Overview of BIOS Features

What This Chapter Contains
3.1 Introduction...............................................................................................77
3.2 BIOS Flash Memory Organization ..................................................................78
3.3 Resource Configuration ...............................................................................78
3.4 System Management BIOS (SMBIOS)............................................................79
3.5 Legacy USB Support ...................................................................................80
3.6 BIOS Updates ............................................................................................80
3.7 Boot Options..............................................................................................81
3.8 Fast Booting Systems with Intel
3.9 BIOS Security Features ...............................................................................84
3.1

Introduction

The board uses an Intel/AMI BIOS that is stored in the Firmware Hub (FWH) and can
be updated using a disk-based program. The FWH contains the BIOS Setup program,
POST, the PCI auto-configuration utility, and Plug and Play support.
The BIOS displays a message during POST identifying the type of BIOS and a revision
code. The initial production BIOSs are identified as SA86510A.86A.
When the BIOS Setup configuration jumper is set to configure mode and the computer
is powered-up, the BIOS compares the CPU version and the microcode version in the
BIOS and reports if the two match.
The BIOS Setup program can be used to view and change the BIOS settings for the
computer. The BIOS Setup program is accessed by pressing the <F2> key after the
Power-On Self-Test (POST) memory test begins and before the operating system boot
begins. The menu bar is shown below.
Maintenance Main
NOTE
The maintenance menu is displayed only when the board is in configure mode.
Section 2.8 on page 61 shows how to put the board in configure mode.
®
Rapid BIOS Boot..........................................82
Advanced Security Power Boot Exit
