information you need. NOTE: Passwords must be configured with at least 6 characters in length. Avaya Wireless AP-3 User’s Guide...
Page 32 The default password is “public”. SNMP Read-Write Each Access Point requires a password to Password allow get and set requests from an SNMP manager. The default password is “public”. This password must be at least 6 characters in length. Avaya Wireless AP-3 User’s Guide...
Page 33 Authentication This is a password shared between the Server Shared Access Point and the RADIUS Secret authentication server (so both passwords must be the same), and is typically provided by the network administrator. Avaya Wireless AP-3 User’s Guide...
Page 34 The Access Point can automatically provide Pool Allocation IP addresses to clients as they sign on. The Scheme network administrator typically provides the IP Pool range. DNS Server IP The network administrator typically provides Address this IP Address. Avaya Wireless AP-3 User’s Guide...
Page 35: Product Package
— this user’s guide in PDF format • One Access Point Quick Start Guide If any of these items are missing or damaged, please contact your reseller or Technical Support (see Technical Support for contact information). Avaya Wireless AP-3 User’s Guide...
Page 36: Ghz Antenna Adapter Or Ap-3 11A Upgrade Kit
• At least one of the following IEEE 802.11-compliant devices: You will need an: If you have an: 802.11a client device 802.11a AP 802.11b or 802.11b/g client device 802.11b AP 802.11b/g client device 802.11b/g AP Avaya Wireless AP-3 User’s Guide...
Page 37: Hardware Installation
• AP-3 with Active Ethernet • AP-3 with Power Supply • 5 GHz or AP-3 11a Upgrade Kit AP-3 with Active Ethernet 1. Slide the AP module onto the mounting bracket. Make sure it is properly seated. Avaya Wireless AP-3 User’s Guide...
Page 38 (not included in the kit) into Slot A or B. NOTE: The 802.11a wireless card with antenna adapter will only fit in Slot 3. Slide an 802.11b or an 802.11b/g wireless card (included in the kit) into Slot A or B. Avaya Wireless AP-3 User’s Guide...
Page 39 Figure 2-2. Slide a PC Card into the AP 4. Connect power to the unit from a DC injector device, such as the Avaya Wireless 1-Port Active Ethernet DC Injector hub. 5. Wait for the LED indicators to turn green before proceeding.
Page 40 If you need assistance, contact your reseller for help. 7. Once you have chosen a final location for your unit, mount the wall bracket and the processor module and place the cover onto the unit as shown. 2-10 Avaya Wireless AP-3 User’s Guide...
Page 41: Ap-3 With Power Supply
Hardware Installation Figure 2-4. Wall mounting the AP AP-3 with Power Supply 1. Clip the power supply into the mounting bracket. 2. Plug the AC power cord into the power supply. Avaya Wireless AP-3 User’s Guide 2-11...
Page 42 Figure 2-5. Install the power supply 3. Slide the AP module onto the mounting bracket. Make sure it is properly seated. 4. Plug the DC connector from the power supply into the top of the AP module. 2-12 Avaya Wireless AP-3 User’s Guide...
Page 43 Hardware Installation Figure 2-6. Insert module in mounting bracket and attach power connector Avaya Wireless AP-3 User’s Guide 2-13...
Page 44 5. Attach one end of an Ethernet cable to the AP's Ethernet port and the other end to a network hub or switch. 6. Connect the unit to a power source. 7. Wait for the power LED to turn green before proceeding. 2-14 Avaya Wireless AP-3 User’s Guide...
Page 45 8. Conduct a Site Survey to determine the best location for your device. 9. Once you have chosen a final location for your unit, mount the wall bracket and the processor module and place the cover onto the unit as shown. Avaya Wireless AP-3 User’s Guide 2-15...
Page 46: Ghz Or Ap-3 11A Upgrade Kit
1. Remove the AP from your network by unplugging the power and Ethernet cables from the unit. 2. Remove the unit from its mounting location - keep the mounting bracket with the AP. 3. Remove the outer plastic cover. 2-16 Avaya Wireless AP-3 User’s Guide...
Page 47 5. Position the antenna adapter, card inward, facing the top of the unit (see Figure 2-11 Insert Card and Antenna) and insert the 5 GHz card into the available card slot. Avaya Wireless AP-3 User’s Guide 2-17...
Page 48 Hardware Installation Figure 2-11. Insert Card and Antenna 2-18 Avaya Wireless AP-3 User’s Guide...
Page 49 — at a 90° angle for flat surface mounts — at a 180° angle for wall mounts 9. Re-install the cover and mount the AP back in place. Figure 2-12. Replace cover 10. Connect the power and Ethernet cables to the AP. Avaya Wireless AP-3 User’s Guide 2-19...
Page 50: Initialization
Initialization Initialization Avaya provides two tools to simplify the initialization and configuration of an AP: • ScanTool • Setup Wizard ScanTool is included on the Installation CD; the Setup Wizard launches automatically the first time you access the HTTP interface.
Page 51: Scantool
If your network does not contain a DHCP server, the Access Point’s IP address defaults to 10.0.0.1. In this case, you can use ScanTool to assign the AP a static IP address that is valid on your network. Avaya Wireless AP-3 User’s Guide 2-21...
Page 52 AP. — Result: The installation program will launch automatically. 5. Follow the on-screen instructions to install the Access Point software and documentation. NOTE: The Avaya Wireless Installation program supports the following operating systems: — Windows 98SE — Windows 2000 2-22...
Page 53 OK. You can change your adapter setting at any time by clicking the Select Adapter button on the Scan List screen. The ScanTool Network Adapter Selection screen will not appear if your computer only has one network adapter installed. Avaya Wireless AP-3 User’s Guide 2-23...
Page 54 Rescan button to update the display. If the unit still does not appear in the list, see Troubleshooting for suggestions. Note that after rebooting an Access Point, it may take up to five minutes for the unit to appear in the Scan List. 2-24 Avaya Wireless AP-3 User’s Guide...
Page 55 — If the AP has not been assigned an IP address (in other words, the unit is using its default IP address, 10.0.0.1), follow these steps to assign it a static IP address that is valid on your network: Avaya Wireless AP-3 User’s Guide 2-25...
Page 56 Initialization Step Action Highlight the entry for the AP you want to configure. Click the Change button. Result: The Change screen appears. Figure 2-14. Scan Tool Change Screen 2-26 Avaya Wireless AP-3 User’s Guide...
Page 57 “public”). NOTE: The TFTP Server IP Address and Image File Name fields are only available if ScanTool detects that the AP does not have a valid software image installed. See Client Connection Problems. Avaya Wireless AP-3 User’s Guide 2-27...
Page 58 When prompted, click OK a second time to return to the Scan List screen. Click Cancel to close the ScanTool. Proceed to Setup Wizard for information on how to access the HTTP interface. 2-28 Avaya Wireless AP-3 User’s Guide...
Page 59: Setup Wizard
Internet Explorer users, follow these steps: a. Select Tools > Internet Options..b. Click the Connections tab. c. Click LAN Settings..d. If necessary, remove the check mark from the Use a proxy server box. Avaya Wireless AP-3 User’s Guide 2-29...
Page 60 — Result: The Enter Network Password screen appears. 4. Enter the HTTP password in the Password field. Leave the User Name field blank. For new units, the default HTTP password is “public”. — Result: The Setup Wizard will launch automatically. 2-30 Avaya Wireless AP-3 User’s Guide...
Page 61 Initialization Figure 2-15. Enter Network Password Avaya Wireless AP-3 User’s Guide 2-31...
Page 62 & Next button. Click this button to submit any changes you made to the unit’s parameters and continue to the next page. The instructions described next shown how to navigate the Setup Wizard using the Save & Next buttons. 2-32 Avaya Wireless AP-3 User’s Guide...
Page 63 8. Assign the AP new passwords to prevent unauthorized access and click Save & Next. Each management interface has its own password: — SNMP Read Password — SNMP Read-Write Password — SNMPv3 Authentication Password — SNMPv3 Privacy Password Avaya Wireless AP-3 User’s Guide 2-33...
Page 64 The AP supports up to 16 SSIDs Names (SSIDs) and VLANs per wireless interface (radio). Refer to the Advanced Configuration chapter for information on the detailed rules on configuring multiple SSIDs, VLANs, and security modes. 1 of 5 2-34 Avaya Wireless AP-3 User’s Guide...
Page 65 Remove the check mark to disable this option. Note that you cannot disable Auto Channel Select for 802.11a products in Europe (see Dynamic Frequency Selection (DFS) for details). 2 of 5 Avaya Wireless AP-3 User’s Guide 2-35...
Page 66 Choose between 6, 9, 12, 18, 24, 36, 48, 54 Mbits/s, and Auto Fallback. The Auto Fallback feature allows the AP to select the best transmit rate based on the cell size. 3 of 5 2-36 Avaya Wireless AP-3 User’s Guide...
Page 67 Initialization Option Description WEP Encryption Place a check mark in the box provided to enable WEP encryption. WEP Encryption for more information. 4 of 5 Avaya Wireless AP-3 User’s Guide 2-37...
Page 68 Chart) to use 64-bit encryption. • Enter 26 hexadecimal characters or 13 ASCII characters to use 128-bit encryption. • Enter 32 hexadecimal characters or 16 ASCII characters to use 152-bit encryption. 5 of 5 2-38 Avaya Wireless AP-3 User’s Guide...
Page 69 Remove the check mark to disable this option. If you are setting up a Wireless Distribution System (WDS), it must be disabled. See Wireless Distribution System (WDS) for more information. 1 of 4 Avaya Wireless AP-3 User’s Guide 2-39...
Page 70 Multicast Rate (described next). In general, a larger distance between APs means that your clients operate a slower data rates (on average). Distance Between APs for more information. 2 of 4 2-40 Avaya Wireless AP-3 User’s Guide...
Page 71 1 and 2 Mbits/sec Medium 1, 2, and 5.5 Mbits/sec Small 1, 2, 5.5 and 11 Mbits/sec Minicell 1, 2, 5.5 and 11 Mbits/sec Microcell 1, 2, 5.5 and 11 Mbits/sec 3 of 4 Avaya Wireless AP-3 User’s Guide 2-41...
Page 72 (0-9 and A-F) or 5 ASCII characters (see ASCII Character Chart) to use 64-bit encryption. • Enter 26 hexadecimal characters (0-9 and A-F) or 13 ASCII characters to use 128-bit encryption 4 of 4 2-42 Avaya Wireless AP-3 User’s Guide...
Page 73 The AP supports up to 16 SSIDs and Names (SSIDs) VLANs per wireless interface (radio). Refer to the Advanced Configuration chapter for information on the detailed rules on configuring multiple SSIDs, VLANs, and security modes. 1 of 5 Avaya Wireless AP-3 User’s Guide 2-43...
Page 74 Access Point’s channel. If you decide to manually set the unit’s channel, ensure that nearby devices do not use the same frequency. Available Channels vary based on regulatory domain. See 802.11g Channel Frequencies. 2 of 5 2-44 Avaya Wireless AP-3 User’s Guide...
Page 75 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbits/sec WEP Encryption Place a check mark in the box provided to enable WEP encryption. WEP Encryption for more information. 3 of 5 Avaya Wireless AP-3 User’s Guide 2-45...
Page 76 Chart) to use 64-bit encryption. • Enter 26 hexadecimal characters or 13 ASCII characters to use 128-bit encryption. • Enter 32 hexadecimal characters or 16 ASCII characters to use 152-bit encryption. 4 of 5 2-46 Avaya Wireless AP-3 User’s Guide...
Page 77 After making a change, click Save & Next to save the change and proceed to the next screen. 11. When finished, click Reboot on the Summary screen to restart the AP and apply your changes. Avaya Wireless AP-3 User’s Guide 2-47...
Page 78: Download The Latest Software
Download the Latest Software Download the Latest Software Avaya periodically releases updated software for the AP on its Web site at http://www.avaya.com/support. Avaya recommends that you check the Web site for the latest updates after you have installed and initialized the unit.
Page 79: Download Updates From A Tftp Server Using The Web Interface
Receive files, with no automatic shutdown or time-out. Download Updates from a TFTP Server using the Web Interface 1. Download the latest software from http://www.avaya.com/support. 2. Copy the latest software updates to your TFTP server. 3. In the Web Interface, click the Commands button and select the Download tab.
Page 80: Download Updates From A Tftp Server Using The Cli Interface
9. The Access Point will reboot automatically when the download is complete. Download Updates from a TFTP Server using the CLI Interface 1. Download the latest software from http://www.avaya.com/support. 2. Copy the latest software updates to your TFTP server. 3. Open the CLI interface via Telnet or a serial connection.
Page 81: Additional Hardware Features
• The power supply of the Access Point has been removed. • There are two 802.11b cards in the cards slots. • There is one 802.11b card and the other card slot is protected with the metal faceplate provided in your kit. Avaya Wireless AP-3 User’s Guide 2-51...
Page 82: Active Ethernet
Active Ethernet module. Active Ethernet (AE) delivers both data and power to the access point over a single Ethernet cable. If you choose to use Active Ethernet, there is no difference in operation; the only difference is in the power source. 2-52 Avaya Wireless AP-3 User’s Guide...
Page 83 10 Watts. Also see Hardware Specifications. NOTE: The AP’s 802.3af-compliant Active Ethernet module is backwards compatible with all Avaya Wireless Active Ethernet hubs that do not support the IEEE 802.3af standard. Avaya Wireless AP-3 User’s Guide 2-53...
Page 84: Led Indicators
Power On Self Test (POST) running PC Card incompatible on indicated interface. PC Card failure on indicated interface. Green Amber Amber Indicated interface in Administrative State PC Card not present 2-54 Avaya Wireless AP-3 User’s Guide...
Page 85: Related Topics
Access Point’s HTTP interface. • See Troubleshooting for troubleshooting suggestions. • See The Command Line Interface for information on the CLI interface and for a list of CLI commands. Avaya Wireless AP-3 User’s Guide 2-55...
Page 86 Related Topics 2-56 Avaya Wireless AP-3 User’s Guide...
Page 87: Status Information
The HTTP interface supports the following Web browser: — Microsoft Internet Explorer 6 with Service Pack 1 or later — Netscape 6.1 or later 2. If necessary, disable the Internet proxy settings. For Internet Explorer users, follow these steps: Avaya Wireless AP-3 User’s Guide...
Page 88 — Result: The Enter Network Password screen appears. 4. Enter the HTTP password in the Password field and click OK. Leave the User Name field blank. (By default, the HTTP password is “public”). — Result: The System Status screen appears. Avaya Wireless AP-3 User’s Guide...
Page 89: System Status
Figure 3-1. Enter Network Password Screen System Status System Status is the first screen to appear each time you connect to the HTTP interface. You can also return to this screen by clicking the Status button. Avaya Wireless AP-3 User’s Guide...
Page 90 System Status Figure 3-2. System Status Screen Avaya Wireless AP-3 User’s Guide...
Page 91 — System Alarms: System traps (if any) appear in this area. Each trap identifies a specific severity level: Critical, Major, Minor, and Informational. See Alarms for a list of possible alarms. Avaya Wireless AP-3 User’s Guide...
Page 92 System Status Avaya Wireless AP-3 User’s Guide...
Page 93: Advanced Configuration
• Bridge: Configure the Spanning Tree Protocol, Storm Threshold protection, Intra BSS traffic, and Packet Forwarding. • Security: Configure security features such as MAC Access Control, WPA, WEP Encryption, and 802.1x. Configure Rogue Access Point Avaya Wireless AP-3 User’s Guide...
Page 94: Configuring The Ap Using The Http/Https Interface
— Netscape 6.1 or later 2. If necessary, disable the Internet proxy settings. For Internet Explorer users, follow these steps: — Select Tools > Internet Options..— Click the Connections tab. — Click LAN Settings..Avaya Wireless AP-3 User’s Guide...
