NetApp E Series Quick Install Manual

1
Before you begin
For warnings, refer to the printed Safety
Notices document.
For detailed installation instructions, refer to installation guide for the
E5400 Controller-Drive Tray and Related Drive Trays, and review
these instructions before beginning the installation.
ATTENTION Register the E-Series storage system – Before
you begin the installation, register your E-Series storage system
at support.netapp.com
controller-drive tray enclosure. Use of any other component serial
numbers (such as those for individual controllers or drive tray
enclosures) will not enable correct registration for the array.
Record the serial number of the integrated controller-drive tray
enclosure for later use. This serial number is required to initiate any
support request for your system.
If your array includes expansion drive trays as well as a controller-
drive tray, refer to the enclosure part numbers in your Sales Order.
Verify that you install the controllers in the controller-drive tray
enclosure, and not in a drive tray enclosure. (Controller-drive tray
enclosures do not inclue a "QS" designator in their part numbers.
Drive tray enclosure part numbers include a "QS" designator.)
E5460 controller-drive tray -- What you need for assembly:
1.1
• One four-unit (4U) -high E5460 controller-drive tray
• Two power cords
• Small Form-factor Pluggable (SFP) transceivers, one for each
of the host channel ports on the base controllers. Host Interface
Cards require additional devices appropriate to the interface.
• One cabinet mounting hardware kit, including:
– Two mounting rails (right and left assemblies)
– Eight M5 x 8 mm screws – Use six screws to secure the
mounting rails and two screws to secure the front of the
controller-drive tray to the cabinet.
– Two M4 x 8 mm screws – Use the screws to secure the rear
of the controller-drive tray to the mounting rails.
using the serial number for the integrated
