37. Input Select (Command : x b)
To select input source for the Set.
Transmission
[x][b][ ][Set ID][ ][Data][Cr]
Data 20H : AV
40H : Component 1
41H : Component 2
60H : RGB (PC)
90H : HDMI/DVI (DTV)
A0H : HDMI/DVI (PC)
Acknowledgement
[b][ ][Set ID][ ][OK][Data][x]
Data 20H : AV
40H : Component 1
41H : Component 2
60H : RGB (PC)
90H : HDMI/DVI (DTV)
A0H : HDMI/DVI (PC)
IR Codes
Use this method to connect your wired remote control port on the monitor.
Remote Control IR Code
Output Wave
●
Single pulse, modulated with 37.9KHz signal at 455kHz
●
Carrier Frequency
◦
◦
68
Appendix C Controlling the Multiple Product
FCAR = 1/Tc=fosc/12
Duty Ratio = T1/Tc = 1/3
ENWW
