Intel Desktop Board D865GSA Technical Product Specification
2.7.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• One Universal 0.8 V / 1.5 V AGP 3.0 connector supporting 1x, 4x, and 8x AGP cards
• Three PCI Conventional (rev 2.3 compliant) bus add-in card connectors. The
SMBus is routed to PCI Conventional bus connector 2 only (ATX expansion slot 6).
PCI Conventional bus add-in cards with SMBus support can access sensor data and
other information residing on the board.
Note the following considerations for the PCI Conventional bus connectors:
• All of the PCI Conventional bus connectors are bus master capable.
• SMBus signals are routed to PCI Conventional bus connector 2. This enables PCI
Conventional bus add-in boards with SMBus support to access sensor data on the
boards. The specific SMBus signals are as follows:
⎯ The SMBus clock line is connected to pin A40.
⎯ The SMBus data line is connected to pin A41.
2.7.2.3

Front Panel Connector

This section describes the functions of the front panel connector. Table 30 lists the
signal names of the front panel connector. Figure 12 is a connection diagram for the
front panel connector.
Table 30. Front Panel Connector
Pin Signal
Hard Drive Activity LED
1 HD_PWR
3 HDA#
Reset Switch
5 Ground
7 FP_RESET#
9 +5 V
58
In/
Out Description
Out Hard disk LED
pull-up to +5 V
Out Hard disk active
LED
Ground
In Reset switch
Power
Power
In/
Pin Signal Out
Power LED
2 HDR_BLNK_GRN Out
4 HDR_BLNK_YEL Out
On/Off Switch
6 FPBUT_IN In
8 Ground
Not Connected
10 N/C
Description
Front panel green
LED
Front panel yellow
LED
Power switch
Ground
Not connected