Page 95 4. Enter the HTTP password in the Password field and click OK. Leave the User Name field blank. (By default, the HTTP password is “public”). — Result: The System Status screen appears. Figure 4-1. Enter Network Password Screen Avaya Wireless AP-3 User’s Guide...
Page 96 6. Click the tab that corresponds to the parameter you want to configure. For example, click Network to configure the Access Point’s TCP/IP settings. The parameters contained in each of the configuration categories are described later in this chapter. Avaya Wireless AP-3 User’s Guide...
Page 97: System
The name of the person responsible for the Contact Email The email address of the person responsible for the AP. Contact Phone The telephone number of the person responsible for the AP. 1 of 2 Avaya Wireless AP-3 User’s Guide...
Page 98: Dynamic Dns Support
DNS is a distributed database that maps the user-readable names and IP addresses (and more) of every registered system on the Internet. Dynamic DNS is a lightweight mechanism that allows for modification of the DNS data of host systems whose IP addresses change dynamically. Avaya Wireless AP-3 User’s Guide...
Page 99 • The number of characters must be 63 or less. (Currently the system name length is limited to 32 bytes). Image upgrades can cause the system to boot with an older system name format that is not DNS compliant. To prevent problems with dynamic DNS Avaya Wireless AP-3 User’s Guide...
Page 100: Network
You can configure and view the following parameters within the IP Configuration screen: NOTE: You must reboot the Access Point in order for any changes to the Basic IP or DNS Client parameters take effect. Avaya Wireless AP-3 User’s Guide...
Page 101 Address Assignment Type is set to Dynamic, this field is read-only and reports the unit’s current IP address. The Access Point will default to 10.0.0.1 if it cannot obtain an address from a DHCP server. 1 of 2 Avaya Wireless AP-3 User’s Guide...
Page 102 (DNS) client. When this feature is enabled, the Access Point contacts the network’s DNS server to translate a host name to the appropriate network IP address. You can use this DNS Client functionality to identify RADIUS servers by host name. See RADIUS for details. 4-10 Avaya Wireless AP-3 User’s Guide...
Page 103 The Access Point uses the default TTL for packets it generates for which the transport layer protocol does not specify a TTL value. This parameter supports a range from 0 to 65535. By default, TTL is 64. Avaya Wireless AP-3 User’s Guide 4-11...
Page 104: Dhcp Server
IP address before enabling this feature. When the DHCP Server functionality is enabled, you can create one or more IP address pools from which to assign addresses to network devices. 4-12 Avaya Wireless AP-3 User’s Guide...
Page 105 Network Figure 4-3. DHCP Server Configuration Screen Avaya Wireless AP-3 User’s Guide 4-13...
Page 106 DHCP clients. Primary DNS IP The AP will assign the specified address to its Address DHCP clients. Secondary DNS IP The AP will assign the specified address to its Address DHCP clients. 1 of 4 4-14 Avaya Wireless AP-3 User’s Guide...
Page 107 Network Parameter Description Number of IP Pool This is a read-only field that reports the Table Entries number of IP address pools currently configured. 2 of 4 Avaya Wireless AP-3 User’s Guide 4-15...
Page 108 IP address. DHCP automatically renews IP Addresses without client notification. This parameter supports a range between 3600 and 86400 seconds. The default is 86400 seconds. • Comment (optional) 3 of 4 4-16 Avaya Wireless AP-3 User’s Guide...
Page 109: Link Integrity
AP disables its wireless interface until the connection is restored. This forces the unit’s wireless clients to switch to another Access Point that still has a network connection. Note that this feature does not affect WDS links (if applicable). Avaya Wireless AP-3 User’s Guide 4-17...
Page 110 • Target IP Address • Comment (optional) • Status: Set this field to Enable to specify that the Access Point should poll this device. You can also disable an entry by changing this field’s value to Disable. 4-18 Avaya Wireless AP-3 User’s Guide...
Page 111 Network Figure 4-4. Link Integrity Configuration Screen Avaya Wireless AP-3 User’s Guide 4-19...
Page 112: Interfaces
For the wireless interface configuration, refer to the wireless parameters below that correspond to your radio type. • Operational Mode • Wireless (802.11a) • Wireless (802.11b) • Wireless (802.11b/g) • Wireless (802.11a/g) • Wireless Distribution System (WDS) • Ethernet 4-20 Avaya Wireless AP-3 User’s Guide...
Page 113 The TX Power Control feature lets the user configure the transmit power level of the card in the AP at one of four levels: • 100% of the maximum transmit power level of the card • 50% • 25% • 12.5% Avaya Wireless AP-3 User’s Guide 4-21...
Page 114 3. Select the transmit power level for interface A from the Wireless-A: Transmit Power Level drop-down menu.Select the transmit power level for interface B from the Wireless-B: Transmit Power Level drop-down menu. 4. Click OK. Figure 4-5. Operational Mode Screen - TX Power Control 4-22 Avaya Wireless AP-3 User’s Guide...
Page 115 802.11a devices. MAC Address This is a read-only field that displays the unique MAC (Media Access Control) address for the Access Point’s wireless interface. The MAC address is assigned at the factory. 1 of 5 Avaya Wireless AP-3 User’s Guide 4-23...
Page 116 • TW: Taiwan Network Name Enter a Network Name (between 2 and 31 (SSID) characters long) for the wireless network. You must configure each wireless client to use this name as well. 2 of 5 4-24 Avaya Wireless AP-3 User’s Guide...
Page 117 Available Channels vary based on regulatory domain. See 802.11a Channel Frequencies. Note that you cannot manually set the channel for 802.11a products in Europe (see Dynamic Frequency Selection (DFS) details). 3 of 5 Avaya Wireless AP-3 User’s Guide 4-25...
Page 118 DTIM should be left at 1, the default value, if any clients have power management enabled. This parameter supports a range between 1 and 255. 4 of 5 4-26 Avaya Wireless AP-3 User’s Guide...
Page 119 AP scans the available frequency and selects a channel that is free of interference. If the AP subsequently detects interference on its channel, it automatically reboots and selects another channel that is free of interference. Avaya Wireless AP-3 User’s Guide 4-27...
Page 120 This typically occurs when there are hidden nodes (clients that can communicate with the Access Point but are out of range of each other) in very large cells. 4-28 Avaya Wireless AP-3 User’s Guide...
Page 121 2347, the Access Point uses the RTS/CTS mechanism for packets that are the specified size or greater. You should not need to enable this parameter for most networks unless you suspect that the wireless cell contains hidden nodes. Avaya Wireless AP-3 User’s Guide 4-29...
Page 122 MAC Address This is a read-only field that displays the unique MAC (Media Access Control) address for the Access Point’s wireless interface. The MAC address is assigned at the factory. 1 of 9 4-30 Avaya Wireless AP-3 User’s Guide...
Page 123 • IL - Israel Network Name Enter a Network Name (between 2 and 31 (SSID) characters long) for the wireless network. You must configure each wireless client to use this name as well. 2 of 9 Avaya Wireless AP-3 User’s Guide 4-31...
Page 124 If you decide to manually set the unit’s channel, ensure that nearby devices do not use the same frequency (unless you are setting up a WDS). Available Channels vary based on regulatory domain. See 802.11b Channel Frequencies. 3 of 9 4-32 Avaya Wireless AP-3 User’s Guide...
Page 125 Large. The distance value is related to the Multicast Rate (described next). In general, a larger distance between APs means that your clients operate a slower data rates (on average). See Distance Between APs more information. 4 of 9 Avaya Wireless AP-3 User’s Guide 4-33...
Page 126 1 and 2 Mbits/sec Medium 1, 2, and 5.5 Mbits/sec Small 1, 2, 5.5 and 11 Mbits/sec Minicell 1, 2, 5.5 and 11 Mbits/sec Microcell 1, 2, 5.5 and 11 Mbits/sec 5 of 9 4-34 Avaya Wireless AP-3 User’s Guide...
Page 127 Access Point uses the RTS/CTS mechanism for packets that are the specified size or greater. When set to 2347 (the default setting), RTS/CTS is disabled. See RTS/CTS Medium Reservation for more information. 6 of 9 Avaya Wireless AP-3 User’s Guide 4-35...
Page 128 Access Point’s specific Network Name to associate with the Access Point. When enabled, a client configured with the Network Name “ANY” cannot connect to the AP. This option is disabled by default. 7 of 9 4-36 Avaya Wireless AP-3 User’s Guide...
Page 129 AP loads. This feature is enabled by default; it helps distribute the wireless load between APs. This feature is not available if you are using an Avaya 802.11a/b Card or a non-Avaya Wireless client with the AP. 8 of 9 Avaya Wireless AP-3 User’s Guide...
Page 130 NOTE: This feature is not available if you are using an Avaya 802.11a/b Card or a non-Avaya Wireless client with the AP. Avaya recommends that you leave this parameter enabled, particularly if you have Avaya Wireless clients on your wireless...
Page 131 NOTE: This feature is not available if you are using an Avaya 802.11a/b Card or a non-Avaya Wireless client with the AP. Cell capacities are compared in the following table, which shows that small cells suit most offices and large cells suit most warehouses:...
Page 132 10 feet. In contrast, a typical warehouse might have a low density area consisting of large cells (with a diameter of about 90 feet) and Access Points installed every 200 feet. 4-40 Avaya Wireless AP-3 User’s Guide...
Page 133 APs is calculated to suit your particular business requirements. Contact your reseller for information on how to conduct a Site Survey. Avaya Wireless AP-3 User’s Guide 4-41...
Page 134 Multicast Rate to 11 Mbits/sec. However, if the Access Point’s cell is large, you need to accommodate stations that may not be able to receive multicast packets at the higher rates; in this case, you should set Multicast Rate to 1 or 2 Mbits/sec. 4-42 Avaya Wireless AP-3 User’s Guide...
Page 135 Figure 4-7. 1 Mbits/s and 11 Mbits/s Multicast Rates NOTE: There is an inter-dependent relationship between the Distance between APs and the Multicast Rate. In general, larger systems operate at a lower average transmit rate. The variation between Avaya Wireless AP-3 User’s Guide 4-43...
Page 136 AP. Wireless (802.11b/g) You can configure the following radio parameters for an 802.11b/g AP: NOTE: You must reboot the Access Point before any changes to these parameters take effect. 4-44 Avaya Wireless AP-3 User’s Guide...
Page 137 802.11g only mode. In general, you should use either 802.11g only mode (if you want to support 802.11g devices only) or 802.11b/g mode to support a mix of 802.11b and 802.11g devices. 1 of 5 Avaya Wireless AP-3 User’s Guide 4-45...
Page 138 802.11b devices. MAC Address This is a read-only field that displays the unique MAC (Media Access Control) address for the Access Point’s wireless interface. The MAC address is assigned at the factory. 2 of 5 4-46 Avaya Wireless AP-3 User’s Guide...
Page 139 This helps prevent interference problems and increases network performance. By default this feature is enabled; 802.11g Channel Frequencies for a list of Channels. 3 of 5 Avaya Wireless AP-3 User’s Guide 4-47...
Page 140 • For 802.11g only -- Auto Fallback, 6, 9, 12, 18, 24, 36, 48, 54 Mbits/sec • For 802.11b/g and 802.11g-wifi -- Auto Fallback, 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbits/sec 4 of 5 4-48 Avaya Wireless AP-3 User’s Guide...
Page 141 Access Point’s specific Network Name to associate with the Access Point. When enabled, a client configured with the Network Name ANY cannot connect to the AP. This option is disabled by default. 5 of 5 Avaya Wireless AP-3 User’s Guide 4-49...
Page 142 You can configure and view the following radio parameters within the Wireless Interface Configuration screen for an 802.11a/g AP: NOTE: You must reboot the Access Point before any changes to these parameters take effect. 4-50 Avaya Wireless AP-3 User’s Guide...
Page 143 802.11g only mode. In general, you should use either 802.11g only mode (if you want to support 802.11g devices only) or 802.11b/g mode to support a mix of 802.11b and 802.11g devices. 1 of 7 Avaya Wireless AP-3 User’s Guide 4-51...
Page 144 802.11b devices. MAC Address This is a read-only field that displays the unique MAC (Media Access Control) address for the Access Point’s wireless interface. The MAC address is assigned at the factory. 2 of 7 4-52 Avaya Wireless AP-3 User’s Guide...
Page 145 • TW: Taiwan Network Name Enter a Network Name (between 2 and 31 (SSID) characters long) for the wireless network. You must configure each wireless client to use this name as well. 3 of 7 Avaya Wireless AP-3 User’s Guide 4-53...
Page 146 802.11a Channel Frequencies 802.11g Channel Frequencies for a list of Channels. NOTE: You cannot disable Auto Channel Select for 802.11a products in Europe (see Dynamic Frequency Selection (DFS) for details). 4 of 7 4-54 Avaya Wireless AP-3 User’s Guide...
Page 147 Available Channels vary based on regulatory domain. See 802.11a Channel Frequencies 802.11g Channel Frequencies. Note that you cannot manually set the channel for 802.11a products in Europe (see Dynamic Frequency Selection (DFS) details). 5 of 7 Avaya Wireless AP-3 User’s Guide 4-55...
Page 148 • For 802.11a only -- Auto Fallback, 6, 9, 12, 18, 24, 36, 48, 54 Mbits/s, and Auto Fallback is the default setting; it allows the AP unit to select the best transmit rate based on the cell size. 6 of 7 4-56 Avaya Wireless AP-3 User’s Guide...
Page 149 Access Point’s specific Network Name to associate with the Access Point. When enabled, a client configured with the Network Name ANY cannot connect to the AP. This option is disabled by default. 7 of 7 Avaya Wireless AP-3 User’s Guide 4-57...
Page 150: Wireless Distribution System (Wds)
(represented by the blue line). This link provides Client 1 with access to network resources even though AP 1 is not directly connected to the Ethernet network. Packets destined for or sent by the client are relayed between the Access Points over the WDS link. 4-58 Avaya Wireless AP-3 User’s Guide...
Page 151 Each WDS link is mapped to a logical WDS port on the AP. WDS ports behave like Ethernet ports rather than like standard wireless interfaces: on a BSS port, an Access Point learns by association and from frames; Avaya Wireless AP-3 User’s Guide 4-59...
Page 152 APs. For example, creating a WDS link between two Access Points connected to the same Ethernet network will create a network loop (if spanning tree is disabled). For more information, refer to the Spanning Tree section. 4-60 Avaya Wireless AP-3 User’s Guide...
Page 153 6. Enter the MAC Address that you wrote down in Step 2 in one of the Partner MAC Address field of the Wireless Distribution Setup window. 7. Set the Status of the device to Enable. 8. Click OK 9. Reboot the AP. Avaya Wireless AP-3 User’s Guide 4-61...
Page 154 NOTE: To set up a Wireless Distribution System (WDS) with 802.1x, set each Access Point’s 802.1x Security Mode to Mixed and assign each unit in the WDS the same Encryption Key 1. See Security. 4-62 Avaya Wireless AP-3 User’s Guide...
Page 155: Ethernet
For best results, Avaya recommends that you configure the Ethernet setting to match the speed and transmission mode of the device the Access Point is connected to (such as a hub or switch). If in doubt, leave this setting at its default, auto-speed-auto-duplex.
Page 156 Password field and the Confirm field. The default password is “public”. Password length is recommended to be at least 8 characters. Secure Management (Services tab) must be enabled to configure SNMPv3. 1 of 2 4-64 Avaya Wireless AP-3 User’s Guide...
Page 157 Confirm field. The default password is “public”. NOTE: For security purposes Avaya recommends changing ALL PASSWORDS from the default “public” immediately, to restrict access to your network devices to authorized personnel. If you lose or forget your password settings, you can always perform Reset to Factory Default Procedure.
