The following is an example of the CLI commands:
Console (config)# snmp-server enable traps
Console (config)# snmp-server trap authentication
Console# show snmp
Community-String Community-Access
---------------- -----------------
public
Community-String Group name
---------------- ----------
Traps are enabled.
Authentication-failure trap is enabled.
Version 1,2 notifications
Target Type
Address
------- ----
Version 3 notifications
Target Type
Address
-------- ----
System Contact: Robert
System Location: Marketing

Defining SNMP View Settings

SNMP Views provides access or blocks access to device features or feature aspects. For example, a view can be
defined which states that SNMP group A has read only (R/O) access to Multicast groups, while SNMP group B
has read-write (R/W) access to Multicast groups. Feature access is granted via the MIB name, or MIB Object ID.
The Up and Down arrows allow navigating through the MIB tree, and MIB branches.
read only
Community Version
--------- -------
Username Security
Level
--------- -------- ----
View name IP address
--------- ----------
view-1 All
IP address Type
----------
----
Udp Filter To
Port name Sec
---- ------ ---
Udp Filter To
Port name Sec
------ ---
- -
Retries
-------
Retries
-------
17
