ArgentBranch
Hardware Reference Manual
(Revision 2)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ArgentBranch and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avaya ArgentBranch

Summary of Contents for Avaya ArgentBranch

  • Page 1 ArgentBranch Hardware Reference Manual (Revision 2)
  • Page 2 Copyright  2001 Avaya Inc. All rights reserved. Published by Avaya Inc., who reserve the right to make improvements to the products described in this manual and to revise this publication at any time without notice to any person of such changes.

  • Page 3: Table Of Contents

    Contents CONTENTS Section 1: Introduction to ArgentBranch ............5 About ArgentBranch ..........................6 ArgentBranch Modules ....................6 ArgentBranch PABX Features ...................7 Safety and Homologation Statements....................9 Declaration of Conformity..................9 Statutory Restrictions....................9 Australian requirements .....................9 Further Information and Product Updates ..................10 Product Variants..........................11 Current Country Variants..................11 Port Labelling.............................12...
  • Page 4 ArgentBranch Hardware Reference Manual DCE Cable.......................24 LAN Interconnect Cable ..................25 LAN Crossover Cable....................26 LAN Cable.......................27 Expansion Interconnect Cable..................28 V.24/V.28 WAN Cable....................29 X.21 WAN Cable.....................30 V.35 WAN Cable.....................31 Port Safety Classification ........................33 Technical Specifications........................35 Interfaces .........................35 Protocols ........................36 Section 3: Fitting/Upgrade Instructions ............1 Rack Mounting Assembly instructions....................2...

  • Page 5: Introduction To Argentbranch

    Section 1: Introduction to ArgentBranch This section contains … About ArgentBranch, page 6 Safety and Homologation Statements, page 9 Further Information and Product Updates, page 10 Product Variants, page 11 Port Labelling, page 12 Port Connections, page 13...

  • Page 6: About Argentbranch

    The features provided by standard Caller Display telephones or Caller Display units. All of the above features can be used with the ArgentBranch to provide a fully integrated voice and data system with features otherwise only available on expensive call centre systems.

  • Page 7: Argentbranch Pabx Features

    Section 1: Introduction to ArgentBranch PABX F RGENT RANCH EATURES The main ArgentBranch PABX features are as follows: 8-60 Telephone Lines (connections to the Public Switched Telephone Network - PSTN). 0-100 Telephone Ports (internal extensions). ISDN connections to meet your traffic requirements.
  • Page 8 For configuration information and an overview of the advanced features available on the ArgentBranch, please refer to the Help Text files on the Installation Wizard CD that accompanies all new units. This CD is designed to make installation and configuration of your ArgentBranch as simple as possible.

  • Page 9: Safety And Homologation Statements

    All ISDN and WAN cables used with this product must not be longer than 3m. Refer to Cables, page 23 for details. The 2A 16V Lump-in-Line PSU supplied with the ArgentBranch must only be connected to 50Hz/60Hz AC power sources in the range 100 – 240V.

  • Page 10: Further Information And Product Updates

    ArgentBranch Hardware Reference Manual FURTHER INFORMATION AND PRODUCT UPDATES Further information, including Product and Reference Manual updates, can be obtained from Avaya Inc. Alchemy Dealers and Distributors, or from Avaya Inc. Alchemy web site: http://www.avaya.co.uk/products/#alchemy Revision 2...

  • Page 11: Product Variants

    Section 1: Introduction to ArgentBranch PRODUCT VARIANTS As a standalone product the ArgentBranch can be used as an IP Router with integral Firewall. When used in conjunction with any ArgentPhone module the ArgentBranch acts as a fully featured PBX. The ArgentBranch 3000 is equipped with 1 x PRI (Primary rate ISDN) module. This module can be used to provide upto 30 external lines.

  • Page 12: Port Labelling

    ArgentBranch Hardware Reference Manual PORT LABELLING This section illustrates the ports on the ArgentBranch products. RGENT RANCH RONT The following diagram shows the port labelling on the front of the Alchemy Series ArgentBranch product: Expansion Port WAN Port Unit LAN Link...

  • Page 13: Port Connections

    Section 1: Introduction to ArgentBranch PORT CONNECTIONS This section provides information on the use of the ArgentBranch ports. It covers: DTE Port. DC Power Input Connector. Connection to Primary Rate ISDN (PRI). Audio Input Connector. Connection to an X.21, V.35 or V.24/V.28 Leased Line.

  • Page 14: Audio Input Connector

    ONNECTION TO AN EASED The Leased Line port on the rear of the ArgentBranch is labelled as follows: This port supports a single synchronous data connection, and can support an X.21, V.35 or V.24/V.28 interface. The selection of the required interface is automatically determined from the pin-out of the appropriate Alchemy Series cable plugged into the port.

