Flag

Accessing the Flag dialog box

From the Main dialog box
dialog box appears.

Displaying the status flag

From the Flag dialog box
1.
determine what information appears.
Select Displayed to show the flag constantly, or select Timed to display the flag for only five seconds
2.
after soft switching.
Select a flag color in Display Color.
3.
In the Display Mode, select Opaque for a solid-color flag or Transparent to see the desktop through
4.
the flag.
Position the status flag on the desktop:
5.
Click Set Position to gain access to the Position Flag screen.
a.
Left-click and hold the title bar and drag to the desired location.
b.
Right-click to return to the Flag dialog box.
c.
Choose one of the following options:
6.
Click OK to save settings.
o
Click X to exit, or press the Esc key to exit without saving settings.
o
NOTE:
box
("Accessing the Main dialog
("Accessing the Flag dialog
Changes made to the position flag are not saved until you click OK in the Flag dialog
("Accessing the Flag dialog
Description
Control used to set flag position
box" on page 17), click Setup>Flag. The Flag
box" on page 24), select Name or EID to
box" on page 24).
Local port operation 24
