4.
After installing the speakers, connect the input terminal with a proper color match.
Figure 3-8
Rotating to the Portrait Position (Select Models)
When installing the monitor in the portrait position, rotate it clockwise based on its front. The monitor
can be rotated in only one direction.
NOTE:
The monitor cannot be rotated if it is installed on the stand.
Figure 3-9
Installing Portrait
NOTE:
The power indicator LED orientation is on the bottom right corner in landscape position and
on the bottom left corner when rotated to portrait position.
ENWW
Connecting to the Input Terminal
Rotating to the Portrait Position (Select Models)
7