Page 158 AP’s management interfaces. • Comment: Enter an optional comment, such as the station name. To edit or delete an entry, click Edit. Edit the information, or select Enable, Disable, or Delete from the Status pull-down menu. 4-66 Avaya Wireless AP-3 User’s Guide...
Page 159: Services
HTTP Access • HTTPS Access (Secure Socket Layer) • Telnet Configuration Settings • Serial Configuration Settings • Automatic Configuration NOTE: You must reboot the Access Point if you change the HTTP Port or Telnet Port. Avaya Wireless AP-3 User’s Guide 4-67...
Page 160 Configure the interface or interfaces Bitmask (Ethernet, Wireless, All Interfaces) from which you will manage the AP via SNMP. You can also select Disabled to prevent a user from accessing the AP via SNMP. 4-68 Avaya Wireless AP-3 User’s Guide...
Page 161 If you exited out of the Setup Wizard and want to relaunch it, enable this option, click OK, and then close your browser or reboot the AP. The Setup Wizard will appear the next time you access the HTTP interface. Avaya Wireless AP-3 User’s Guide 4-69...
Page 162 (SSL) over port 443. The AP supports SSLv3 with a 128-bit encryption certificate maintained by the AP for secure communications between the AP and the HTTP client. All communications are encrypted using the server and the client-side certificate. 4-70 Avaya Wireless AP-3 User’s Guide...
Page 163 SSL Certificate Specifies the SSL passphrase to use if Passphrase Enable HTTPS has been checked. You must change the SSL passphrase when uploading a new certificate/private key pair, which will have a corresponding passphrase. Avaya Wireless AP-3 User’s Guide 4-71...
Page 164 23. However, you can use this field if you want to change the Telnet port for security reasons (but your Telnet application also must support the new port number you select). 1 of 2 4-72 Avaya Wireless AP-3 User’s Guide...
Page 165 Timeout (seconds) will wait during a session while there is no activity. The AP will terminate the session on timeout. The range is 1 to 36000 seconds; the default is 900 seconds. 2 of 2 Avaya Wireless AP-3 User’s Guide 4-73...
Page 166: Serial Configuration Settings
Select either None (default) or Xon/Xoff (software controlled) data flow control. NOTE: To avoid potential problems when communicating with the AP through the serial port, Avaya recommends that you leave the Flow Control setting at None (the default value). Serial Data Bits...
Page 167 When an AP is configured for dynamic IP, the Configuration filename and the TFTP server IP address are contained in the DHCP response when the AP gets its IP address dynamically from the DHCP server. When Avaya Wireless AP-3 User’s Guide 4-75...
Page 168 4. Enter the IP address of the TFTP server in the TFTP Server Address field. NOTE: The default filename is config. The default TFTP IP address is 10.0.0.2. 5. Click OK to save the changes. 4-76 Avaya Wireless AP-3 User’s Guide...
Page 169 Syslog server was configured, the following messages can be observed on the Syslog server: — AutoConfig for Static IP — TFTP server address and configuration filename — AutoConfg Successful Figure 4-11. Automatic Configuration Screen Avaya Wireless AP-3 User’s Guide 4-77...
Page 170 TFTP Server IP address (Boot Server Host Name, option 66) and Configuration file (Bootfile Name, option 67) as follows: 3. Select DHCP Server > DHCP Option > Scope. The DHCP Options: Scope Screen appears. 4-78 Avaya Wireless AP-3 User’s Guide...
Page 171 4. Add the Boot Server Hostname and Boot Filename parameters to the Active Options list. 5. Set the value of the Boot Server Hostname Parameter to the host name or IP Address of the TFTP server. For example: 11.0.0.7. Avaya Wireless AP-3 User’s Guide 4-79...
Page 172 8. Reboot the AP. When the AP reboots it receives the new configuration information and must reboot one additional time. If a Syslog server was configured, the following messages can be observed on the Syslog server: — AutoConfig for Dynamic IP 4-80 Avaya Wireless AP-3 User’s Guide...
Page 173: Filtering
1. Select the interface or interfaces that will implement the filter from the Ethernet Protocol Filtering drop-down menu. — Ethernet: Packets are examined at the Ethernet interface — Wireless: Packets are examined at the Wireless interface Avaya Wireless AP-3 User’s Guide 4-81...
Page 174 — An entry’s status must be enabled in order for the protocol to be subject to the filter. 4. Reboot the AP for any changes to the Ethernet Protocol Filter Table to take effect. 4-82 Avaya Wireless AP-3 User’s Guide...
Page 175: Static Mac
• Comment: This field is optional. Each MAC Address or Mask is comprised of 12 hexadecimal digits (0-9, A-F) that correspond to a 48-bit identifier. (Each hexadecimal digit represents 4 bits (0 or 1).) Avaya Wireless AP-3 User’s Guide 4-83...
Page 176 FF:FF:FF:00:00:00, the AP will examine the source and destination addresses of each packet looking for any MAC address starting with 00:20:A6. If the Mask is FF:FF:FF:FF:FF:FF, the AP will only look for the specific MAC address (in this case, 00:20:A6:12:54:C3). 4-84 Avaya Wireless AP-3 User’s Guide...
Page 177 Masks to setup a filter. The entry is enabled automatically when saved. To edit an entry, click Edit. To disable or remove an entry, click Edit and change the Status field from Enable to Disable or Delete. Avaya Wireless AP-3 User’s Guide 4-85...
Page 178 Filtering Figure 4-14. Static MAC Configuration Screen 4-86 Avaya Wireless AP-3 User’s Guide...
Page 179 • Wired Mask: FF:FF:FF:FF:FF:FF • Wireless MAC Address: 00:02:2D:51:94:E4 • Wireless Mask: FF:FF:FF:FF:FF:FF Result: Traffic between the Wired Server and Wireless Client 1 is blocked. Wireless Clients 2 and 3 can still communicate with the Wired Server. Avaya Wireless AP-3 User’s Guide 4-87...
Page 180 Client 2 share the same prefix (00:02:2D), traffic between the Wired Server and Wireless Clients 1 and 2 is blocked. Wireless Client 3 can still communicate with the Wired Server since it has a different prefix (00:20:A6). 4-88 Avaya Wireless AP-3 User’s Guide...
Page 181 Ethernet. • Wired MAC Address: 00:00:00:00:00:00 • Wired Mask: 00:00:00:00:00:00 • Wireless MAC Address: 00:20:A6:12:4E:38 • Wireless Mask: FF:FF:FF:FF:FF:FF Result: The Access Point blocks all traffic between Wireless Client 3 and the Ethernet network. Avaya Wireless AP-3 User’s Guide 4-89...
Page 182: Advanced
• Enable Proxy ARP: Place a check mark in the box provided to allow the Access Point to respond to Address Resolution Protocol (ARP) requests for wireless clients. When enabled, the AP answers ARP requests for wireless stations without actually forwarding them to 4-90 Avaya Wireless AP-3 User’s Guide...
Page 183 • Deny IP Multicasts The AP can filter these protocols in the wireless-to-Ethernet direction, the Ethernet-to-wireless direction, or in both directions. Click Edit and use the Status field to Enable or Disable the filter. Avaya Wireless AP-3 User’s Guide 4-91...
Page 184: Tcp/Udp Port
1. Place a check mark in the box labeled Enable TCP/UDP Port Filtering. 2. Click Add under the TCP/UDP Port Filter Table heading. 3. In the TCP/UDP Port Filter Table, enter the Protocol Names to filter. 4-92 Avaya Wireless AP-3 User’s Guide...
Page 185 2. Make any changes to the Protocol Name or Port Number for a specific entry, if necessary. 3. In the row that defines the port, set the Status to Enable, Disable, or Delete, as appropriate. 4. Select OK Avaya Wireless AP-3 User’s Guide 4-93...
Page 186: Alarms
Remove the check mark from the box to disable the alarms. Alarm Severity Levels vary. • Configuration Alarm Trap Name Description oriTrapDNSIPNotConfigured This traps is generated when the DNS IP Address has not been configured. Severity Level: Major 4-94 Avaya Wireless AP-3 User’s Guide...
Page 187 - MAC Access Control Table - RADIUS MAC Authentication - 802.1x Authentication specifying the EAP-Type Severity Level: Major This trap is generated when an oriTrapUnauthorizedManager Detected unauthorized manager has attempted to view and/or modify parameters. Severity Level: Major Avaya Wireless AP-3 User’s Guide 4-95...
Page 188 Severity Level: Critical oriTrapWLCIncompatibleFir This trap is generated when the mware firmware of the wireless interface/card is incompatible with the AP. Severity Level: Critical 1 of 2 4-96 Avaya Wireless AP-3 User’s Guide...
Page 189 AP. Severity Level: Critical oriTrapWLCFirmwareDownlo This trap is generated when a failure adFailure occurs during the firmware download process of the wireless interface/card. Severity Level: Critical 2 of 2 Avaya Wireless AP-3 User’s Guide 4-97...
Page 190 This trap is generated when a certain software or hardware module is not initialized or fails to initialize. Trap Severity Level: Major oriTrapDeviceRebooting This trap is generated when the AP is rebooting. Trap Severity Level: Informational 1 of 2 4-98 Avaya Wireless AP-3 User’s Guide...
Page 191 DHCP server. The result is that the Access Point reverts to its static IP configuration and you will need to set reset configuration options. Trap Severity Level: Major 2 of 2 Avaya Wireless AP-3 User’s Guide 4-99...
Page 192 Severity Level: Informational This trap is generated when an error oriTrapFlashMemoryCorrupt occurs while downloading a file to the AP and the data in the flash memory is invalid or corrupted. Severity Level: Critical 4-100 Avaya Wireless AP-3 User’s Guide...
Page 193 (upload or download). Severity Level: Informational • Image Alarms Trap Name Description oriTrapZeroSizeImage This trap is generated when a zero size image is loaded on the AP. Trap Severity Level: Major 1 of 2 Avaya Wireless AP-3 User’s Guide 4-101...
Page 194 AP exceeds the size limitation of the flash memory. Trap Severity Level: Major oriTrapIncompatibleImage This trap is generated when an incompatible image is loaded in the Trap Severity Level: Major 2 of 2 4-102 Avaya Wireless AP-3 User’s Guide...
Page 195 The AP has been turned on or rebooted. Trap Severity Level: Informational linkUp The AP's Ethernet interface link is up (working). Trap Severity Level: Informational linkDown The AP's Ethernet interface link is down (not working). Trap Severity Level: Informational Avaya Wireless AP-3 User’s Guide 4-103...
Page 196 AP to the SNMP managers specified in the Alarm Host Table. Severity Levels There are three severity levels for system alarms: • Critical • Major • Informational 4-104 Avaya Wireless AP-3 User’s Guide...
Page 197 • Comment: Enter an optional comment, such as the alarm (trap) host station name. To edit or delete an entry, click Edit. Edit the information, or select Enable, Disable, or Delete from the Status drop-down menu. Avaya Wireless AP-3 User’s Guide 4-105...
Page 198: Syslog
Syslog server). The access point logs “Session Start (Log-in)” and “Session Stop (Log-out)” events for each wireless client as an alternative to RADIUS accounting. See RFC 3164 at http://www.rfc-editor.org for more information on the Syslog standard. 4-106 Avaya Wireless AP-3 User’s Guide...
Page 199 Syslog Events are logged according to the level of detail specified by the administrator. Logging only urgent system messages will create a far smaller, more easily read log then a log of every event the system Avaya Wireless AP-3 User’s Guide 4-107...
Page 200 • Syslog Port Number: This field is read-only and displays the port number (514) assigned for system logging. • Syslog Lowest Priority Logged: The AP will send event messages to the Syslog server that correspond to the selected priority and 4-108 Avaya Wireless AP-3 User’s Guide...
Page 201: Bridge
• Spanning Tree protocol used for loop avoidance Once the AP is connected to your network, it learns which devices are connected to it and records their MAC addresses in the Learn Table. The Avaya Wireless AP-3 User’s Guide 4-109...
Page 202: Spanning Tree
For more information on Spanning Tree protocol, please see Section 8.0 of the IEEE 802.1d standard. The Spanning Tree configuration options are advanced settings. Avaya recommends that you leave these 4-110 Avaya Wireless AP-3 User’s Guide...
Page 203: Storm Threshold
• Address Threshold: Enter the maximum allowed number of packets per second. • Ethernet Threshold: Enter the maximum allowed number of packets per second. • Wireless Threshold: Enter the maximum allowed number of packets per second. Avaya Wireless AP-3 User’s Guide 4-111...
Page 204: Intra Bss
This filters wireless traffic without burdening the AP and provides additional security by limiting potential destinations or by routing the traffic directly to a firewall. You can redirect to a specific port (Ethernet 4-112 Avaya Wireless AP-3 User’s Guide...
Page 205 — Ethernet — A WDS connection (see Wireless Distribution System (WDS) for details) — Any (traffic is redirected to a port based on the bridge learning process) 4. Click OK to save your changes. Avaya Wireless AP-3 User’s Guide 4-113...
Page 206: Security
WEP Encryption The original encryption technique specified by the IEEE 802.11 standard. 802.1x An IEEE standard for client authentication. Authentication Wi-Fi Protected A new standard that provides improved Access (WPA) encryption security over WEP. 4-114 Avaya Wireless AP-3 User’s Guide...
Page 207 — For 64-bit encryption, an encryption key is 10 hexadecimal characters (0-9 and A-F) or 5 ASCII characters (see ASCII Character Chart). — For 128-bit encryption, an encryption key is 26 hexadecimal characters or 13 ASCII characters. Avaya Wireless AP-3 User’s Guide 4-115...
Page 208 Extensible Authentication Protocol (EAP) as a standards-based authentication framework, and supports automatic key distribution for enhanced security. The EAP-based authentication framework can easily be upgraded to keep pace with future EAP types. 4-116 Avaya Wireless AP-3 User’s Guide...
Page 209 Refer to the documentation that came with your RADIUS server to determine which EAP types it supports. NOTE: The AP supports the following EAP types when Authentication Mode is set to 802.1x or WPA: EAP-TLS, PEAP, and EAP-TTLS. Avaya Wireless AP-3 User’s Guide 4-117...
Page 210 When Authentication Mode is set to Mixed, the AP supports the following EAP types: EAP-TLS, PEAP, EAP-TLLS, and EAP-MD5 (MD5 does not support automatic key distribution; therefore, if you choose this method you need to manually configure each client with the network's encryption key). 4-118 Avaya Wireless AP-3 User’s Guide...
Page 211 The AP inhibits all data traffic from a particular client PC until the client PC is authenticated. Regardless of its authentication status, a client PC can always exchange 802.1x messages in the clear with the AP (the client begins encrypting data after it has been authenticated). Avaya Wireless AP-3 User’s Guide 4-119...
Page 212 After the client has been successfully authenticated, the client receives an Encryption Key from the AP (if the EAP type supports automatic key distribution). The client uses this key to encrypt data after it has been authenticated. 4-120 Avaya Wireless AP-3 User’s Guide...
Page 213 WPA provides the following new security measures not available with WEP: • Improved packet encryption using the Temporal Key Integrity Protocol (TKIP) and the Michael Message Integrity Check (MIC). Avaya Wireless AP-3 User’s Guide 4-121...
Page 214 — The AP securely delivers the appropriate keys to its clients • Client/server mutual authentication — 802.1x — Pre-shared key (for networks that do not have an 802.1x solution implemented) NOTE: For more information on WPA, see the Wi-Fi Alliance Web site at http://www.wi-fi.org. 4-122 Avaya Wireless AP-3 User’s Guide...
Page 215 Security modes: Security Mode Description No Security This is the default setting for an AP. Enable WEP The AP and clients use the same static Encryption WEP keys to encrypt data. 1 of 3 Avaya Wireless AP-3 User’s Guide 4-123...
