Basic Operations

Creating A New MeetingManager Project

The RMS CodeCrafter wizard creates project files that it uses in generating the NetLinx code you
need. To create a .CGP file:
1. From the Introductory page click New Project.
2. The next page is the Project Start page. Select your desired RMS application, AssetManager.
3. Either type or click Browse to select the location of your integrated file.
While it is not necessary to have either an .AXS or .AWP file to use the RMS
CodeCrafter wizard, it is advisable. The integrated file will populate several fields
throughout the wizard that you will need to otherwise enter manually.
4. Click Next.
the desired file and click Next.
i!-ConnectLinx Options that apply.
5. Select your i!-ConnectLinx Options:
6. Define the Room Name, Location, Owner.
7. Click the radio button to select one of the following Scheduling Displays:
8. Click Next. The next page is RMS Server Address page.
9. Type the R.M.S. Server Address in the field provided or leave blank to use the default.
10. Click Next. The next page is RMS Virtual and Socket Device Definitions page.
11. Type all D:P:S fields that apply.
12. Click Next. The next page is Scheduling: Main Panels page.
13. To add a panel, click Add Panel and open the Add/Edit Main Panel window. To edit a panel,
select the panel from the list and click Edit Panel to open the Add/Edit Main Panel window.
14. Once you have added all of your main panels, click Next. If you selected either Main and
Welcome Panels or Welcome panels only in step 7 the next page is Scheduling: Welcome
Panels page. Otherwise it is Named NetLinx Devices page.
66
If NetLinx Studio workspace file (.APW) is selected as the integrated file:
a. From the list of NetLinx code files listed in the Code File Selection page, click on
If NetLinx Studio workspace file (.APW) was not selected as the integrated file:
b. The next page is Scheduling and i!-ConnectLinx options page. Check all
Support pre-meeting presets?
Monitor source usage?
Using multiple display devices?
Main and welcome panels
Welcome panels only
No scheduling display
Main and welcome panels or Welcome panels only selected:
