Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN
AP 8120-O
How to get help
To access the complete range of services and support that Avaya provides, go to www.avaya.com.
You can also go to
• technical documentation
• product training
• technical support
If you purchased a service contract for your Avaya product from a distributor or authorized reseller
and you need assistance, contact the technical support staff for that distributor or reseller.
Safety Messages
Caution:
The Avaya WLAN AP 8120-O radios are disabled by default and can be enabled only by a
system administrator.
Voltage:
Danger — High voltage. This situation or condition can cause injury or death due to electric
shock.
Warning:
Only a qualified service personnel must install this product. Read and follow all warning notices
and instructions marked on the product or included in the documentation.
Warning:
Install this device in such a manner as to maintain a minimum of 25 cm (9.8 inches) separation
distance between the radiating element(s) and all persons. This safety warning conforms with
FCC radio frequency exposure limits.
©
2014 Avaya Inc.
www.avaya.com/support
Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O
to access the following pages:
Release 3.0
NN47251-312
Issue 02.01
June 2014
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLAN 8100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avaya WLAN 8100 Series

Summary of Contents for Avaya WLAN 8100 Series

  • Page 1 Safety Messages Caution: The Avaya WLAN AP 8120-O radios are disabled by default and can be enabled only by a system administrator. Voltage: Danger — High voltage. This situation or condition can cause injury or death due to electric shock.
  • Page 2 Do not touch or move the access point when the antennas are transmitting or receiving. Warning: Intentional radiators, such as the Avaya WLAN AP 8120-O are not intended to be operated with any antenna(s) other than those furnished by Avaya. An intentional radiator may only be operated with the antenna(s) with which it is authorized.
  • Page 3 Warning: Avaya requires that the access point in the outdoor enclosure be powered with a Power Over Ethernet (POE) that is supplied only from a WLAN Avaya 8100. Introduction This section describes site conditions required before installing the WLAN AP 8120-O access point.
  • Page 4 Power over Ethernet (POE) equipment located inside the building. In the event of a local strike, the Ethernet surge arrester instantaneously limits sudden voltage surges across the cable. Note: The Avaya-provided series indoor Ethernet surge arrester is not rated for outdoor use. You must only install the device indoors. Warning: You are required to have a rated surge protector for any cable exiting the building.

  • Page 5: Table Of Contents

    Das Installationspaket enthält die folgenden Teile: • 1 Access Point Avaya WLAN-AP 8120-O • 1 Montageset: - 1 Flachhalterung - 2 Basishalterungen - 1 Schlauchschelle - 4 Ankerbolzen June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...

  • Page 6: Related Links

    The AP 8120-O access point has one RJ-45 port that provides a 10/100/1000BASE-TX Ethernet connection that is used to indirectly connect the access point to an Avaya WC 8180 WLAN controller, typically through an intermediate Layer 2 or Layer 3 network. When connecting an outdoor access point, use a Category 5e (CAT-5e) cable with straight-through signaling and standard RJ-45 connectors to connect to a network device.

  • Page 7: Waterproofing The Ethernet Utp Cable

    Ethernet UTP cable or risk an electrical shock. To waterproof the Ethernet cable, complete the following procedure: Note: Avaya recommends using only an certified outdoor UTP cable such as a CAT-5E cable. Procedure 1. Unscrew the waterproof feed through cap and extract the grommet seal.
  • Page 8 PIN 7– Brown and white PIN 7– Brown and white PIN 8– Solid brown PIN 8– Solid brown Related Links Installing the WLAN AP 8120-O on page 5 June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...

  • Page 9: Grounding The Wlan Ap 8120-O

    5. Connect the other end of the green ground wire to an acceptable low-impedance Earth ground using the shortest and most direct run. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...

  • Page 10: Installing The Wlan Ap 8120-O On A Vertical Pole

    2. Drive the screws to attach the plane bracket to the back case. 3. Align the tab holes of the static brackets horizontally to the pole. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 11 4. Drive the four round head screws to attach the static bracket to the plane bracket. 5. Thread the open end of the hose strap through the two tabs on the static bracket. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 12 WLAN AP 8120-O. 9. Insert Avaya 5 GHz antennas as required into the connectors at the top of the WLAN AP 8120-O. Tighten the antennas by hand. 10. Insert Avaya 2.4 GHz antennas as required into the connectors at the bottom of the WLAN AP 8120-O Tighten the antennas by hand.
  • Page 13 Ethernet surge arrester and PoE to the WLAN AP 8120- Note: If you are using the Avaya PoE injector, you are not required to use the supplied Ethernet surge arrester as the Avaya PoE injector has internal surge protection.

