Uploading Files

The File Upload to Server page contains fields for uploading the software from the TFTP server to the device.
The image file can also be uploaded from the File Upload to Server page. To open the File Upload to Server
page, click System → File Management → File Upload in the tree view.
Figure 1-28. File Upload to Server
Firmware Upload — Indicates that the upload is for firmware. If Firmware Upload is selected, the Configura-
tion Upload fields are grayed out.
Configuration Upload — Indicates that the upload is for configuration files. If Configuration Upload is
selected, the Firmware Upload fields are grayed out.
Upload via TFTP — Enables initiating an upload via the TFTP server.
Upload via HTTP — Enables initiating an upload via the HTTP or HTTPS server. Only configuration files can
be uploaded using HTTP or HTTPS server.
Software Image Upload
TFTP Server IP Address — The TFTP Server IP Address to which the Image file is uploaded.
Destination File Name (1-160 Characters) — Indicates the Image file path to which the file is uploaded.
Configuration Upload
TFTP Server IP Address — The TFTP Server IP Address to which the Configuration file is uploaded.
41
