Paper source
Optional 250-sheet grain long
drawer
grain short
Optional 500-sheet grain long
drawer
grain short
Multipurpose feeder* grain long
grain short
* Due to label design characteristics, unacceptable feeding may be experienced from the multipurpose feeder.
Media specifications
Labels Thickness:
Smoothness:
* 50–150 Sheffield is optimal. This printer may support labels with smoothness of less than 50 Sheffield
such as coated paper, polyester, vinyl, or other synthetic facestock paper. Using media higher than 200
Sheffield could result in print quality degradation.
Card stock Weight:
Card stock and label guidelines
When printing on labels:
•
From the printer control panel, set Paper Type to Labels in the Paper Menu.
• Do not load labels together with paper or transparencies in the same paper tray. Combining print materials can
cause feeding problems.
•
Use only letter-, A4-, or legal-size full label sheets. Partial sheets may cause labels to peel off during printing, resulting
in a paper jam. Adhesive material may contaminate your printer. It could also void your printer and cartridge
warranties.
When printing on card stock:
• From the printer control panel, set Paper Type to Card Stock in the Paper Menu.
• Set Paper Weight to Card Stock Weight in the Paper Menu.
• Set Card Stock Weight to Normal or Heavy.
•
Do not use creased card stock. It may cause paper jams.
Grain direction Index Bristol
120 g/m
163 g/m
120 g/m
163 g/m
120 g/m
163 g/m
0.102–0.305 mm (0.004–0.012 in.)
50–300 Sheffield*
Up to 163 g/m
Up to 163 g/m
Up to 176 g/m
Printer specifications
Card stock
Tag
2 2
120 g/m
2 2
163 g/m
2 2
120 g/m
2 2
163 g/m
2 2
120 g/m
2 2
163 g/m
2
Index Bristol (90 lb)
2
Tag (100 lb)
2
Cover (65 lb)
102
Labels
Cover Paper
2
135 g/m 131 g/m
2
176 g/m
2
135 g/m 131 g/m
2
176 g/m
2
135 g/m 131 g/m
2
176 g/m
2
2
2
