Installed DIMMs must be the same speed and either all registered or all unbuffered. For a list of supported
memory, call your service representative or visit the Intel Support website:
http://support.intel.com/support/motherboards/server/l440gx/compat.htm
CAUTION
Use extreme care when installing a DIMM. Applying too much pressure can damage the socket.
DIMMs are keyed and can be inserted in only one way.
Mixing dissimilar metals may cause later memory failures resulting in data corruption. Only install
DIMMs with gold-plated edge connectors in gold-plated sockets.
To install your memory:
1.
Open your server.
2.
Holding the DIMM only by its edges, remove it from its anti-static package.
3. Orient the DIMM so that the two notches in the bottom edge of the DIMM align with the keyed
socket.
4.
Insert the bottom edge of the DIMM into the socket, and press down firmly on the DIMM until it
seats correctly.
5. Gently push the plastic ejector levers on the socket ends to the upright position.
6. Repeat the steps to install each DIMM.
7.
Ensure that no cables are protruding from the server chassis and then close the server.
8.
Connect all external cables and the power cord to the server.
9.
Turn on the monitor and then the server.
12 ISP2150 2U Rack Server Platform Quick Start Guide