Page 216 The AP uses 802.1x Mode for clients that (802.1x and WEP support 802.1x (and have an 802.1x Encryption) supplicant application installed). The AP uses static WEP Encryption for clients that do not use 802.1x. 2 of 3 4-124 Avaya Wireless AP-3 User’s Guide...
Page 217 You configure an SSID/VLAN to use a particular Security mode by setting the Security Mode parameter in the SSID, VLAN, and Security table (refer to Configure Multiple SSID/VLAN/Security Mode Entries). The following table summarizes the Security Mode options available in the HTTP Avaya Wireless AP-3 User’s Guide 4-125...
Page 218 Dynamic TKIP Pre-shared Key Keying NOTE: Before enabling the 802.1x, Mixed, or WPA mode, the 802.1x server should be configured. Set the encryption key in Mixed mode after the authentication is set to Mixed mode. 4-126 Avaya Wireless AP-3 User’s Guide...
Page 219: Authentication Protocol Hierarchy
SSID. NOTE: The ability to configure up to 16 VLAN/SSID pairs and to configure a security mode per SSID is available only for 802.11b/g APs and 802.11a Upgrade Kit APs. Avaya Wireless AP-3 User’s Guide 4-127...
Page 220: Vlan Overview
VLANs now extend as far as the reach of the access point signal. Clients can be segmented into wireless sub-networks via SSID and VLAN 4-128 Avaya Wireless AP-3 User’s Guide...
Page 221 The access points communicate across a VLAN-capable switch that analyzes VLAN-tagged packet headers and directs traffic to the appropriate ports. On the wired network, a RADIUS server authenticates traffic and a DHCP server manages IP addresses for the VLAN(s). Avaya Wireless AP-3 User’s Guide 4-129...
Page 222 1. VLAN-enabled access point 2. VLAN-aware switch (IEEE 802.1Q uplink) 3. AP management via wired host (SNMP, Web interface or CLI) 4. DHCP Server 5. RADIUS Server 6. VLAN 1 7. VLAN 2 4-130 Avaya Wireless AP-3 User’s Guide...
Page 223 SSID, VLAN, and Security Modes Figure 4-17. Components of a typical VLAN Avaya Wireless AP-3 User’s Guide 4-131...
Page 224: Vlan Workgroups And Traffic Management
The AP matches packets transmitted or received to a network name with the associated VLAN. Traffic received by a VLAN is only sent on the wireless interface associated with that same VLAN. This eliminates unnecessary traffic on the wireless LAN, conserving bandwidth and maximizing throughput. 4-132 Avaya Wireless AP-3 User’s Guide...
Page 225: Typical User Vlan Configurations
Workgroups enable clients from different VLANs to access different resources using the same network infrastructure. Clients using the same physical network are limited to those resources available to their workgroup. Avaya Wireless AP-3 User’s Guide 4-133...
Page 226 AP to use multiple SSIDs. 2. VLAN enabled, all VLAN Workgroups use the same VLAN ID Tag 3. VLAN enabled, each VLAN workgroup uses a different VLAN ID 4. VLAN enabled, a mixture of Tagged and Untagged workgroups 4-134 Avaya Wireless AP-3 User’s Guide...
Page 227: Configure Multiple Ssid/Vlan/Security Mode Entries
VLAN support. If VLAN is disabled, all table entries on the SSID/VLAN/Security page will be disabled. 3. Click the tab for Wireless A or Wireless B (if applicable). 4. Place a check in the Enable Security Per SSID check box. Avaya Wireless AP-3 User’s Guide 4-135...
Page 228 The ability to configure up to 16 VLAN/SSID pairs and to configure a security mode per SSID is available only for 802.11b/g APs and 802.11a Upgrade Kit APs. 802.11b APs do not support multiple VLAN/SSID pairs. APs with the 4-136 Avaya Wireless AP-3 User’s Guide...
Page 229 SSID capability. 5. Add one or more new SSID/VLAN/security mode entries. Each wireless interface supports up to 16 entries. Follow these steps: a. Click Add to create a new SSID/VLAN/security mode entry. Avaya Wireless AP-3 User’s Guide 4-137...
Page 230 Figure 4-19. SSID, VLAN, and Security Table - Wireless A - Add Entries b. Enter a Network Name (SSID), between 2 and 31 characters, in the field provided. This parameter is mandatory. c. Enter a VLAN ID in the field provided. This parameter is mandatory. 4-138 Avaya Wireless AP-3 User’s Guide...
Page 231 Enable WPA-PSK Mode NOTE: If you have two or more SSIDs per interface with a security mode of None, be aware that security being applied in the VLAN is not being applied in the wireless network. Avaya Wireless AP-3 User’s Guide 4-139...
Page 232: B Ascii Character Chart
— For 152-bit encryption, an encryption key is 32 hexadecimal characters or 16 ASCII characters. Enable 802.1x Security Follow these steps to enable 802.1x on an SSID/VLAN pair: 1. Set Security Mode to 802.1x. 2. Select an Encryption Key Length. 4-140 Avaya Wireless AP-3 User’s Guide...
Page 233 Rekeying frustrates hacking attempts without taxing system resources. Setting a fairly frequent rekey value (900 seconds=15 minutes) effectively protects against intrusion without disrupting network activities. 3. Place a check mark in the box labeled Enable Encryption (WEP). Avaya Wireless AP-3 User’s Guide 4-141...
Page 234 3. Enter a phrase in the PSK Pass Phrase field. The AP will automatically generate a Pre-Shared Key based on the phrase you enter. You must also configure your clients to use this same key. 4-142 Avaya Wireless AP-3 User’s Guide...
Page 235: Typical Vlan Management Configurations
Configure Multiple SSID/VLAN/Security Mode Entries Enter between 8 and 63 characters. Avaya recommends using a pass phrase of at least 13 characters, including both numbers and upper and lower case letters, to ensure that the generated key cannot be easily deciphered by network infiltrators.
Page 236 VLAN User IDs on the AP, all members of that User VLAN will have management access to the AP. Be careful to restrict VLAN membership to those with legitimate access to the AP. 1. Click Configure > VLAN. 4-144 Avaya Wireless AP-3 User’s Guide...
Page 237: Mac Access
• Operation Type: Choose between Passthru and Block. This determines how the stations identified in the MAC Access Control Table are filtered. — If set to Passthru, only the addresses listed in the Control Table will pass through the bridge. Avaya Wireless AP-3 User’s Guide 4-145...
Page 238 NOTE: For larger networks that include multiple Access Points, you may prefer to maintain this list on a centralized location using the Access Control by Means of RADIUS Authentication. 4-146 Avaya Wireless AP-3 User’s Guide...
Page 239: Rogue Access Point Detection (Rad)
Rogue Access Points by utilizing the coverage of the trusted Access Point deployment. The Rogue AP Scan employs background scanning using low-level 802.11 scanning functions for effective wireless detection of Access Avaya Wireless AP-3 User’s Guide 4-147...
Page 240 (except scan on the working channel) the CTS to self-mechanism is used to set the NAV values of clients to keep them silent during the scanning period. In addition, the scan repetition duration 4-148 Avaya Wireless AP-3 User’s Guide...
Page 241 Trap Host on all these Access Points to the IP address of the management station. The Access Points on detecting a new Access Point sends a RAD Scan Result Trap to the management station. Avaya Wireless AP-3 User’s Guide 4-149...
Page 242 Access Detection enabled and the trap host is configured to be the management station. The Trusted AP on detecting the Rogue AP will send a trap to the management station with the Channel and BSSID of the Rogue Access Point. 4-150 Avaya Wireless AP-3 User’s Guide...
Page 243 15 and 1440 minutes. 5. Select the Scan Interface as Slot A, Slot B, or both. 6. Click OK. The results of the RAD scan be viewed in the Status page in the HTTP interface. Avaya Wireless AP-3 User’s Guide 4-151...
Page 244 Configure Multiple SSID/VLAN/Security Mode Entries Figure 4-22. Rogue Access Point Detection Screen 4-152 Avaya Wireless AP-3 User’s Guide...
Page 245: Radius
You can configure the AP to communicate with up to six different RADIUS servers: • Primary Authentication Server (MAC-based authentication) • Back-up Authentication Server (MAC-based authentication) • Primary Authentication Server (EAP/802.1x authentication) • Back-up Authentication Server (EAP/802.1x authentication) • Primary Accounting Server • Back-up Accounting Server Avaya Wireless AP-3 User’s Guide 4-153...
Page 246: Mac Access Control By Means Of Radius Authentication
MAC Address values that identify the authorized stations that may access the wireless network. You must specify information for at least the primary RADIUS server. The back-up RADIUS server is optional. 4-154 Avaya Wireless AP-3 User’s Guide...
Page 247 (reauthentication is disabled). The configurable range is from 900 seconds to 43200 seconds. NOTE: Authorization Lifetime is used for MAC authenticated clients and 802.1x clients. Setting Authorization Lifetime in the RADIUS Auth tab will also effect EAP/802.1x Authorization clients. Avaya Wireless AP-3 User’s Guide 4-155...
Page 248 9. Enter the Shared Secret in the Shared Secret and Confirm Shared Secret field. This is a password shared by the RADIUS server and the AP. The same password must also be configured on the RADIUS server. 4-156 Avaya Wireless AP-3 User’s Guide...
Page 249 12. If you are configuring a back-up server, repeat Steps 6 through 11 for the back-up server. 13. Click OK to save your changes. 14. Reboot the AP for these changes to take effect. Avaya Wireless AP-3 User’s Guide 4-157...
Page 250 RADIUS Figure 4-23. RADIUS MAC-Based Access Control Screen 4-158 Avaya Wireless AP-3 User’s Guide...
Page 251: Radius Authentication With 802.1X
6. Enter the server’s IP address or name in the field provided. 7. Enter the port number which the AP and the server will use to communicate. By default, RADIUS servers communicate on port 1812. Avaya Wireless AP-3 User’s Guide 4-159...
Page 252 802.1x clients. Setting Authorization Lifetime in the RADIUS Auth tab will also effect EAP/802.1x Authorization clients. 14. Click OK to save your changes. 15. Reboot the AP device for these changes to take effect. 4-160 Avaya Wireless AP-3 User’s Guide...
Page 253: Radius Accounting
Using an external RADIUS server, the AP can track and record the length of client sessions on the access point by sending RADIUS accounting messages per RFC2866. When a wireless client is successfully authenticated, RADIUS accounting is initiated by sending an “Accounting Avaya Wireless AP-3 User’s Guide 4-161...
Page 254 MAC Access Control list are not tracked. Configuring RADIUS Accounting Follow these steps to enable RADIUS accounting on the AP: NOTE: For Radius accounting to work, first Radius authentication needs to be enabled as follows: 4-162 Avaya Wireless AP-3 User’s Guide...
Page 255 — Colon delimited: colon between each pair of digits: xx:yy:zz:aa:bb:cc) — Single dash delimited: dash between the sixth and seventh digits: xxyyzz-aabbcc — No delimiters: No characters or spaces between pairs of hexadecimal digits: xxyyzzaabbcc Avaya Wireless AP-3 User’s Guide 4-163...
Page 256 12. If you are configuring a back-up server, repeat Steps 6 through 11 for the back-up server. 13. Click OK to save your changes. Now that Radius authentication is enabled and configured, configure Radius Accounting as follows: 4-164 Avaya Wireless AP-3 User’s Guide...
Page 257 8. Enter the Shared Secret in the Shared Secret and Confirm Shared Secret field. This is a password shared by the RADIUS server and the AP. The same password must also be configured on the RADIUS server. Avaya Wireless AP-3 User’s Guide 4-165...
Page 258 11. If you are configuring a back-up server, repeat Steps 5 through 10 for the back-up server. 12. Enable Radius accounting and click OK to save your changes. 13. Reboot the AP device for these changes to take effect. 4-166 Avaya Wireless AP-3 User’s Guide...
Page 259 RADIUS Figure 4-25. RADIUS Accounting Server Configuration Avaya Wireless AP-3 User’s Guide 4-167...
Page 260 RADIUS 4-168 Avaya Wireless AP-3 User’s Guide...
Page 261: Monitor Information
RADIUS server(s). • Interfaces: Displays the Access Point’s interface statistics (Wireless and Ethernet). • Link Test Evaluates the link with a wireless client. • Station Statistics: Displays statistics for stations and Wireless Distribution System links. Avaya Wireless AP-3 User’s Guide...
Page 262: Logging Into The Http Interface
— Netscape 6.1 or later 2. If necessary, disable the Internet proxy settings. For Internet Explorer users, follow these steps: — Select Tools > Internet Options..— Click the Connections tab. — Click LAN Settings..Avaya Wireless AP-3 User’s Guide...
Page 263 4. Enter the HTTP password in the Password field and click OK. Leave the User Name field blank. (By default, the HTTP password is “public”). — Result: The System Status screen appears. Figure 5-1. Enter Network Password Screen Avaya Wireless AP-3 User’s Guide...
Page 264 6. Click the tab that corresponds to the statistics you want to review. For example, click Learn Table to see the list of nodes that the AP has discovered on the network. 7. If applicable, click the Refresh button to update the statistics. Avaya Wireless AP-3 User’s Guide...
Page 265: Version
• Version: Specifies the component’s version or build number. The Software Image version is the most useful information on this screen for the typical end user. Avaya Wireless AP-3 User’s Guide...
Page 266 Version Figure 5-3. Version Information Screen Avaya Wireless AP-3 User’s Guide...
Page 267: Icmp
This tab provides statistical information for both received and transmitted messages directed to the AP. Not all ICMP traffic on the network is counted in the ICMP (Internet Control Message Protocol) statistics. Figure 5-4. ICMP Monitoring Screen Avaya Wireless AP-3 User’s Guide...
Page 268: Ip/Arp Table
IP/ARP Table IP/ARP Table This tab provides information based on the Address Resolution Protocol (ARP), which relates MAC Address and IP Addresses. Figure 5-5. IP/ARP Table Avaya Wireless AP-3 User’s Guide...
Page 269: Learn Table
MAC address for each node that the device has learned is on the network and the interface on which the node was detected. There can be up 10,000 entries in the Learn Table. Figure 5-6. Learn Table Avaya Wireless AP-3 User’s Guide...
Page 270: Iapp
IAPP IAPP This tab displays statistics relating to client handovers and communications between Avaya Wireless Access Points. Figure 5-7. IAPP Screen 5-10 Avaya Wireless AP-3 User’s Guide...
Page 271: Radius
RADIUS RADIUS This tab provides RADIUS authentication, EAP/802.1x authentication, and accounting information for both the Primary and Backup RADIUS servers. NOTE: RADIUS authentication and accounting must be enabled for this information to be valid. Avaya Wireless AP-3 User’s Guide 5-11...
Page 272: Interfaces
Interfaces Figure 5-8. RADIUS Monitoring Screen Interfaces This tab displays statistics for the Ethernet and wireless interfaces. The Operational Status can be up, down, or testing. 5-12 Avaya Wireless AP-3 User’s Guide...
Page 273 Interfaces Figure 5-9. Wireless Interface Monitoring Avaya Wireless AP-3 User’s Guide 5-13...
Page 274: Link Test
NOTE: This feature is not available for an 802.11b/g AP. Also, this feature is not available if you are using a non-Avaya Wireless client with an 802.11b AP. Follow these steps to perform a Link Test: 1. Open the Remote Link Test screen.
Page 275 Access Point (referred to as the Initiator Station) and the wireless client (referred to as the Remote Station): — Station Name: The Access Point’s System Name or the client’s Windows Networking name. — MAC Address Avaya Wireless AP-3 User’s Guide 5-15...
Page 276 -95 dBm is more desirable than a noise level of -89 dBm. The bar graph displays the relative strength of the noise level (a shorter bar represents a weaker noise level and is more desirable than a longer bar). 5-16 Avaya Wireless AP-3 User’s Guide...
