Intel Desktop Board D865GSA Technical Product Specification
1.1

Overview

1.1.1

Feature Summary

Table 1 summarizes the major features of the Desktop Board D865GSA.
Table 1. Feature Summary
Form Factor
Processor
Memory
Chipset
Video
Audio
Legacy I/O Control
USB
Peripheral
Interfaces
LAN Support
10
microATX (9.60 inches by 8.80 inches [243.84 millimeters by 223.52 millimeters])
Support for the following:
® ®
• Intel Pentium D processor in an LGA775 socket with an 800 MHz system bus
® ®
• Intel Pentium 4 processor in an LGA775 socket with an 800 or 533 MHz
system bus
® ®
• Intel Celeron D processor in an LGA775 socket with a 533 MHz system bus
• Two 184-pin DDR SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR 400, DDR 333, and DDR 266
• Support for up to 2 GB of system memory
®
Intel 865G Chipset, consisting of:
®
• Intel 82865G Graphics and Memory Controller Hub (GMCH)
®
• Intel 82801EB I/O Controller Hub (ICH5)
• 4 Mbit Firmware Hub (FWH)
®
Intel Extreme Graphics 2 controller
Audio subsystem for AC '97 processing using the Realtek* ALC655 codec
Winbond* W83627EHG LPC Bus I/O controller
Support for USB 2.0 devices
• Eight USB ports
• One serial port
• One parallel port
• Two Serial ATA IDE interfaces
• Two Parallel ATA IDE interfaces with UDMA 33, ATA-66/100 support
• One diskette drive interface
• PS/2* keyboard and mouse ports
10/100 Mbits/sec LAN subsystem using the Realtek RTL8100C Ethernet LAN
controller
continued
