Front Panel Audio Connector; Atx12V Power Connector; Main Power Connector; Power Supply Connectors - Intel BLKD865GSAL Technical Product Specification

Table 27. Front Panel Audio Connector
Pin Signal Name
1 Mono Mic in (Stereo Mic 1)
3 Mono Mic Bias (Stereo Mic 2)
5 Right channel out
7 No connect
9 Left channel out
2.7.2.1

Power Supply Connectors

The board has the following power supply connectors:
• Main power – a 2 x 12 connector. This connector is compatible with 2 x 10
connectors previously used on Intel Desktop boards. The board supports the use of
ATX12V power supplies with either 2 x 10 or 2 x 12 main power cables. When
using a power supply with a 2 x 10 main power cable, attach that cable on the
rightmost pins of the main power connector, leaving pins 11, 12, 23, and 24
unconnected.
• ATX12V power – a 2 x 2 connector. This connector provides power directly to the
processor voltage regulator and must always be used. Failure to do so will prevent
the board from booting.
Table 28. ATX12V Power Connector
Pin Signal Name
1 Ground
3 +12 V
Table 29. Main Power Connector
Pin Signal Name
1 +3.3 V
2 +3.3 V
3 Ground
4 +5 V
5 Ground
6 +5 V
7 Ground
8 PWRGD (Power Good)
9 +5 V (Standby)
10 +12 V
(Note)
11 +12 V
12 2 x 12 connector detect
Note: When using a 2 x 10 power supply cable, this pin will be unconnected.
Pin
2
4
6
8
10
Pin Signal Name
2 Ground
4 +12 V
Pin Signal Name
13 +3.3 V
14 -12 V
15 Ground
16 PS-ON# (power supply remote on/off)
17 Ground
18 Ground
19 Ground
20 No connect
21 +5 V
22 +5 V
23 +5 V
(Note)
24 Ground
Technical Reference
Signal Name
Audio Ground
Audio +5 V
Right channel return
Key
Left channel return
(Note)
(Note)