Page 277 — 1 Mbps (pkts): The number of packets received at the 1 Mbits/sec transmit rate since the start of the Link Test. NOTE: Click the Refresh button periodically to update the test results. The test screen does not refresh automatically. Avaya Wireless AP-3 User’s Guide 5-17...
Page 278 Link Test Figure 5-11. SNR Report Screen 5. Click Close to end the Link Test. 5-18 Avaya Wireless AP-3 User’s Guide...
Page 279: Station Statistics
Click on the Refresh button in the browser window to view the latest statistics. If any new clients associate to the AP, you can see the statistics of the new clients after you click the refresh button. Avaya Wireless AP-3 User’s Guide 5-19...
Page 280 The following stations statistics are displayed: • MAC Address: The MAC address of the wireless client for which the statistics are gathered. For WDS links, this is the partner MAC address of the link. 5-20 Avaya Wireless AP-3 User’s Guide...
Page 281 (or WDS link partner) by the • Non-Unicast Frames Received: The number of Non-Unicast frames received (i.e. broadcast or multicast) from the associated wireless station (or WDS link partner) by the AP. Avaya Wireless AP-3 User’s Guide 5-21...
Page 282 • Octets Transmitted: The number of octets sent to the associated wireless station (or WDS link partner) from the AP. • Unicast Frames Transmitted: The number of Unicast frames transmitted to the associated wireless station (or WDS link partner) from the AP. 5-22 Avaya Wireless AP-3 User’s Guide...
Page 283: Commands
Reboot the AP in the specified number of seconds. • Reset: Reset all of the Access Point’s configuration settings to factory defaults. • Help Link: Configure the location where the AP Help files can be found. Avaya Wireless AP-3 User’s Guide...
Page 284: Logging Into The Http Interface
— Netscape 6.1 or later 2. If necessary, disable the Internet proxy settings. For Internet Explorer users, follow these steps: — Select Tools > Internet Options..— Click the Connections tab. — Click LAN Settings..Avaya Wireless AP-3 User’s Guide...
Page 285 4. Enter the HTTP password in the Password field and click OK. Leave the User Name field blank. (By default, the HTTP password is “public”). — Result: The System Status screen appears. Figure 6-1. Enter Network Password Screen Avaya Wireless AP-3 User’s Guide...
Page 286 5. Click the Commands button located on the left-hand side of the screen. Figure 6-2. Commands Main Screen 6. Click the tab that corresponds to the command you want to issue. For example, click Reboot to restart the unit. Avaya Wireless AP-3 User’s Guide...
Page 287: Introduction To File Transfer By Tftp Or Http
A TFTP server must be running and configured to point to the directory containing the file. If you do not have a TFTP server installed on your system, install the TFTP server from the Avaya Wireless CD. Avaya Wireless AP-3 User’s Guide...
Page 288: Http File Transfer Guidelines
• Large image size • Non VxWorks image • AP image • Digital signature verification If any of the above checks fail on the downloaded image, the Access Point deletes the downloaded image and retains the old image. Avaya Wireless AP-3 User’s Guide...
Page 289: Update Ap By Using Tftp
If you do not have a TFTP server installed on your system, install the TFTP server from the Avaya Wireless CD. You can either install the TFTP server from the CD Wizard or run OEM-TFTP-Server.exe found in the CD’s Xtras/SolarWinds sub-directory.
Page 290 This is the IP address that will be used to point the Access Point to the AP Image file. 3. In the File Name field, enter the name of the file to be downloaded (including the file extension). Avaya Wireless AP-3 User’s Guide...
Page 291: Update Ap By Using Http
Bootloader files, and Certificate and Private Key files to the AP. 1. Once on the Update AP screen, click on the via HTTP tab. The Update AP via HTTP tab shows version information and allows you to enter HTTP information as described below. Avaya Wireless AP-3 User’s Guide...
Page 292 — Image for the AP Image (executable program). — Bsp/Bl for the Bootloader software. — Certificate: the digital certificate for authentication in SSL communications. — Private Key: the private key for encryption in SSL communications. 6-10 Avaya Wireless AP-3 User’s Guide...
Page 293 5. Click OK to continue with the operation or Cancel to abort the operation. NOTE: An HTTP file transfer using SSL may take extra time. If the operation completes successfully the following screen appears. Avaya Wireless AP-3 User’s Guide 6-11...
Page 294 Update AP by Using HTTP Figure 6-6. Update AP Successful If the operation did not complete successfully the following screen appears, and the reason for the failure is displayed. Figure 6-7. Update AP Unsuccessful 6-12 Avaya Wireless AP-3 User’s Guide...
Page 295: Upload Files By Using Tftp
If you do not have a TFTP server installed on your system, install the TFTP server from the Avaya Wireless CD. You can either install the TFTP server from the CD Wizard or run OEM-TFTP-Server.exe found in the CD’s Xtras/SolarWinds sub-directory.
Page 296 4. Click the Retrieve Config File button to initiate the upload of the Configuration file from the AP to the TFTP server. NOTE: For information on how to download the file from the TFTP server to the AP, see Update AP by Using TFTP. 6-14 Avaya Wireless AP-3 User’s Guide...
Page 297: Upload Files By Using Http
Figure 6-9. Retrieve File via HTTP Command Screen 2. Click on the Retrieve Config File button to initiate this operation. The AP displays a confirmation message that asks if you want to proceed with retrieving the configuration file. Avaya Wireless AP-3 User’s Guide 6-15...
Page 298 Upload Files by Using HTTP Figure 6-10. Retrieve File Confirmation Dialog 3. Click OK to continue with the operation or Cancel to abort the operation. The File Download dialog box is displayed. 6-16 Avaya Wireless AP-3 User’s Guide...
Page 299 Figure 6-11. File Download Dialog Box 4. On clicking the Save button the following Save As window displays, where you are prompted to choose the filename and location where the Configuration file is to be downloaded. Avaya Wireless AP-3 User’s Guide 6-17...
Page 300: Reboot
Use the Reboot tab to save configuration changes (if any) and reset the AP. Entering a value of 0 (zero) seconds causes an immediate reboot. Note that Reset, described below, does not save configuration changes. 6-18 Avaya Wireless AP-3 User’s Guide...
Page 301 Rebooting the AP will cause all users who are currently connected to lose their connection to the network until the AP has completed the restart pro- cess and resumed operation. Figure 6-13. Reboot Command Screen Avaya Wireless AP-3 User’s Guide 6-19...
Page 302: Reset
Resetting the AP to its factory default configuration will permanently over- write all changes that have made to the unit. The AP will reboot automati- cally after this command has been issued. Figure 6-14. Reset to Factory Defaults Command Screen 6-20 Avaya Wireless AP-3 User’s Guide...
Page 303: Help Link
Add the AP’s management IP address to the Internet Explorer list of Trusted Sites. The Avaya Wireless AP Help information is available in English, French, German, Italian, Spanish, and Japanese. The Help files are copied to your computer in one language only.
Page 304 Help Link Figure 6-15. Help Link Configuration Screen 6-22 Avaya Wireless AP-3 User’s Guide...
Page 305: Troubleshooting
The most common initialization and installation problems relate to IP addressing. For example, you must have valid IP addresses for both the AP and the management computer to access the unit’s HTTP interface. • IP Address management is fundamental. Avaya Wireless AP-3 User’s Guide...
Page 306 • The AP Supports a Command Line Interface (CLI). If you are having trouble locating your AP on the network, connect to the unit directly using the serial interface and refer to The Command Line Interface for CLI command syntax and parameter names. Avaya Wireless AP-3 User’s Guide...
Page 307: Connectivity Issues
3. If you are using Active Ethernet, make sure you are using a Category 5, foiled, twisted pair cable to power the AP. Serial Link Does Not Work 1. Make sure you are using a standard, straight-through, 9-pin serial cable. 2. Double-check the physical network connections. Avaya Wireless AP-3 User’s Guide...
Page 308 (see Ethernet). If you cannot access the unit over Ethernet, then use the CLI interface over the serial port to configure the Ethernet port (see The Command Line Interface Ethernet Interface Commands). 3. Perform network infrastructure troubleshooting (check switches, routers, etc.). Avaya Wireless AP-3 User’s Guide...
Page 309: Basic Software Setup And Configuration Problems
1. Client computers should have the same Network Name and security settings as the AP. 2. Network Names should be allocated and maintained by the Network Administrator. 3. Refer to the documentation that came with your client card for additional troubleshooting suggestions. Avaya Wireless AP-3 User’s Guide...
Page 310 5. If you use static IP Address assignments, and cannot access the unit over Ethernet, use the Initializing the IP Address using CLI procedure. Once the IP Address is set, you can use the Ethernet Interface to complete configuration. Avaya Wireless AP-3 User’s Guide...
Page 311 User Name field empty and enter the HTTP password in the Password field. The default HTTP password is “public”. 3. Use the CLI over the serial port to check the IP Access Table, which can be restricting access to Telnet and HTTP. Avaya Wireless AP-3 User’s Guide...
Page 312 2. Confirm that your computer has an IP address in the same IP subnet as your Access Point. 3. Use the CLI over the serial port to check the IP Access Table, which can be restricting access to Telnet and HTTP. Avaya Wireless AP-3 User’s Guide...
Page 313 (including the file extension) and directory path. 5. If you have a problem uploading a file, verify that the TFTP server is configured to allow uploads (typically the default setting is to allow only downloads). Avaya Wireless AP-3 User’s Guide...
Page 314: Client Connection Problems
Client PC Card Does Not Work 1. Make sure you are using the latest PC Card driver software. 2. Download and install the latest Avaya Wireless client software from http://www.avaya.com/support. 7-10 Avaya Wireless AP-3 User’s Guide...
Page 315 Internet, there may be a physical network configuration problem (contact your network support staff). 4. If using Active Ethernet, make sure you are not using a crossover Ethernet cable between the AP and the hub. Avaya Wireless AP-3 User’s Guide 7-11...
Page 316: Vlan Operation Issues
Most problems can be avoided by ensuring that 802.1Q compliant VLAN tags containing the proper VLAN ID have been inserted in the bridged frames. The VLAN ID in the header should correspond to the user’s assigned network name. 7-12 Avaya Wireless AP-3 User’s Guide...
Page 317: Active Ethernet (Ae)
2. Try a different port on the same AE hub (remember to move the input port accordingly) – if it works, there is probably a faulty port or bad RJ-45 port connection. 3. If possible, try to connect the AP to a different AE hub. Avaya Wireless AP-3 User’s Guide 7-13...
Page 318 5. Try to re-connect the AP to a different output port (remember to move the input port accordingly) – if it works, there is probably a faulty output or input port in the AE hub or a bad RJ-45 connection. 7-14 Avaya Wireless AP-3 User’s Guide...
Page 319: Recovery Procedures
AP Image. If the AP has a corrupted software image, follow the Forced Reload Procedure to erase the current AP Image and download a new image. Avaya Wireless AP-3 User’s Guide 7-15...
Page 320: Reset To Factory Default Procedure
2. If not using DHCP, use the ScanTool or CLI over a serial connection to set the IP address, subnet mask, and other IP parameters. See The Command Line Interface for CLI information. 7-16 Avaya Wireless AP-3 User’s Guide...
Page 321: Forced Reload Procedure
Use this procedure to erase the current AP Image and download a new AP Image. In some cases, specifically when a missing or corrupted AP Image prevents successful booting, you may need to use ScanTool or the Bootloader CLI to download a new executable AP Image. Avaya Wireless AP-3 User’s Guide 7-17...
Page 322 Ethernet connection, a TFTP server, and a serial cable (if using the Bootloader CLI) to reload firmware. 2. Press and hold the RELOAD button for about 20 seconds until the POWER LED turns amber. Result: The AP deletes the current AP Image. 7-18 Avaya Wireless AP-3 User’s Guide...
Page 323 Before starting, you need to know the Access Point’s IP address, subnet mask, the TFTP Server IP Address, and the AP Image file name. Make sure the TFTP server is running and configured to point to the folder containing the image to be downloaded. Avaya Wireless AP-3 User’s Guide 7-19...
Page 324 Download Procedure Follow these steps to use ScanTool to download a software image to an Access Point with a missing image: 1. Download the latest software from http://www.avaya.com/support. 2. Copy the latest software updates to your TFTP server. 3. Launch ScanTool.
Page 325 You must also connect the AP to a computer with a standard serial cable and use a terminal client, such as HyperTerminal. From the terminal, enter CLI Commands to set the IP address and download an AP Image. Avaya Wireless AP-3 User’s Guide 7-21...
Page 326 TFTP server is running and configured to point to the folder containing the image to be downloaded. Download Procedure 1. Download the latest software from http://www.avaya.com/support. 2. Copy the latest software updates to your TFTP server’s default directory.
Page 327 Result: The terminal display shows Power On Self Tests (POST) activity. After approximately 30 seconds, a message indicates: Sending Traps to SNMP manager periodically. After this message appears, press the ENTER key repeatedly until the following prompt appears: [Device name]> Avaya Wireless AP-3 User’s Guide 7-23...
Page 328 Result: The AP will reboot and then download the image file. You should see downloading activity begin after a few seconds within the TFTP server’s status screen. 8. When the download process is complete, configure the AP as described in Getting Started Advanced Configuration. 7-24 Avaya Wireless AP-3 User’s Guide...
Page 329: Setting Ip Address Using Serial Port
2. Remove the front cover from the AP to reveal the serial port. 3. Connect one end of the serial cable to the AP and the other end to a serial port on your computer. 4. Power on the computer and AP, if necessary. Avaya Wireless AP-3 User’s Guide 7-25...
Page 330 In addition, many web sites offer shareware or commercial terminal programs you can download. Once the IP address has been assigned, you can use the HTTP interface or the CLI over Telnet to complete configuration. 7-26 Avaya Wireless AP-3 User’s Guide...
Page 331 This process may take up to 90 seconds. Please enter password: [Device name]> 4. Enter the CLI password (default is public). Result: The terminal displays a welcome message and then the CLI Prompt: > [Device name] Avaya Wireless AP-3 User’s Guide 7-27...
Page 332 [Device name]> set ipaddr <IP Address> [Device name]> set ipsubmask <IP Subnet Mask> [Device name]> set ipgw <Default Gateway IP Address> [Device name]> (to confirm your new settings) show ip [Device name]> reboot 0 7-28 Avaya Wireless AP-3 User’s Guide...
Page 333: Related Applications
AP. Check the RADIUS Authentication Server’s Shared Secret and Destination Port number (default is 1812; for RADIUS Accounting, the default is 1813). • Make sure the RADIUS authentication server RAS setup matches the AP. Avaya Wireless AP-3 User’s Guide 7-29...
Page 334: Tftp Server
You can upload configuration files from the AP for backup or copying, and you can download configuration files or new software images. The TFTP software is located on the Avaya Wireless AP Installation CD-ROM. If a TFTP server is not configured and running, you will not be able to download and upload images and configuration files to/from the AP.
Page 335: A The Command Line Interface
CLI scripts. After entering commands, press the Enter key to execute the command. The CLI is available through both the Serial Port interface and over the Ethernet interface using Telnet. NOTE: All CLI commands and parameters are case-sensitive. Avaya Wireless AP-3 User’s Guide...
Page 336 IAPP Commands • System Information Commands • Intra BSS Commands • Telnet Commands • Inventory Management Commands • TFTP Commands • IP Access Table Commands • WDS Commands • IP Commands • 802.11a Wireless Interface Commands Avaya Wireless AP-3 User’s Guide...
Page 337: General Notes
• Information that you input as shown is displayed in bold constant width type. For example: [Device Name]> set ipaddr 10.0.0.12 • The names of keyboard keys, software buttons, and field names are displayed in bold type. For example: Click the Configure button. Avaya Wireless AP-3 User’s Guide...
