Table 21 lists the component-side connectors identified in Figure 11.
Table 21. Component-side Connectors Shown in Figure 11
Item/callout
from Figure 11
Description
A
PCI Conventional bus add-in card connector 3
B
PCI Conventional bus add-in card connector 2
C
PCI Conventional bus add-in card connector 1
D
AGP 3.0 connector
E
Rear chassis fan connector
F
+12V power connector (ATX12V)
G
Processor fan connector
H
Main power connector
I
Diskette drive connector
J
Primary parallel ATA IDE connector [Black]
K
Chassis intrusion connector
L
Secondary parallel ATA IDE connector [White]
M
Serial ATA connector 0
N
Serial ATA connector 1
O
Front panel connector
P
Front chassis fan connector
Q
Front panel USB connector
R
Front panel USB connector
S
ATAPI CD-ROM connector
T
Front panel audio connector
