BENDIX EC-16 ANTILOCK CONTROLLER Manual page 19

SECTION III - INSPECTION FOR ILLUMINATED LEDs
START HERE
GO TO SECTION V
YES
"TESTING FOR POWER
TO THE EC-16 ™
CONTROLLER"
™
INSPECT THE EC-16 CONTROLLER FOR
PRESENCE OF ILLUMINATED LEDS AND RECORD
IS GREEN VOLT LED ILLUMINATED?
YES
IS GREEN LED FLASHING?
NO
ARE ANY RED LEDs ILLUMINATED?
YES
NOTE AND RECORD
THE CONDITION OF
ALL RED LEDs
GO TO SECTION IV "INSPECTION
FOR ILLUMINATED LEDs"
NO
NO
ARE ANY RED
LEDs
ILLUMINATED?
YES
REPLACE THE EC-16 ™
CONTROLLER
GO TO SECTION IX "TESTING FOR FALSE
NO
FAILURE INDICATION - CAUSED BY
WHEEL SPEED COMPONENTS"
™
EC-16 CONTROLLER
DIAGNOSTIC DISPLAY
GO TO SECTION V
"TESTING FOR POWER
™
TO THE EC-16
CONTROLLER"
19