Page 338: Important Terminology
For example, the System Group is composed of several related parameters. Groups can also All items for a given Group can be contain Tables. displayed with a show <Group> CLI Command. 1 of 2 Avaya Wireless AP-3 User’s Guide...
Page 339 SNMP Table. All items for a given Table can be displayed with a show <Table> CLI Command. TFTP Refers to the TFTP Server, used for file transfers. 2 of 2 Avaya Wireless AP-3 User’s Guide...
Page 340: Navigation And Special Keys
Ctrl-U Delete all text to left of cursor Ctrl-P Go to the previous line in the history buffer Ctrl-N Go to the next line in the history buffer Complete the command line List available commands Avaya Wireless AP-3 User’s Guide...
Page 341: Cli Error Messages
Parameter at the command prompt. Invalid Table An invalid table parameter value has been Parameter Value entered at the command prompt. Read Only Parameter User is attempting to configure a read-only parameter. 1 of 2 Avaya Wireless AP-3 User’s Guide...
Page 342: Bootloader Cli
Access Point uses the normal CLI. This guide covers the normal CLI unless otherwise specified. The Bootloader CLI is accessible via the serial interface only if the AP does not contain a software image or a download image command over TFTP has failed. Avaya Wireless AP-3 User’s Guide...
Page 343: Avaya Wireless Ap-3 User's Guide
The parameters supported by the Bootloader CLI (for viewing and modifying) are: • System Name • IP Address Assignment Type • IP Address • IP Mask • Gateway IP Address • TFTP Server IP Address • Image File Name (including the file extension) Avaya Wireless AP-3 User’s Guide...
Page 344 Bootloader CLI The following lists display the results of using the help command in the Bootloader CLI: Figure A-1. Results of “help” bootloader CLI command A-10 Avaya Wireless AP-3 User’s Guide...
Page 345: Cli Conventions
This section contains the following topics: • Command Conventions • Entering Text Strings Command Conventions Each table element (or parameter) must be specified, as in the example below. [Device-Name]> set mgmtipaccesstbl 0 ipaddr 10.0.0.10 ipmask 255.255.0.0 Avaya Wireless AP-3 User’s Guide A-11...
Page 346 — If multiple table objects are to be modified the order in which they are entered is not important. — If the entire table entry is to be modified, all the table objects have to be specified. A-12 Avaya Wireless AP-3 User’s Guide...
Page 347 For example: — Does not need quote marks [Device-Name]> set sysname Lobby — Requires quote marks. [Device-Name]> set sysname “Front Lobby” Avaya Wireless AP-3 User’s Guide A-13...
Page 348: Cli Help
CLI Help This section contains the following topics: • The Question Mark • The Help Command The Question Mark This command can be used in a number of ways to display available commands and parameters. A-14 Avaya Wireless AP-3 User’s Guide...
Page 349 Prompt to enter successive parameters [Device-Name]> download for commands (see Example 4. Displaying prompts for successive parameters) Example 1. Displaying the command list To display the command list, enter ?. [Device-Name]> ? Avaya Wireless AP-3 User’s Guide A-15...
Page 350 Example 3a allows you to see every possible parameter for the set (or show) commands. Notice from example 3a that the list is very long. Example 3b shows how to display a subset of the parameters based on initial parameter letters. A-16 Avaya Wireless AP-3 User’s Guide...
Page 351 CLI Help Example 3a. Displaying every parameter that can be changed [Device-Name]> set ? Figure A-5. Result of “set ?” CLI command Avaya Wireless AP-3 User’s Guide A-17...
Page 352 Result: The parameter is changed and a new CLI line is echoed with the new value (in the first part of the following example, the value is the IP Address of the TFTP server). A-18 Avaya Wireless AP-3 User’s Guide...
Page 353: The Help Command
[Device-Name]> download 192.168.0.101 apimage img <CR> The Help Command command displays instructions on using control-key sequences help for navigating a command line and displays command information and examples. • Using help as the only argument: [Device-Name]> help Avaya Wireless AP-3 User’s Guide A-19...
Page 354 CLI Help Figure A-8. Results of “help” CLI command • Complete command description and command usage can be provided by: [Device-Name]> help <command name> [Device-Name]> <command name> help A-20 Avaya Wireless AP-3 User’s Guide...
Page 355: Accessing The Ap Cli
— Com Port: <COM1, COM2, etc., depending on your computer> — Baud rate: 9600 — Data Bits: 8 — Stop bits: 1 — Flow Control: None — Parity: None Avaya Wireless AP-3 User’s Guide A-21...
Page 356: Using Telnet To Log In To The Ap
Result: HyperTerminal sends a line return at the end of each line of code. 3. Enter the CLI password (default is public). NOTE: Avaya recommends changing all default passwords immediately. See the following sections for information on how to change the default passwords: — CLI password, see passwd.
Page 357 3. Type telnet <IP Address of the unit>. 4. Enter the CLI password (default is public). NOTE: Avaya recommends changing all default passwords immediately. See the following sections for information on how to change the default passwords: — CLI password, see passwd.
Page 358: Cli Commands
• show: Displays the value of the specified parameter, or displays all parameter values of a specified group (parameter table). • upload: Uses TFTP server to upload configuration files from Access Point to TFTP default directory or specified path A-24 Avaya Wireless AP-3 User’s Guide...
Page 359: Done
TFTP parameters. Executing download without parameters will display command help and usage information. Syntax: Action Syntax Downloads a file [Device-Name]> download <tftp server address> <path and filename> <file type> 1 of 2 Avaya Wireless AP-3 User’s Guide A-25...
Page 360: Help
[Device-Name]> download 192.168.1.100 APImage2 img exit Ends a CLI session: [Device-Name]> exit done quit commands perform the same action. help Displays instructions on using control-key sequences for navigating a command line and displays command information and examples. A-26 Avaya Wireless AP-3 User’s Guide...
Page 361 CLI Commands Syntax: Action Syntax Use help as the only argument. [Device-Name]> help See the following example. Display complete command [Device-Name]> help <command name> description and command usage [Device-Name]> <command name> help Avaya Wireless AP-3 User’s Guide A-27...
Page 362 CLI Commands Example: Figure A-9. Results of “help” CLI command A-28 Avaya Wireless AP-3 User’s Guide...
Page 363: History
Changes the CLI Password. [Device-Name]> passwd <oldpassword> <newpassword> <newpassword> CAUTION: Avaya strongly urges you to change the default passwords to restrict access to your network devices to authorized personnel. If you lose or for- get your password settings, you can always perform the...
Page 364: Quit
[Device-Name]> quit done exit commands perform the same action. reboot Reboots the Access Point after specified number of seconds. Specify a value of 0 (zero) for immediate reboot. [Device-Name]> reboot 0 [Device-Name]> reboot 30 A-30 Avaya Wireless AP-3 User’s Guide...
Page 365: Search
HTTP interface. In the following example, the CLI returns the list of parameters that make up an entry in the IP Access Table. Example: [Device-Name]> search mgmtipaccesstbl Figure A-10. Results of “search mgmtipaccesstbl” CLI command Avaya Wireless AP-3 User’s Guide A-31...
Page 366: Set
To inform you of this behavior, the CLI provides informational messages when you have configured an object that requires a reboot. The following messages are displayed as a result of the configuring such object or objects. A-32 Avaya Wireless AP-3 User’s Guide...
Page 367 Modifications have been made to parameters that require the device to be rebooted. These changes will only take effect after the next reboot. Examples [Device-Name]> set sysloc “Main Lobby” [Device-Name]> set mgmtipaccesstbl 0 ipaddr 10.0.0.10 ipmask 255.255.0.0 Avaya Wireless AP-3 User’s Guide A-33...
Page 368 <element 1> <value 1> … <element n> <value n> Example: [Device-Name]> set mgmtipaccesstbl 0 ipaddr 10.0.0.10 ipmask 255.255.0.0 Result: A new table entry is created for IP address 10.0.0.10 with a 255.255.0.0 subnet mask. A-34 Avaya Wireless AP-3 User’s Guide...
Page 369 [Device-Name]> set <Table> index status <1=enable, 2=disable, 3=delete> Example: [Device-Name]> set mgmtipaccesstbl 2 status enable [Device-Name]> set mgmtipaccesstbl 2 status disable [Device-Name]> set mgmtipaccesstbl 2 status delete [Device-Name]> set mgmtipaccesstbl 2 status 2 Avaya Wireless AP-3 User’s Guide A-35...
Page 370: Show
Enter key. To see a list of available parameters, enter a question mark (?) after show (example: show ?). Syntax [Device-Name]> show <parameter> [Device-Name]> show <group> [Device-Name]> show <table> Examples [Device-Name]> show ipaddr [Device-Name]> show network [Device-Name]> show mgmtipaccesstbl A-36 Avaya Wireless AP-3 User’s Guide...
Page 371 [Device-Name]> show <group name> Example: [Device-Name]> show network Result: The CLI displays network group parameters. Note return the same data. show network show ip Figure A-11. Results of “show network” and “show ip” CLI Commands Avaya Wireless AP-3 User’s Guide A-37...
Page 372 Displays the Access Point IP address. Figure A-12. Result of “show ipaddr” CLI Command To view all parameters in a table: Syntax: [Device-Name]> show <table name> Example: [Device-Name]> show mgmtipaccesstbl Result: Displays the IP Access Table and its entries. A-38 Avaya Wireless AP-3 User’s Guide...
Page 373: Upload
[Device-Name]> upload <tftp server address> <path and filename> <filetype> Display help and usage [Device-Name]> help upload information: Execute the upload command [Device-Name]> upload * using previously set (stored) TFTP Parameters: Example: [Device-Name]> upload 192.168.1.100 APconfig.sys config Avaya Wireless AP-3 User’s Guide A-39...
Page 374: Parameter Tables
(can be “set”), W = Write Only • CLI Parameter - Parameter name as used in the Access Point Access Point network objects are associated with Groups. The network objects and their associated parameters are described in the following sections. A-40 Avaya Wireless AP-3 User’s Guide...
Page 375: Auto Configuration Commands
AP is configured for Static IP. If the AP is configured for Dynamic IP these parameters are not used and obtained from DHCP. The default filename is “config”. The default TFTP IP address is 10.0.0.2 for the AP. Avaya Wireless AP-3 User’s Guide A-41...
Page 376: Auto Configuration Parameters
Enter the filename of the configuration file that is used if the AP is configured for Static IP. [Device-Name]> set autoconfigTFTPaddr <IP address> Enter the TFTP server address that is used if the AP is configured for Static IP. A-42 Avaya Wireless AP-3 User’s Guide...
Page 377: Dhcp Server Commands
(2) delete (3) Gateway IP IpAddress User Defined dhcpgw Address Primary DNS IP IpAddress User Defined dhcppridnsipaddr Address Secondary DNS IpAddress User Defined dhcpsecdnsipaddr IP Address Number of IP Pool Integer32 dhcpippooltblent Table Entries Avaya Wireless AP-3 User’s Guide A-43...
Page 378: Ip Address Pool Parameters
Default Lease Time Integer32 3600– defleasetm (optional) 86400 sec (default) Maximum Lease Integer32 3600– maxleasetm Time (optional) 86400 sec (default) Comment (optional) DisplayString User Defined Status (optional) Integer enable (1) status disable (2) delete (3) A-44 Avaya Wireless AP-3 User’s Guide...
Page 379: Syntax Examples
[Device-Name]> set dhcpippooltbl 0 startipaddr <start ip address> endipaddr <end ip address> [Device-Name]> set dhcpgw <gateway ip address> [Device-Name]> set dhcppridnsipaddr <primary dns ip address> [Device-Name]> set dhcpsecdnsipaddr <secondary dns ip address> [Device-Name]> set dhcpstatus enable [Device-Name]> reboot 0 Avaya Wireless AP-3 User’s Guide A-45...
Page 380: Dns Client Commands
Name 254 characters) Syntax Examples [Device-Name]> set dnsstatus enable [Device-Name]> set dnsprisvripaddr <IP address of primary DNS server> [Device-Name]> set dnssecsvripaddr <IP address of secondary DNS server> [Device-Name]> set dnsdomainname <default domain name> A-46 Avaya Wireless AP-3 User’s Guide...
Page 381 DNS Client Commands [Device-Name]> show dns Figure A-13. Results of “show dns” CLI command Avaya Wireless AP-3 User’s Guide A-47...
Page 382: Ethernet Interface Commands
Access CLI Parameter Ethernet Interface Group ethernet Speed Integer 10halfduplex etherspeed 10fullduplex 10autoduplex 100halfduplex 100fullduplex autohalfduplex autoautoduplex (default) MAC Address PhyAddress ethermacaddr Syntax Examples [Device-Name]> set etherspeed <value (see Table A-1) [Device-Name]> reboot 0 A-48 Avaya Wireless AP-3 User’s Guide...
Page 383 10 Mbits/sec - full duplex 10fullduplex 10 Mbits/sec - auto duplex 10autoduplex 100 Mbits/sec - half duplex 100halfduplex 100 Mbits/sec - full duplex 100fullduplex Auto Speed - half duplex autohalfduplex Auto Speed - auto duplex autoautoduplex (default) Avaya Wireless AP-3 User’s Guide A-49...
Page 384: Filtering Commands
1 or 3 - Ethernet 4 or 6 - Wireless A 8 or 10 - Wireless B 12 = Wireless A & B 13 or 15 - all interfaces (default is Operation Type passthru etherfltoptype block A-50 Avaya Wireless AP-3 User’s Guide...
Page 385: Ethernet Protocol Filtering Table Parameters
The filter Operation Type (passthru or block) applies only to the protocol filters that are enabled in this table. NOTE: The AP requires a reboot for changes to the Ethernet Protocol Filtering Table to take effect. Avaya Wireless AP-3 User’s Guide A-51...
Page 386: Static Mac Address Filter Table
Static MAC PhysAddress User Defined wirelessmacaddr Address on Wireless Network Static MAC PhysAddress User Defined wirelessmask Address Mask on Wireless Network Comment DisplayString max 255 (optional) characters Status (optional) Integer enable (default) status disable delete A-52 Avaya Wireless AP-3 User’s Guide...
Page 387: Proxy Arp Parameters
(default) IP Address IpAddress User Defined iparpfltipaddr Subnet Mask IpAddress User Defined iparpfltsubmask Broadcast Filtering Table Name Type Values Access CLI Parameter Broadcast Filtering Table broadcastflttbl Table Index Integer index 1 of 2 Avaya Wireless AP-3 User’s Guide A-53...
Page 388: Tcp/Udp Port Filtering
2 of 2 TCP/UDP Port Filtering The following parameters are used to enable/disable the Port filter feature. Name Type Values Access CLI Parameter Port Filtering Group portflt Port Filter Status Integer enable (default) portfltstatus disable A-54 Avaya Wireless AP-3 User’s Guide...
Page 389: Tcp/Udp Port Filtering Table
Port Filtering Table Table portflttbl Table Index User Defined index (there are also 4 pre-defined indices, see Port Number in this table for more information) Port Type Octet String porttype tcp/udp 1 of 3 Avaya Wireless AP-3 User’s Guide A-55...
Page 390 Service – 138, Index 3: NetBios Session Service – 139, Index 4: SNMP Service – 161) Protocol Name DisplayString User Defined protoname (there are also 4 pre-defined protocols, see Port Number above) 2 of 3 A-56 Avaya Wireless AP-3 User’s Guide...
Page 391 8 or 10 - Wireless 12 = Wireless A & 13 or 15 - all interfaces (default is 15) Status (optional) Integer enable (default for status new entries) disable (default for pre-defined entries) delete 3 of 3 Avaya Wireless AP-3 User’s Guide A-57...
Page 392: Http And Https Commands
HTTP and HTTPS Commands HTTP (Web browser) Parameters CAUTION: Avaya strongly urges you to change the default passwords to restrict access to your network devices to authorized personnel. If you lose or for- get your password settings, you can always perform the...
