Secure the console switch to the rails, using four M-6 screws, two on each side.
5.
NOTE:
cage nuts.

Console switch components

Item
Description
1
Power cord connector
2
Power switch
3
Fan
4
Serial management connector
5
Console port A USB ports (keyboard/mouse only)
6
Console port A keyboard connector
7
Console port A video connector
8
Console port A mouse connector
9
RJ-45 tiering port (designated by the letter A)
10
Server connection ports 1–8
11
Server connection ports 9–16*
Some racks enable you to use four sheet metal screws in place of M-6 screws and
Installing the HP KVM Server Console Switch G2 11