  • Page 14: Mounting The Wlan Ap 8120-O On A Horizontal Pole

    Figure 9: Attaching the plane bracket to backcase 2. Drive the screws to attach the plane bracket to the back case. 3. Align the static brackets tab holes vertically to the pole. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 15 4. Drive the four round head screws to attach the static bracket to the plane bracket. 5. Thread the open end of the hose strap through the two tabs on the static bracket. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 16 7. Verify that the WLAN AP 8120-O is attached securely to the pole. 8. Ground the WLAN AP 8120-O to a proper Earth ground using the procedure in Grounding the WLAN AP 8120-O. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 17 9. Insert Avaya 5 GHz antennas as required into the connectors at the top of the WLAN AP 8120-O. Tighten the antennas by hand. 10. Insert Avaya 2.4 GHz antennas as required into the connectors at the bottom of the WLAN AP 8120-O.

  • Page 18: Installing The Wlan Ap 8120-O On A Wall

    To connect the Avaya PoE injector to the WLAN AP 8120-O, see Installing the Power over Ethernet injector. Related Links Installing the WLAN AP 8120-O on page 5 Installing the WLAN AP 8120-O on a wall Complete the following procedure to mount the WLAN AP 8120-O on a wall.
  • Page 19 Figure 15: Drilling holes into surface 3. Hammer the bolt into each of the holes that you drilled. 4. Place the lock and flat washers on the four hex cap screws. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 20 5. Drive the screws to attach the plane bracket to the back case. 6. Tighten the flat washers to secure the bracket to the mounting surface. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 21 WLAN AP 8120-O. 9. Insert Avaya 5 GHz antennas as required into the connectors at the top of the WLAN AP 8120-O. Tighten the antennas by hand. 10. Insert Avaya 2.4 GHz antennas as required into the connectors at the bottom of the WLAN AP 8120-O Tighten the antennas by hand.
  • Page 22 8120-O. Note: If you are using the Avaya PoE injector, you are not required to use the supplied Ethernet surge arrester as the Avaya PoE injector has internal surge protection. a. To connect the supplied Ethernet surge arrester with the WLAN AP 8120-O, see Installing the Ethernet surge arrester.

  • Page 23: Installing The Ethernet Surge Arrester

    (POE) devices and supports normal and reverse polarity PoE. For a typical installation, refer to the following diagram. Note: If you are using the Avaya PoE injector, you are not required to connect the Ethernet surge arrester, because the Avaya PoE injector already has internal surge protection. Warning: The Ethernet surge arrester is an indoors unit only.
  • Page 24 3. Using a certified grounding wire, screw one end of a copper grounding wire to the large ground screw located between the two RJ-45 connectors as shown in the following diagram. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 25 6. Insert the wateproofed end of the Ethernet cable into the bottom of the WLAN AP 8120-O, tightening in place by hand. See the waterproofing the Ethernet UTP cable section,Waterproofing the Ethernet UTP cable for waterproofing the Ethernet cable. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 26 Ethernet cables are fed through their respective openings at the bottom of the Ethernet surge arrester. 9. Screw the top on securely. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...

  • Page 27: Installing The Power Over Ethernet Injector

    5 Installing the Power over Ethernet injector Avaya provides a Power over Ethernet (PoE) injector for the AP8120 access point that you can order separately. The PD-9001G-40/SP is a single port, Gigabit Midspan with surge protection injector that is 802.3af and 802.3at compliant. When using the PD-9001G-40/SP, you are not required to use the Ethernet surge arrester provided with the AP8120-O.
  • Page 28 3. Connect the other end to a working AC outlet. 4. Insert one end of an Ethernet cable into the DATA IN port on the PoE adapter. June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
  • Page 29 Figure 23: PoE DATA IN and DATA & POWER ports 5. Connect the other end to the Avaya WLAN switch. The AC indicator lights up. Figure 24: PoE AC and PORT indicators 6. Insert the waterproofed connection of Ethernet cable into the Ethernet connector found at the bottom of the WLAN AP 8120-O .
  • Page 30 7. Insert the other end of the weatherproofed Ethernet cable into the DATA & POWER OUT port on the PoE. The Port indicator lights up. Related Links Installing the WLAN AP 8120-O on page 5 June 2014 Installation Job Aid (English) for Avaya WLAN 8100 series- WLAN AP 8120-O...