Page 393: Syntax Examples
(\) when configuring the Help Link location.) The AP Help information is available in English, French, German, Italian, Spanish, and Japanese. Syntax Examples Change HTTP Interface Password [Device-Name]> set httppasswd <New Password> (HTTP interface password) Avaya Wireless AP-3 User’s Guide A-59...
Page 394 Set TCP Port [Device-Name]> set httpport <HTTP port number (default is 80)> Configure Secure Socket Layer (HTTPS) Enabling SSL and configuring a passphrase allows encrypted Secure Socket Layer communications to the AP through the HTTPS interface. A-60 Avaya Wireless AP-3 User’s Guide...
Page 395 [Device-Name]> set sslpassphrase <SSL certificate passphrase> [Device-Name]> show http To view all HTTP configuration information including SSL. HTTP Group Parameters ===================== httpifbitmask httppasswd ******** httpport httphelplink file:///C:/Program Files/ORiNOCO/AP2000/HTML/home.htm httpsetupwiz disable sslstatus enable sslpassphrase ******** Avaya Wireless AP-3 User’s Guide A-61...
Page 396: Iapp Commands
(default) iappstatus disable Periodic Announce Integer iappannint Interval (seconds) 120 (default) Announce Integer 2 seconds iappannresp Response Time Handover Time-out Integer 410 ms iapphandtout 512 ms (default) 614 ms 717 ms 819 ms A-62 Avaya Wireless AP-3 User’s Guide...
Page 397: Intra Bss Commands
AP from communicating with each other: Name Type Values Access CLI Parameter Intra BSS Traffic Group intrabss Intra BSS Traffic Integer passthru (default) intrabssoptype Operation block Syntax Example [Device-Name]> set intrabssoptype <passthru (default)/block)> Avaya Wireless AP-3 User’s Guide A-63...
Page 398: Inventory Management Commands
When creating table entries, you may either specify the argument name followed by argument value or simply entering the argument value. When only the argument value is specified, then enter the values in the order A-64 Avaya Wireless AP-3 User’s Guide...
Page 399: Syntax Examples
IpAddress User Defined ipmask Comment DisplayString User Defined (optional) Status (optional) Integer enable (default) status disable delete Syntax Examples Edit Management IP Access Table [Device-Name]> set mgmtipaccesstbl <index> ipaddr <IP address> ipmask <subnet mask> Avaya Wireless AP-3 User’s Guide A-65...
Page 400: Ip Commands
(default) NOTE: The IP Address Assignment Type (ipaddrtype) must be set to static before the IP Address (ipaddr), IP Mask (ipmask) or Default Gateway IP Address (ipgw) values can be entered. A-66 Avaya Wireless AP-3 User’s Guide...
Page 401: Syntax Examples
[Device-Name]> set ipgw <gateway IP address> [Device-Name]> show network Link Integrity Commands Link Integrity Parameters Name Type Values Access CLI Parameter Link Integrity Group linkint Link Integrity Integer enable linkintstatus Status disable (default) 1 of 2 Avaya Wireless AP-3 User’s Guide A-67...
Page 402: Ip Target Table Parameters
Link Integrity IP Table linkinttbl Target Table Table Index Integer index Target IP Address IpAddress User Defined ipaddr Comment DisplayString User Defined (up to (optional) 254 characters) Status (optional) Integer enable status disable (default) delete A-68 Avaya Wireless AP-3 User’s Guide...
Page 403: Syntax Examples
[Device-Name]> set linkintpollint <the interval between link integrity checks> [Device-Name]> set linkintpollretx <number of times to retransmit before considering the link down> [Device-Name]> set linkintstatus enable [Device-Name]> show linkinttbl (confirm new settings) [Device-Name]> reboot 0 Avaya Wireless AP-3 User’s Guide A-69...
Page 404: Mac Access Control Commands
Integer passthru (default) macacloptype block MAC Access Control Table Parameters Name Type Values Access CLI Parameter MAC Address Table macacltbl Control Table Table Index index MAC Address PhysAddress User Defined macaddr 1 of 2 A-70 Avaya Wireless AP-3 User’s Guide...
Page 405: Syntax Examples
Add an Entry to the MAC Access Control Table [Device-Name]> set macacltbl <index> macaddr <MAC Address> status enable [Device-Name]> show macacltbl Disable or Delete an Entry in the MAC Access Control Table [Device-Name]> set macacltbl <index> status <disable/delete> [Device-Name]> show macacltbl Avaya Wireless AP-3 User’s Guide A-71...
Page 406: Monitoring Parameters
— statif: Displays information and statistics about the Ethernet and wireless interfaces. — stat802.11: Displays additional statistics for the wireless interfaces. — statethernet: Displays additional statistics for the Ethernet interface. — statmss: Displays station statistics and Wireless Distribution System links. A-72 Avaya Wireless AP-3 User’s Guide...
Page 407: Packet Forwarding Commands
Status disable (default) Packet Forwarding Integer 0 (any) (default) pktfwdif Interface Port 1 (Ethernet) 2 (WDS 1) 3 (WDS 2) 4 (WDS 3) 5 (WDS 4) 6 (WDS 5) 7 (WDS 6) Avaya Wireless AP-3 User’s Guide A-73...
Page 408: Rad Commands
The set radstatus command enables Rogue Access Point Detection. The scan repetition duration (radscanint) is also configurable.If the Access Point uses directional antennas to provide directional coverage, then the interface bitmask (radifbitmask) can be configured to maximize the scanning coverage area. A-74 Avaya Wireless AP-3 User’s Guide...
Page 409: Rogue Access Point Detection (Rad) Parameters
Syntax Examples [Device-Name]> set radstatus enable [Device-Name]> set radscanint <15-1440> [Device-Name]> set radifbitmask <4 (WiF A), 8 (WiF B), or 12 (both interfaces)> [Device-Name]> show rad Figure A-14. Results of “show rad” CLI command Avaya Wireless AP-3 User’s Guide A-75...
Page 410: Radius Commands
RADIUS Commands RADIUS Commands Avaya Wireless devices that use RADIUS authentication or accounting support a primary and backup RADIUS server for MAC-based authentication and a primary and backup RADIUS server for EAP/802.1x authentication. The configuration parameters and statistics are the same for both primary and backup servers.
Page 411: Radius Authentication Parameters
Use a server name only if you have enabled the DNS Client functionality. See DNS Client Commands. Name Type Values Access CLI Parameter RADIUS Table radiustbl Authentication Primary RADIUS Integer index Backup RADIUS Integer index RADIUS Server Integer enable status Status disable (default) Avaya Wireless AP-3 User’s Guide A-77...
Page 412 1812 (default) Shared Secret DisplayString User Defined ssecret max 63 characters Response Time Integer 1 – 4 seconds responsetm (sec) 3 sec (default) Maximum Integer 0 – 4 maxretx Retransmissions 3 (default) (optional) A-78 Avaya Wireless AP-3 User’s Guide...
Page 413: Radius Accounting Parameters
254 characters if using a name) Port (optional) Integer User Defined port 1813 (default) Shared Secret DisplayString User Defined ssecret max 63 characters 1 of 2 Avaya Wireless AP-3 User’s Guide A-79...
Page 414: Syntax Examples
[Device-Name]> set radiustbl <index> status enable seraddrfmt <ipaddr or name> ipaddr <RADIUS IP address or name> port <user defined> ssecret <user defined> responsetm <1 to 10 seconds> maxretx <0 to 4 times> [Device-Name]> show radiustbl A-80 Avaya Wireless AP-3 User’s Guide...
Page 415 RADIUS Commands Figure A-15. Results of “show radiustbl” CLI command Avaya Wireless AP-3 User’s Guide A-81...
Page 416: Enable Radius Mac Access Control
Set Authorization Lifetime (for MAC-based authentication or EAP/802.1x authentication) Device-Name]> set radauthlifetm <7200-43200 seconds; default is 0 (disabled)> Enable RADIUS Accounting [Device-Name]> set radaccstatus enable [Device-Name]> set radaccinactivetmr <inactivity timer in minutes> [Device-Name]> show radius A-82 Avaya Wireless AP-3 User’s Guide...
Page 417: Configure Radius Accounting Server
[Device-Name]> set radacctbl <index> status <enable> seraddrfmt <ipaddr or name> ipaddr <RADIUS IP address or name> port <user defined> ssecret <user defined> responsetm <1 to 4 seconds> maxretx <1 to 10 times> [Device-Name]> show radacctbl Avaya Wireless AP-3 User’s Guide A-83...
Page 418: Secure Management Commands
Secure Management Commands Figure A-17. Results of “show radacctbl” CLI command Secure Management Commands Secure Management Parameters Name Type Values Access CLI Parameter Secure Integer Enable/Disable securemgmtstatus Management A-84 Avaya Wireless AP-3 User’s Guide...
Page 419: Serial Port Commands
Stop Bits Integer serstopbits Flow Control Value none (default) serflowctrl xonxoff NOTE: To avoid unexpected performance issues, leave Flow Control at the default setting (none) unless you are sure what this setting should Avaya Wireless AP-3 User’s Guide A-85...
Page 420: Syntax Examples
SNMP Commands SNMP Parameters CAUTION: Avaya strongly urges you to change the default passwords to restrict access to your network devices to authorized personnel. If you lose or for- get your password settings, you can always perform the Reset to Factory Default Procedure.
Page 421 DisplayString User Defined snmprwpasswd Password public (default) max 63 characters SNMPv3 DisplayString User Defined snmpv3authpasswd Authentication public (default) Password max 63 characters SNMPv3 Privacy DisplayString User Defined snmpv3privpasswd Password public (default) max 63 characters Avaya Wireless AP-3 User’s Guide A-87...
Page 422 User Defined index IP Address IpAddress User Defined ipaddr Password DisplayString User Defined (up to passwd 64 characters) Comment DisplayString User Defined (up to (optional) 254 characters) Status (optional) Integer enable (default) status disable delete A-88 Avaya Wireless AP-3 User’s Guide...
Page 423: Syntax Examples
0 or 2 = disable (all interfaces) All management channels disabled 1 or 3 = Ethernet only Ethernet only enabled 4 or 6 = Wireless A only Wireless A only enabled 1 of 2 Avaya Wireless AP-3 User’s Guide A-89...
Page 424: Spanning Tree Commands
(default) stpstatus Status disable Bridge Priority Integer 0 – 65535 stppriority 32768 (default) Maximum Age Integer 600 – 4000 stpmaxage (in 0.01 sec intervals; i.e., 6 to 40 seconds) 2000 (default) 1 of 2 A-90 Avaya Wireless AP-3 User’s Guide...
Page 425: Spanning Tree Priority And Path Cost Table
Access CLI Parameter Spanning Tree Table stpbl Table Table Index (Port) 1 – 15 index Priority Integer 0 – 255 priority 128 (default) Path Cost Integer 1 – 65535 pathcost 100 (default) 1 of 2 Avaya Wireless AP-3 User’s Guide A-91...
Page 426: Spectralink Voip Commands
This parameter will set the basic rates of the AP to be 1 and 2 Mbps in 802.11bg mode and will allow old telephones that operate only at the 1 and 2 Mbps basic rate to connect to the AP. A-92 Avaya Wireless AP-3 User’s Guide...
Page 427: Storm Threshold Commands
Storm Threshold Parameters Name Type Values Access CLI Parameter Storm Threshold Group stmthres Broadcast Integer 0 – 255 stmbrdthres Threshold packets/sec (default is 0) Multicast Threshold Integer 0 – 255 stmmultithres packets/sec (default is 0) Avaya Wireless AP-3 User’s Guide A-93...
Page 428: Storm Threshold Table
(default is 0) Syslog Commands Syslog Parameters The following parameters configure the Syslog settings. Name Type Values Access CLI Parameter Syslog Group syslog Syslog Status Integer enable syslogstatus disable (default) 1 of 2 A-94 Avaya Wireless AP-3 User’s Guide...
Page 429 HTTP interface. When Heartbeat is enabled, the AP periodically sends a message to the Syslog server to indicate that it is active. The frequency with which the heartbeat message is sent depends upon the setting of the Heartbeat Interval. Avaya Wireless AP-3 User’s Guide A-95...
Page 430: Syslog Host Table Parameters
1 – 10 index IP Address IpAddress User Defined ipaddr Comment (optional) DisplayString User Defined Status (optional) Integer enable status disable delete Syntax Examples [Device-Name]> set syslogpriority <1-7 (default is 6)> [Device-Name]> set syslogstatus <enable/disable> A-96 Avaya Wireless AP-3 User’s Guide...
Page 431: System Information Commands
User Defined sysname Location DisplayString User Defined sysloc Contact Name Display User Defined sysctname String Contact E-mail Display User Defined sysctemail String Contact Phone Display User Defined sysctphone String Maximum 254 characters 1 of 2 Avaya Wireless AP-3 User’s Guide A-97...
Page 432 – minutes ss – seconds Emergency Restore Resets all sysresettodefaults to defaults parameters to Note: You must default factory enter the following values command twice to reset to defaults: sysresettodefaults 2 of 2 A-98 Avaya Wireless AP-3 User’s Guide...
Page 433: Syntax Examples
[Device-Name]> set sysname <system name> sysloc <Unit Location> [Device-Name]> set sysctname <Contact Name (person responsible for system)> [Device-Name]> set sysctphone <Contact Phone Number> sysctemail <Contact E-mail address> [Device-Name]> show system Figure A-19. Result of “show system” CLI Command Avaya Wireless AP-3 User’s Guide A-99...
Page 434: Telnet Commands
Telnet Port Integer User Defined telport 23 (default) Telnet Login Integer 1 – 300 seconds tellogintout Inactivity Time-out 30 sec (default) Telnet Session Idle Integer 1 - 900 seconds telsessiontout Time-out 900 sec (default) A-100 Avaya Wireless AP-3 User’s Guide...
Page 435: Syntax Examples
12 = Wireless A and Wireless B Wireless A and Wireless B enabled 13 or 15 = all interfaces All management channels enabled Set TCP Port [Device-Name]> set telport <Telnet port number (default is 23)> Avaya Wireless AP-3 User’s Guide A-101...
Page 436: Tftp Commands
Name Type Values Access CLI Parameter TFTP Group tftp TFTP Server IP IpAddress User Defined tftpipaddr Address 1 of 2 A-102 Avaya Wireless AP-3 User’s Guide...
Page 437: Syntax Examples
[Device-Name]> set tftpfilename <file name> tftpfiletype config tftpipaddr <IP address of your TFTP server> (to ensure the filename, file type, and the IP [Device-Name]> show tftp address are correct) [Device-Name]> download * [Device-Name]> reboot 0 Avaya Wireless AP-3 User’s Guide A-103...
Page 438 [Device-Name]> show tftp (to ensure the filename, file type, and the IP address are correct) After setting the TFTP parameters, you can back up your current file (as long as all the other parameters are the same), with the following command: [Device-Name]> upload * A-104 Avaya Wireless AP-3 User’s Guide...
Page 439: Wds Commands
Name Type Values Access CLI Parameter WDS Security Table wdssectbl Table Table Index Integer Primary WNIC = 3 index Secondary WNIC = 4 Security Mode Integer none, wep secmode Encryption Key 0 WEPKeyType encryptkey0 Avaya Wireless AP-3 User’s Guide A-105...
Page 440: 802.11A Wireless Interface Commands
0 – 2347 medres Reservation Default is 2347 (off) MAC Address PhyAddress 12 hex digits macaddr Closed System Integer enable closedsys disable (default) Supported Octet String Depends on suppchannels Frequency Channels Regulatory Domain 1 of 2 A-106 Avaya Wireless AP-3 User’s Guide...
Page 441 54 Mbits/sec Physical Layer Type Integer ofdm (orthogonal phytype frequency division multiplexing) for 802.11a Note 1: For 802.11a APs in Europe, Auto Channel Select is a read-only parameter; it is always enabled. 2 of 2 Avaya Wireless AP-3 User’s Guide A-107...