  • Page 15: Argent Expansion Ports

    RGENT XPANSION ORTS The ArgentBranch is equipped with six Expansion ports. These are located on the rear of the unit and are labelled as follows: EXPANSION The Expansion ports are used to interconnect to other Alchemy Series products i.e. the ArgentPhone 8/16/30.

  • Page 16: External Control Connector

    ONNECTION TO ASIC The ArgentBranch 0808 connects to Basic Rate ISDN. The ArgentBranch 3000 has one free ISDN slot (slot B). A second PRI30 module or a BRI8 module can be installed in this slot. The ArgentPRI30 or ArgentBRI8 upgrade Features are supplied with suitable cables for connection to the ISDN Network.

  • Page 17: Technical Data

    Section 2: Technical Data This section contains … Port Pinouts, page 18 Cables, page 23 Port Safety Classification, page 33 Technical Specifications, page 35...

  • Page 18: Port Pinouts

    ArgentBranch Hardware Reference Manual PORT PINOUTS This section provides technical specifications for the ArgentBranch ports. DTE P OCKET Pin 1 Pin 25 Pin No. Description Signal Direction Transmit Data (TxD) Receive Data (RxD) Request to Send (RTS) Clear to Send(CTS)

  • Page 19: Isdn Port - Pri (Rj45 Socket)

    Section 2: Technical Data ISDN P – P (RJ45 Socket) Pin 1 Pin 8 Pin No. Description Signal Direction Receive data (Rx-A) Receive data (Rx-B) Transmit data (Tx-B) Transmit data (Tx-A) LAN P - 10B T/100B T (RJ45 S OCKET The information below refers to LAN ports 1 –...

  • Page 20: Wan Port (37 Way D-Type Socket)

    ArgentBranch Hardware Reference Manual WAN P OCKET Pin 1 Pin 37 Description Signal Description Signal Dir. Dir. V11 Rx-B V11 Rx-A V11 Ind-A V11 Ind-B V11 Clk-A V11 Clk-B V11 Tx-A V11 Tx-B V11 Ctl-B V11 Ctl-A V11 Gnd WAN ID 0...

  • Page 21: Audio Port (3.5Mm Stereo Jack Socket)

    Section 2: Technical Data (3.5 UDIO TEREO OCKET Left Right Common Pin No. Description Signal Direction Common Common Left Audio In – Left Channel Right Audio In – Right Channel (RJ45 S XPANSION OCKET Pin 1 Pin 8 Pin No. Description Signal Direction Receive Data (Rx-B)

  • Page 22: External Control Port

    ArgentBranch Hardware Reference Manual XTERNAL ONTROL Pin No. Description Circuit 1 Circuit 2 0 Volts (Ground/Chassis) Not Connected Not Connected Control Circuit Information Control Circuit 1 Pin 2 and Pin 3, ensure that Pin 2 is at a positive voltage with respect to Pin 3.

  • Page 23: Cables

    Section 2: Technical Data CABLES This section provides information about the cables that are used with ArgentBranch. PRI/BRI ISDN C ABLE Part No: CABBRINN03M0PP00 Sales Feature: ARG-ISDNC Supply: Supplied as standard with ArgentBranch. 1 cable supplied per ISDN unit. RJ45 Plug.

  • Page 24: Dce Cable

    ArgentBranch Hardware Reference Manual DCE C ABLE Part No: CABMANSN02M0PS00 Sales Feature: ARG-TAC 25 Way D-Type Plug with UNC 4-40 locking screws. 9 Way D-Type Socket with UNC 4-40 locking screws. 12 core screened cable – each core is 7/0.203mm (24 a.w.g.) tinned copper stranded wire, nominal capacitance of 95pF/m, resistance of 92 Ω/km, screened with tinned...

  • Page 25: Lan Interconnect Cable

    NTERCONNECT ABLE Part No: CABETHNN01M0PP00 Sales Feature: ARG-HSIC Supply: Optional extra. This cable is used when connecting the ArgentWAN 3 to the ArgentBranch. RJ45 Plug. RJ45 Plug. Cat 5 UTP cable – GREEN. 1 metre. Pin Connections End A Colour...

  • Page 26: Lan Crossover Cable

    ArgentBranch Hardware Reference Manual LAN C ROSSOVER ABLE Part No: CABETHNX03M0PP00 Sales Feature: ARG-EX10C Supply: Optional extra. This cable is used when connecting Hub Ports 1 – 7 directly to another Hub. RJ45 Plug. RJ45 Plug. Cat 5 UTP cable – BLACK.

