Intel Desktop Board D865GSA Technical Product Specification
Table 42 lists the BIOS Setup program menu features.
Table 42. BIOS Setup Program Menu Bar
Maintenance Main
Clears Displays
passwords and processor
displays and
processor memory
information configura-
tion
Table 43 lists the function keys available for menu screens.
Table 43. BIOS Setup Program Function Keys
BIOS Setup Program
Function Key
< ← > or < → >
< ↑ > or < ↓ >
<Tab>
<Enter>
<F9>
<F10>
<Esc>
3.2

BIOS Flash Memory Organization

The Firmware Hub (FWH) includes a 4 Mbit (512 KB) symmetrical flash memory device.
3.3

Resource Configuration

3.3.1

PCI Autoconfiguration

The BIOS can automatically configure PCI devices. PCI devices may be onboard or
add-in cards. Autoconfiguration lets a user insert or remove PCI cards without having
to configure the system. When a user turns on the system after adding a PCI card, the
BIOS automatically configures interrupts, the I/O space, and other system resources.
Any interrupts set to Available in Setup are considered to be available for use by the
add-in card.
78
Advanced Security
Configures Sets
advanced passwords
features and security
available features
through the
chipset
Description
Selects a different menu screen (Moves the cursor left or right)
Selects an item (Moves the cursor up or down)
Selects a field (Not implemented)
Executes command or selects the submenu
Load the default configuration values for the current menu
Save the current values and exits the BIOS Setup program
Exits the menu
Power Boot
Configures Selects boot
power options
manage-
ment
features and
power
supply
controls
Exit
Saves or
discards
changes to
Setup
program
options
