Configuring The Identity Manager Drivers And Templates - Novell BUSINESS CONTINUITY CLUSTERING 1.1 SP2 - ADMINISTRATION Administration Manual

6.1.1 Configuring the Identity Manager Drivers and Templates

1 Start your Internet browser and enter the URL for iManager.
The URL is http://server_ip_address/nps/iManager.html. Replace server_ip_address with the
IP address or DNS name of the server that has iManager and the Identity Manager
preconfigured templates for iManager installed.
2 Specify your username and password, specify the tree where you want to log in, then click
Login.
3 In the left column, click Identity Manager Utilities, then click the New Driver link.
4 Choose to place the new driver in a new driver set, then click Next.
Both the User Object Synchronization driver and the Cluster Resource Synchronization driver
can be added to the same driver set.
5 Specify the driver set name, context, and the server that the driver set will be associated with.
The server is the same server where you installed the Identity Manager engine and eDirectory
driver.
6 Choose to not create a new partition for the driver set, then click Next.
7 Choose to import a preconfigured driver from the server, select the Identity Manager
preconfigured template for cluster resource synchronization, then click Next.
The template name is
8 Fill in the values on the wizard page as prompted, then click Next.
Each field contains an example of the type of information that should go into the field.
Descriptions of the information required are also included with each field.
Driver name: Specify a unique name for this driver to identify its function. For example,
Cluster1SyncCluster2. If you use both preconfigured templates, you must specify different
driver names for each driver template.
Name of SSL Certificate: If you do not have an SSL certificate, leave this value set to the
default. The certificate is created later in the configuration process. See
Certificates" on page 70
In a single tree configuration, if you specify the SSL CertificateDNS certificate that was
created when you installed OES 2 on the Identity Manager node, you do not need to create
an additional SSL certificate later.
DNS name of other IDM node: Specify the DNS name or IP address of the Identity
Manager server in the other cluster.
Port number for this driver: If you have a business continuity cluster that consists of
three or four clusters, you must specify unique port numbers for each driver template set.
The default port number is 2002.
You must specify the same port number for the same template in the other cluster. For
example, if you specify 2003 as the port number for the resource synchronization
template, you must specify 2003 as the port number for the resource synchronization
template in the peer driver for the other cluster.
Full Distinguished Name (DN) of the cluster this driver services: For example,
Cluster1.siteA.Novell.
68 BCC 1.1 SP2: Administration Guide for NetWare 6.5 SP8
BCCClusterResourceSynchronization.XML
for instructions on creating SSL certificates.
.
"Creating SSL