  • Page 27: Lan Cable

    Section 2: Technical Data LAN C ABLE Part No: CABETHNN03M0PP00 Sales Feature: ARG-LAN3C Supply: Optional extra. This cable is used when connecting Hub Ports 1 – 7 directly to a PC. RJ45 Plug. RJ45 Plug. Cat 5 UTP cable – GREY. 3 metres.

  • Page 28: Expansion Interconnect Cable

    ArgentBranch Hardware Reference Manual XPANSION NTERCONNECT ABLE Part No: CABTDMSN01M0PP00 Sales Feature: ARG-VIC Supply: Optional extra. The RJ45 Plug Shell at each end of the cable is connected to the STP Cable Drain Wire. Shielded RJ45 Plug. Shielded RJ45 Plug.

  • Page 29: V.24/V.28 Wan Cable

    Section 2: Technical Data V.24/V.28 WAN C ABLE Part No: CABV28SN03M0PP00 Sales Feature: ARG-WANV24C Supply: Optional extra. 37 Way D-Type Plug with UNC 4-40 locking screws. 25 Way D-Type Plug with UNC 4-40 locking screws. Labelled with CABV28SN03M0PP00 /1. 12 core screened cable – each core is 7/0.203mm (24 a.w.g.) tinned copper stranded wire, nominal capacitance of 95pF/m, resistance of 92 Ω/km, screened with tinned copper braid, maximum working voltage of 440V r.m.s.

  • Page 30: Wan Cable

    ArgentBranch Hardware Reference Manual X.21 WAN C ABLE Part No: CABX21SN03M0PP00 Sales Feature: ARG-WANX21C Supply: Optional extra. 37 Way D-Type Plug with UNC 4-40 locking screws. 15 Way D-Type Plug with M3 locking screws. Labelled with CABX21SN03M0PP00. 6 twisted pair screened cable – each core is 7/0.203mm (24 a.w.g.) tinned copper stranded wire, nominal capacitance of 98pF/m, impedance of 77 Ω...

  • Page 31: Wan Cable

    Section 2: Technical Data V.35 WAN C ABLE Part No: CABV35SN03M0PP00 Sales Feature: ARG-WANV35C Supply: Optional extra. 37 Way D-Type Plug with UNC 4-40 locking screws. 34 Way MRAC Plug. Labelled with CABV35SN03M0PP00. 10 twisted pair screened cable – each core is 7/0.203mm (24 a.w.g.) tinned copper stranded wire, nominal capacitance of 98pF/m, impedance of 80 Ω...
  • Page 32 ArgentBranch Hardware Reference Manual End A Name Cable Notes End B Receive Clock – A Twisted Pair Receive Clock – B External Clock – A Twisted Pair External Clock - B Ground ----- Connect pins 7 and 25 to pin 6 at End A only.

  • Page 33: Port Safety Classification

    Connector for DC input SELV power. Additionally the Alchemy Series ArgentBranch 3000 has the ability to support either 1 x BRI8 module (providing 4 x BRI ISDN ports) or a second PRI30 module (providing a second PRI ISDN port). Revision 2...
  • Page 34 ArgentBranch Hardware Reference Manual The ArgentBranch 0808 supports 2 x BRI8 modules (providing 8 x BRI ISDN ports). The BRI ISDN port is classified as follows: Port Name Port Description Port Classification BRI ports BRI ISDN connection TNV (Operating (NET)

  • Page 35: Technical Specifications

    Section 2: Technical Data TECHNICAL SPECIFICATIONS NTERFACES Interface Information 25 way D-Type female connector, V.24/V.28. (Used for Production Test purposes only). ISDN PRI S/T: 1 x RJ45 socket (optionally 2). ETSI S/T Interface to CTR4 for Pan European Connection. BRI S/T: 4 x RJ45 sockets.

  • Page 36: Protocols

    ArgentBranch Hardware Reference Manual ROTOCOLS Protocol Information V.120 - - - A standard Rate Adaption mechanism. V.110 - - - A standard Rate Adaption mechanism. RFC 1661 Point to Point Protocol. RFC 1570 Link Control Protocol. RFC 1990 Multi-Link (Point to Point) Protocol.

  • Page 37: Fitting/Upgrade Instructions

    Index Section 3: Fitting/Upgrade Instructions This section contains … Rack Mounting Assembly Instructions, page 2 BRI/PRI ISDN Module Upgrade Instructions, page 3 Modem Module Upgrade Instructions, page 4 Voice Compression Module Upgrade, page 5...
