24
Installation
Position of the slots and relevant modules
A

Available modules

Analogue output modules
Single analogue output
AO1050 (20mADC)
AO1051 (10VDC)
AO1052 (±5mADC)
AO1053 (±10mADC)
Dual analogue output
AO1026 (20mADC)
AO1027 (10VDC)
AO1028 (±5mADC)
AO1029 (±10mADC)
Useful information
19
B
PU
PS
22
C
IM
AO1054 (±20mADC)
AO1055 (±1VDC)
AO1056 (±5VDC)
AO1057 (±10VDC)
AO1030 (±20mADC)
AO1031 (±1VDC)
AO1032 (±5VDC)
AO1033 (±10VDC)
Power supply modules
31
D
26
