CARLO GAVAZZI WM23-96 - PROGRAMMING User Manual page 37

36
Page 9: VA L1, VA L2, VA L3
Page 10: AL1
Page 11: AL2
Page 12: W , PF , var , Hz
Page 13: W , PF , VA ,Hz
Page 14: W (max), PF (min)
Page 15: W dmd, VA dmd, r.t.
Page 16: W dmd (max), VA dmd (max)
Page 17: THD VL1, THD VL2, THD VL3
Page 17: THD AL1,THD AL2, THD AL3
Power supply specifications
AC voltage: 90 to 260 VDC/VAC, 18 to 60VDC/VAC, 24 VAC -
15+10% 50-60Hz, 48 VAC -15+10% 50-60Hz, 115VAC -
15+10% 50-60Hz, 230 VAC -15+10% 50-60Hz
General specifications
Operating temperature: 0 to +50°C (32 to 122°F)
(R.H. < 90% non condensing)
Storage temperature: -10 to +60°C (14 to 140°F)
(R.H. < 90% non consensing)
Installation category Cat. III (IEC 664)
Key-pad lock: by means of selector placed behind the display
or by means of contact (in case of presence of the module 3
input contacts)
Insulation: 4000 VRMS between all inputs/outputs to ground
Dielectric strength: 4000 VRMS for 1 minute
EMC
Emissions: EN50082-1 (class A) residential, commercial and
light industry environment
Immunity: EN 61000-6-2 (class A) industrial environment
Other standards
Safety: IEC 61010-1, EN 61010-1
Single Phase Connections
35
Technical Features
32 37
User's page
38
