Accessing the Commands dialog box

From the Main dialog box
Commands dialog box appears.
NOTE:
a password, see Setting password protection (on page 29).

Running system diagnostics

Clicking Run Diagnostics
board functions subsystems (memory, intra-board communications, HP KVM Server Console Switch G2
control, and the video channels) for each system controller.
Test
Memory Test
Firmware CRCs
Comm Interfaces
Switch Controller
Local Video
Online IAs
Offline IAs
Suspect IAs
("Accessing the Main dialog
The Log Out button is only active if a password is set. For more information on setting
("Activating Run
Diagnostics" on page 39) runs a command to check the main
Description
Reports the condition of the main board RAM. This indicator displays the results of
the memory tests performed at system reboot.
Validates the current firmware images stored in the system FLASH by comparing a
CRC value on each image and comparing those results to the expected values.
Verifies the intra-board communication subsystems are accessible and functional by
querying the communications controller and performing basic register level tests.
Verifies the switch matrix controller is accessible and functional by querying the
switch matrix controller and performing basic register level tests.
Verifies that all the video channel subsystems are accessible, functional, and
performing basic register level tests.
Indicates the total number of currently connected and powered interface adapters.
Indicates the number of interface adapters that have been connected successfully in
the past and are powered down.
Indicates the number of interface adapters that have been detected but are either
unavailable for connection or have dropped packets during the ping tests.
box" on page 17), click Commands. The
Local port operation 38
