Intel Desktop Board D865GSA Technical Product Specification
1.6

Legacy I/O Controller

The Winbond W83627EHG I/O controller provides the following features:
• One serial port
• One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• PS/2-style mouse and keyboard interfaces
• Interface for one 1.44 MB or 2.88 MB diskette drive
• Intelligent power management, including a programmable wake-up event interface
• PCI power management support
The BIOS Setup program provides configuration options for the I/O controller.
For information about
Winbond W83627EHG I/O controller
1.6.1

Serial Port

The board has one serial port connector located on the back panel. The serial port
supports data transfers at speeds up to 115.2 kbits/sec with BIOS support.
For information about
The location of the serial port A connector
1.6.2

Parallel Port

The 25-pin D-Sub parallel port connector is located on the back panel. Use the BIOS
Setup program to set the parallel port mode.
For information about
The location of the parallel port connector
1.6.3

Diskette Drive Controller

The I/O controller supports one diskette drive. Use the BIOS Setup program to
configure the diskette drive interface.
For information about
The location of the diskette drive connector on the D865GSA board
36
Refer to
http://www.winbond.com/e-winbondhtm/index.asp
Refer to
Figure 10, page 53
Refer to
Figure 10, page 53
Refer to
Figure 11, page 54