Page 442: Syntax Examples
Network Name (SSID) [Device-Name]> set wif <index 3 (Slot A) or 4 (Slot B)> netname <Network Name (SSID) for wireless interface> [Device-Name]> show wif Figure A-20. Results of “show wif” CLI command for an AP A-108 Avaya Wireless AP-3 User’s Guide...
Page 443 AP at one of four levels: • 100% of the maximum transmit power level of the card • 50% • 25% • 12.5% Perform the following commands to enable TX Power Control and set the transmit power level: Avaya Wireless AP-3 User’s Guide A-109...
Page 444 Allowed values are: 1 (100%), 2 (50%), 3 (25%), 4 (12.5%) Autochannel Select (ACS) ACS is enabled by default. Reboot after disabling or enabling ACS. [Device-Name]> set wif <index> autochannel <enable/disable> [Device-Name]> reboot 0 Enable/Disable Closed System [Device-Name]> set wif <index> closedsys <enable/disable> A-110 Avaya Wireless AP-3 User’s Guide...
Page 445: 802.11B Wireless Interface Commands
0 – 2347 medres Reservation Default is 2347 (off) MAC Address PhyAddress 12 hex digits macaddr Closed System Integer enable closedsys disable (default) Supported Octet String Depends on suppchannels Frequency Channels Regulatory Domain 1 of 3 Avaya Wireless AP-3 User’s Guide A-111...
Page 446 Multicast Rate Integer 1 Mbits/sec (1) multrate 2 Mbits/sec (2) (default) 5.5 Mbits/sec (3) 11 Mbits/sec (4) Closed Wireless Integer enable closedsys System disable (default) Medium Distribution Integer enable (default) meddendistrib disable 2 of 3 A-112 Avaya Wireless AP-3 User’s Guide...
Page 447 Depends on suppchannels Frequency Channels Regulatory Domain Physical Layer Type Integer dsss (direct phytype sequence spread spectrum) for 802.11b Regulatory Domain DisplayString U.S./Canada -- regdomain List Europe -- ETSI Japan -- MKK 3 of 3 Avaya Wireless AP-3 User’s Guide A-113...
Page 448: Syntax Examples
<Network Name (SSID) for wireless interface> [Device-Name]> show wif For results of the command, see Figure A-20. show wif Operational Mode [Device-Name]> set wif <index> mode <see table> Mode Operational Mode dot11b-only dot11g-only dot11bg dot11a-only dot11g-wifi A-114 Avaya Wireless AP-3 User’s Guide...
Page 449: Tx Power Control
Allowed values are: 1 (100%), 2 (50%), 3 (25%), 4 (12.5%) Autochannel Select (ACS) ACS is enabled by default. Reboot after disabling or enabling ACS. [Device-Name]> set wif <index> autochannel <enable/disable> [Device-Name]> reboot 0 Enable/Disable Closed System [Device-Name]> set wif <index> closedsys <enable/disable> Avaya Wireless AP-3 User’s Guide A-115...
Page 450 From these measurements the appropriate cell size and density is determined, and the optimum distance between APs is calculated to suit your particular business requirements. A-116 Avaya Wireless AP-3 User’s Guide...
Page 451 Multicast Rate Large 1 and 2 Mbits/sec Medium 1, 2, and 5.5 Mbits/sec Small 1, 2, 5.5 and 11 Mbits/sec Minicell 1, 2, 5.5 and 11 Mbits/sec Microcell 1, 2, 5.5 and 11 Mbits/sec Avaya Wireless AP-3 User’s Guide A-117...
Page 452: 802.11B/G Wireless Interface Commands
1 – 255 dtimperiod 1 = default RTS/CTS Medium Integer 0 – 2347 medres Reservation Default is 2347 (off) MAC Address PhyAddress 12 hex digits macaddr Closed System Integer enable closedsys disable (default) 1 of 4 A-118 Avaya Wireless AP-3 User’s Guide...
Page 453 (default) dot11g-wifi Operating Integer 1 - 14; available channel Frequency Channel channels vary by regulatory domain/country; 802.11g Channel Frequencies Supported Data Octet String See Transmit Rate, suppdatarates Rates next. 2 of 4 Avaya Wireless AP-3 User’s Guide A-119...
Page 454 11 Mbits/sec For 802.11g-only mode: 0 (auto fallback - default) 6 Mbits/sec 9 Mbits/sec 12 Mbits/sec 18 Mbits/sec 24 Mbits/sec 36 Mbits/sec 48 Mbits/sec 54 Mbits/sec 36 Mbits/sec 48 Mbits/sec 54 Mbits/sec 3 of 4 A-120 Avaya Wireless AP-3 User’s Guide...
Page 455: Syntax Examples
Physical Layer Type Integer ERP (Extended phytype Rate Protocol) 4 of 4 Syntax Examples Network Name (SSID) [Device-Name]> set wif <index 3 (Slot A) or 4 (Slot B)> netname <Network Name (SSID) for wireless interface> Avaya Wireless AP-3 User’s Guide A-121...
Page 456 The TX Power Control feature lets the user configure the transmit power level of the card in the AP at one of four levels: • 100% of the maximum transmit power level of the card • 50% • 25% • 12.5% A-122 Avaya Wireless AP-3 User’s Guide...
Page 457 Allowed values are: 1 (100%), 2 (50%), 3 (25%), 4 (12.5%) Autochannel Select (ACS) ACS is enabled by default. Reboot after disabling or enabling ACS. [Device-Name]> set wif <index> autochannel <enable/disable> [Device-Name]> reboot 0 Enable/Disable Closed System [Device-Name]> set wif <index> closedsys <enable/disable> Avaya Wireless AP-3 User’s Guide A-123...
Page 458: Wireless Interface Ssid/Vlan/Security Commands
Name Type Values Access CLI Parameter Wireless Interface Table wifssidtbl SSID Table Table Index Integer Primary WNIC = 3 index Secondary WNIC Table Index Integer 1 - 16 (SSID ssidindex index) 1 of 3 A-124 Avaya Wireless AP-3 User’s Guide...
Page 459 WEPKeyType User Defined encryptkey0 Encryption Key 1 WEPKeyType User Defined encryptkey1 Encryption Key 2 WEPKeyType User Defined encryptkey2 Encryption Key 3 WEPKeyType User Defined encryptkey3 Encryption Integer32 0 - 3 encryptkeytx Transmit Key 2 of 3 Avaya Wireless AP-3 User’s Guide A-125...
Page 460: Syntax Examples
PSK Pass Phrase setting. Similarly, setting PSK Pass Phrase will override a previous Pre-Shared Key setting. Note 2: Avaya recommends using a PSK Pass Phrase of at least 13 characters to ensure that the generated key cannot be easily deciphered by network infiltrators.
Page 461 Inactive NOTE: If you have two or more SSIDs per interface with a security mode of None, be aware that security being applied in the VLAN is not being applied in the wireless network. Avaya Wireless AP-3 User’s Guide A-127...
Page 462: Vlan/Ssid Pair Commands
VLAN ID Table NOTE: Sixteen VLAN/SSID pairs are available for 802.11b/g APs and APs with an 11a Upgrade Kit. 802.11b APs and APs with a 5 GHz Upgrade Kit support only one VLAN/SSID pair. A-128 Avaya Wireless AP-3 User’s Guide...
Page 463 Note 1: When adding a new entry to the table, you must specify the index instance you want to configure, such as 3.5; the 0 index value is not applicable to this table and does not create a new entry. Avaya Wireless AP-3 User’s Guide A-129...
Page 464: Syntax Examples
[Device-Name]> reboot 0 NOTE: Sixteen VLAN/SSID pairs are available for 802.11b/g APs and APs with an 11a Upgrade Kit. 802.11b APs and APs with a 5 GHz Upgrade Kit support only one VLAN/SSID pair. A-130 Avaya Wireless AP-3 User’s Guide...
Page 465: Ascii Character Chart
The table below lists the ASCII characters that you can use to configure WEP Encryption Keys. It also lists the Hexadecimal equivalent for each ASCII character. ASCII ASCII ASCII ASCII Character Equivalent Character Equivalent Character Equivalent Character Equivalent " < & > Avaya Wireless AP-3 User’s Guide...
Page 466 Description ASCII ASCII ASCII ASCII Character Equivalent Character Equivalent Character Equivalent Character Equivalent Avaya Wireless AP-3 User’s Guide...
Page 467: C Specifications
Access Point: • Number of Stations per BSS • Management Functions • Advanced Bridging Functions • Medium Access Control (MAC) Functions • Security Functions • Network Functions • Advanced Wireless Functions Avaya Wireless AP-3 User’s Guide...
Page 468 50 up to 44 up to 88 up to 88 Authentication With WPA up to 27 up to 27 Management Functions Feature 802.11b 802.11a 802.11b/g Web User Interface Telnet / CLI SNMP Agent TFTP Avaya Wireless AP-3 User’s Guide...
Page 469 Software Features Advanced Bridging Functions Feature 802.11b 802.11a 802.11b/g IEEE 802.1d Bridging WDS Relay Roaming Protocol Filtering Multicast/Broadcast Storm Filtering Proxy ARP TCP/UDP Port Filtering Blocking Intra BSS Clients Packet Forwarding Avaya Wireless AP-3 User’s Guide...
Page 470: Medium Access Control (Mac) Functions
Available with 802.11a upgrade kit. Not available with 5Ghz upgrade kit. Note 1: A user cannot manually select a channel for products sold in Europe; these products require automatic channel selection using Dynamic Frequency Selection (DFS). Avaya Wireless AP-3 User’s Guide...
Page 471: Security Functions
Note 2: EAP-MD5, EAP-TLS, EAP-TTLS, and PEAP client supplicant supported. Note 3: Use in conjunction with WPA or 802.1x Authentication. Note 4: Support is provided for a primary and backup RADIUS authentication server for both MAC-based authentication and 802.1x authentication. Avaya Wireless AP-3 User’s Guide...
Page 472: Network Functions
5 GHz Upgrade Kit: One VLAN ID per wireless interface Note 1: Includes Fallback to Primary RADIUS Server, RADIUS Session Timeout, RADIUS Multiple MAC Address Formats, RADIUS DNS Host Name Support, RADIUS Start/Stop Accounting. Avaya Wireless AP-3 User’s Guide...
Page 473: Advanced Wireless Functions
— — Support Note 1: Available only one way (AP to client) if using an Avaya 802.11a/b Card or a non-Avaya Wireless client. Note 2: No client support in 802.11a or 802.11b/g. Note 3: This feature is not available if you are using an Avaya 802.11a/b Card or a non-Avaya Wireless client with an 802.11b AP.
Page 474: Hardware Specifications
Voltage = 100 to 240 VAC (50-60 Hz) Current = 0.2 amp Power Consumption = 20 Watts With Active Ethernet Module Input Voltage = 42 to 60 VDC Output Current = 200mA at 48V Power Consumption = 9-10 Watts Avaya Wireless AP-3 User’s Guide...
Page 475 Transport = -40° to 75°C (-40° to 167 °F) @ 15 to 95% relative humidity Storage = -20° to 75°C (-4° to 167 °F) @ 10 to 95% relative humidity Ethernet Interface 10/100 Base-TX, RJ-45 female socket Serial Port Interface Standard RS-232C interface with DB-9, female connector Avaya Wireless AP-3 User’s Guide...
Page 476: Radio Specifications
• Netscape 6.1 or later Radio Specifications • 802.11a Channel Frequencies • 802.11b Channel Frequencies • 802.11g Channel Frequencies • Wireless Communication Range NOTE: Refer to the Regulatory Flyer included with the AP for the latest regulatory information. C-10 Avaya Wireless AP-3 User’s Guide...
Page 477: A Channel Frequencies
In the CLI, any channels that are not available are labeled Not Supported. NOTE: The original 5 GHz Upgrade Kit only supports the Lower and Middle U-NII bands. The 11a Upgrade Kit supports all of the frequency bands described below. Avaya Wireless AP-3 User’s Guide C-11...
Page 478 — 5.675 5.675 5.675 5.785 — — 5.785 5.785 5.785 5.805 — — 5.805 5.805 5.805 ISM Band 5.825 — — 5.825 — 5.825 Note 1: Channel 34 is the default channel for Japan C-12 Avaya Wireless AP-3 User’s Guide...
Page 479 2.422 2.422 2.422 2.427 2.427 2.427 2.427 2.432 2.432 2.432 2.432 2.437 2.437 2.437 2.437 2.442 2.442 2.442 2.442 2.447 2.447 2.447 2.447 2.452 2.452 2.452 2.457 2.457 2.457 2.462 2.462 2.462 2.467 2.467 Avaya Wireless AP-3 User’s Guide C-13...
Page 480 The web interface will always display the available channels depending in the cards regulatory domain. In the CLI, any channels that are not available are labeled Not Supported. ETSI Channel ID (GHz) (GHz) (GHz) (GHz) 2.412 2.412 2.412 2.417 2.417 2.417 C-14 Avaya Wireless AP-3 User’s Guide...
Page 481 2.452 2.452 2.452 2.457 2.457 2.457 2.462 2.462 2.462 2.467 2.467 2.472 2.472 2.484 Note 1: France is restricted to these channels. Note 2: Channel 14 is only available when using 802.11b only mode. Avaya Wireless AP-3 User’s Guide C-15...
Page 482 Communications at a lower transmit range may travel longer distances. The range values listed in the Communications Range Chart are typical distances as calculated by Avaya’s development team for FCC-certified products. These values provide a rule of thumb and may vary according to the actual radio conditions at the location where the product is used.
Page 483 (614 ft.) Closed Office 67 m 84 m 104 m 129 m (220 ft.) (276 ft.) (341 ft.) (423 ft.) Tx Power Receiver Sensitivity (dBm) Antenna Gain 0 dBi (integrated diversity antenna module; 2.4-2.5 GHz) Avaya Wireless AP-3 User’s Guide C-17...
Page 484 62 m Office (30 ft.) (52 ft.) (85 ft.) (115 ft.) (141 ft.) (164 ft.) (190 ft.) (203 ft.) Tx Power (dBm) Receiver Sensitivit y (dBm) Antenna 3.5 dBi (integrated diversity antennas; 5.15-5.35 GHz) Gain C-18 Avaya Wireless AP-3 User’s Guide...
Page 485 92 m Office (72 ft.) (95 ft.) (128 ft.) (171 ft.) (210 ft.) (262 ft.) (282 ft.) (302 ft.) Tx Power (dBm) Receiver Sensitivity (dBm) Antenna 4 dBi (integrated diversity antennas; 5.15-5.85 GHz) Gain Avaya Wireless AP-3 User’s Guide C-19...
Page 486 (531 ft.) (571 ft.) (761 ft.) Closed 138 m 149 m 97 m 111 m 120 m 160 m Office (453 ft.) (489 ft.) (318 ft.) (364 ft.) (394 ft.) (525 ft.) Tx Power (dBm) C-20 Avaya Wireless AP-3 User’s Guide...
Page 487 Radio Specifications Receiver Sensitivity (dBm) Antenna Gain 3 dBi (integrated diversity antenna module; 2.4-2.5 GHz) Avaya Wireless AP-3 User’s Guide C-21...
Page 488 Radio Specifications C-22 Avaya Wireless AP-3 User’s Guide...
Page 489: Before You Seek Help
Troubleshooting, gather the following information and contact your local authorized reseller or see http://www.avaya.com/support for contact information: • List of Avaya Wireless products installed on your network; include the following: — Product names and quantity — Part numbers (P/N) —...
Page 490 — What were you doing when the error occurred? — What error message did you see? — Can you reproduce the problem? — For each Avaya Wireless product, describe the behavior of the device’s LEDs when the problem occurs Avaya Wireless AP-3 User’s Guide...
