Keystroke
Right or Left arrows
Page Up or Page Down
Ctrl + Ctrl, Shift + Shift
or Alt + Alt
Home or End
Backspace
Delete
Shift, Delete
Numbers
Caps Lock

Configuring the Setup dialog box

You can configure the console switch and manage routine tasks for your servers from the Setup dialog
box ("Accessing the Setup dialog

Accessing the Setup dialog box

From the Main dialog box
box appears.

Managing routine tasks for servers

Button
Menu
Flag
Description
Moves the cursor between columns. When editing a text box, these keys move
the cursor within the column.
Pages up and down through Name and Port lists.
Activates OSD.
Moves the cursor to the top or bottom of a list.
Erases characters in a text box.
Deletes current selection in the Scan dialog box or characters in a text box.
Deletes from current selection to all lines below it when editing a scan list.
Adds numbers from the keyboard or keypad.
Disables the user. (Use the Shift key to change case.)
box" on page 21) within the OSD.
("Accessing the Main dialog
Function
Changes the server listing between numerically by port or EID number and
alphabetically by name. After you press Print Scrn, changes the delay time before
the Main dialog box appears.
Changes the display, timing, color, and location of the status flag.
box" on page 17), click Setup. The Setup dialog
Local port operation 21
