3
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
Installing the Stand (Sold Separately)
1.
Remove the six screws (1), monitor stand (2) and cable management clip (3) from the box.
NOTE:
secure and hide cables from the front view of the monitor.
Figure 3-1
2.
Place a soft cloth on the table and place the product with the screen facing downward. Connect
the stand as shown in the following illustrations.
Figure 3-2
4
Chapter 3 Setting Up the Monitor
The LD4200tm stand uses six M4 x 12mm screws. Use the cable management clip to
Stand Accessory Contents
Sliding the Stand Onto the Monitor
ENWW
