CARLO GAVAZZI WM23-96 - PROGRAMMING User Manual page 16

1.2..
S
..2.1
S 1.2..
..2.1
S 1.2..
..2.1
S 1.2..
..2.1
S
S 1.2..
..2.1
Alarm output
13
Programming
keys and confirm it with
LoA: % value of the zero of the
output range (0-20mA, 0-10V) that
is generated by the minimum
measured value (LoE). Select the
desired value by means of the
and keys and confirm it with
S
.
HiA: % value of the full scale of the
output range (0-20mA, 0-10V) that
is generated by the maximum
measured value (HiE).
Select the desired value by means
of the and
S
firm it with
See also "Example 1" in useful
information on page 18.
RS422/485 Serial port
address
Select "AddrESS" from the main
menu by means of the
keys; to enter the menu press
then set the desired address value
(from 1 to 255) by means of the
and keys and confirm it with
S
.
17
7
15
S
keys and con-
.
and
Useful information
.
