To remove all stroke attributes from a selected object, do one of the following:
•
Choose None from the Stroke Options pop-up menu in the Property inspector or the Stroke
Options pop-up window.
•
Click the Stroke Color box in either the Tools panel or the Property inspector and click the
Transparent button.
Creating custom strokes
You can use the Edit Stroke dialog box to change specific stroke characteristics.
The Edit Stroke dialog box has three tabs: Options, Shape, and Sensitivity.
The stroke preview at the bottom of each tab shows the current brush with the current settings.
The current pressure- and speed-sensitivity settings are reflected in the preview by a stroke that
tapers or fades or otherwise changes from left to right.
To open the Edit Stroke dialog box:
Do one of the following to open the Stroke Options pop-up window:
1
Choose Stroke Options from the Stroke Options pop-up menu in the Property inspector.
Choose Stroke Options from the Stroke Color box pop-up window in the Tools panel.
Click Advanced.
2
The Edit Stroke dialog box opens.
Working with strokes 107
