Dell 5324 - PowerConnect Switch User Manual Addendum page 35

UDP Port (1-65535) — The UDP port used to send notifications. The default is 162.
Filter Name — Includes or excludes SNMP filters.
Timeout (1-300) — The amount of time (seconds) the device waits before resending informs. The default is 15
seconds.
Retries (1-255) — The amount of times the device resends an inform request. The default is 3.
Remove Notification Recipient — When checked, removes selected notification recipients.
Adding a New Trap Recipients
1
Open Notification Recipients page.
2
Click Add.
The Add Notification Recipients page opens.
3
Define the relevant fields.
4
Click Apply Changes.
The notification recipient is added, and the device is updated.
Displaying Notification Recipients Tables
1
Open Notification Recipients page.
2
Click Show All.
The Notification Recipients Tables page opens.
