BENDIX EC-16 ANTILOCK CONTROLLER Manual page 18

START HERE
NO
ARE ANY RED LEDs
ILLUMINATED?
YES
NOTE AND RECORD THE
CONDITION OF ALL RED
LEDs
GO TO SECTION IV
"INSPECTION FOR
ILLUMINATED LEDs"
GO TO SECTION VIII "TESTING FOR
FALSE FAILURE INDICATION -
CAUSED BY DASH LAMP RELAY"
18
SECTION II - INSPECTION FOR ILLUMINATED LEDs
INSPECT EC-16
CONTROLLER FOR
PRESENCE OF ILLUMINATED
LEDs AND RECORD
CHECK CLOSELY AND
NOTE IF GREEN, VLT
LED IS ILLUMINATED
YES (ON)
NO
IS GREEN LED FLASHING?
YES
GO TO SECTION V "TESTING
FOR POWER TO THE EC-16
CONTROLLER".
™
NO (OFF)
ARE ANY RED LEDs
ILLUMINATED?
NO
™
EC-16 ™ CONTROLLER
DIAGNOSTIC DISPLAY
YES
REPLACE THE EC-16
CONTROLLER
GO TO SECTION V
"TESTING FOR POWER
™
TO THE EC-16
CONTROLLER"
RED LEDs
GREEN VLT LED
™
