5-Port Gigabit Ethernet SPA Overview

5-Port Gigabit Ethernet SPA LEDs

The 5-Port Gigabit Ethernet SPA has two types of LEDs: an A/L LED for each individual port and a
STATUS LED for the SPA, as shown in

Figure 2-13 5-Port Gigabit Ethernet SPA Faceplate

1
Table 2-17

Table 2-17 5-Port Gigabit Ethernet SPA LEDs

LED Label
A/L
STATUS

5-Port Gigabit Ethernet SPA Cables and Connectors

The 5-Port Gigabit Ethernet SPA has five electrical connectors that support SFP modules. Each port can
send and receive traffic using cabling appropriate for the SFP module inserted.

SFP Module Connections

The small form-factor pluggable (SFP) module is an input/output (I/O) device that plugs into the Gigabit
Ethernet ports on the 5-Port Gigabit Ethernet SPA, linking the port with a fiber-optic network.
The 5-Port Gigabit Ethernet SPA accepts only the SFP modules listed as supported in this document. An
Note
SFP module check is run every time an SFP module is inserted into the 5-Port Gigabit Ethernet SPA, and
only SFP modules that pass this check can be used by the 5-Port Gigabit Ethernet SPA.
SFP modules exist for technologies other than Gigabit Ethernet and for products other than the 5-Port
Gigabit Ethernet SPA. However, the information in this document pertains only to SFP modules that plug
into the 5-Port Gigabit Ethernet SPA ports.
Cisco 12000 Series Router SIP and SPA Hardware Installation Guide
2-20
1
A/L (Active/Link) LED
describes the 5-Port Gigabit Ethernet SPA LEDs.
Color
Off
Green
Amber
Off
Green
Amber
Chapter 2 Overview: Cisco 12000 Series Router Shared Port Adapters
Figure 2-13.
2 STATUS LED
State Meaning
Off Port is not enabled.
On Port is enabled and the link is up.
On Port is enabled and the link is down.
Off SPA power is off.
On SPA is ready and operational.
On SPA power is on and good, and the SPA is being configured.
Release 12.0(32)SY1, OL-8831-01, Rev. G6, July 19, 2007
