Site Information - Visonic POWERMAX REMOTE - PROGRAMMER SOFTWARE User Manual

6-2___________________________________________________________Data Details Tables

6.1 Site Information

Site Information displays general information about the site control panel.
Panel Site Name: The name of the site where the control panel is installed. By default this
field receives the name of the PowerMax model detected.
System Manager: The name of the System Manager responsible for programming the
control panel, responding to alarms and other events.
Address, City, State, and Zip Code: The complete address of the site.
Panel Phone No.
control panel.
Additional Information: Additional important information about the PowerMax site and
facilities.
Primary Phone No.
Primary Communication Mode
Secondary Phone No.
Remote Programmer dials this telephone number.
Secondary Communication Mode
Note: If there is no entry for the secondary telephone number, the PowerMax Remote
Programmer will dial the primary telephone only.
Note: If the dialed telephone number is engaged or there is no answer, the PowerMax
Remote Programmer will toggle between the primary telephone number and the secondary
telephone number.
Time Zone: Select from the list the relevant time zone.
Download Code: A 4-digit password, including letters A-F, used to enable downloading
data to the control panel.
Installer Code: A 4-digit password used to manage the control panel via the built-in
keypad.
∗
Available in PowerMax only.
∗∗
Available in PowerMax+ only.
∗
: The telephone number which the PC modem uses to connect to the
∗∗
: The first telephone number the control panel dials.
∗∗
: The mode used to call a primary telephone number.
∗∗
: When the primary telephone number is engaged, the PowerMax
∗∗
: The mode used to call a secondary telephone number.
