Button
Broadcast
Scan
Security
Switch
Keyboard
Language
Devices
Names

Changing the display behavior

From the Menu dialog box
HP KVM Server Console Switch G2 connection mode, and a time to delay display of the OSD after
pressing the Print Scrn key can be changed. The display order setting alters how servers display in several
screens, including the Main, Devices, and Broadcast dialog boxes.

Accessing the Menu dialog box

To access the Menu dialog from the Main dialog box
click Setup>Menu. The Menu dialog box appears.

Selecting the display order of servers

From the Menu dialog box
1.
servers alphabetically by name.
Function
Controls multiple servers simultaneously through keyboard and mouse actions.
Sets up custom scan patters for up to 16 servers.
Sets password to restrict server access. A valid password must be alphanumeric and
contain a minimum of five characters and a maximum of 15 characters. Permitted
characters are case sensitive and can consist of A–Z, 0–9, spaces and hyphens.
Enables the Screen Saver mode.
Changes the Switch mode to preemptive or cooperative.
Changes the keyboard country code reported by the interface adapter if queried.
Enables a user to change the language displayed in the OSD. Changes the
language for help text, key mapping, and all screens.
Identifies device types attached to the console switch, including servers and other
legacy console switches. You can also modify the type of legacy console switches.
Enables you to name the interface adapter.
("Accessing the Menu dialog
("Accessing the Menu dialog
box" on page 22), the display order of servers,
("Accessing the Main dialog
box" on page 22), select Name to display
box" on page 17),
Local port operation 22
