6.6.1 MC-4 Get Unit Configuration

The HOST initiates by sending the GET_UNIT_CONFIG command packet:
SOP DLL DC CMD
F1 03 38
If the command is received without error, the MC-4 responds with the UNIT_CONFIG response packet:
SOP DLL DC CMD
F1 1E 91
DATA3 DATA4 DATA5
SW MJ SW MN PTCL MJ
REV REV REV
01 00 01
DATA10 DATA11 DATA12 DATA13 DATA14 DATA15 DATA16 DATA17
Time Time Time
Stamp Stamp Stamp
30 31 2f
0 1 /
DATA18 DATA19 DATA20 DATA21 DATA22 DATA23 DATA24 DATA25
Time Time Time
Stamp Stamp Stamp
20 31 37
(sp) 1 7
DATA26 DATA27
Serial Number (LSB) Serial Number
68
From the response packet we can see that the MC-4 is configured as:
Product Id is Lexicon MC-4
Software type COMPLETE
Software level of RELEASED
Software Version 1.00
Protocol Version 1.01
with 1007 parameters
and 25 effects,
and the software image was built
"01/07/27 17:07"
and has an internal serial number of
1128 (0x00 00 04 68)
AppDC EOP
00 F2
App DC DATA0 DATA1
Product Id SW TYPE
19 04
DATA6 DATA7 DATA8
PARAM PARAM
PTCL MN COUNT COUNT
REV (LSB) (MSB)
01 EF 03
Time Time Time
Stamp Stamp Stamp
30 37 2f
0 7 /
Time Time Time
Stamp Stamp Stamp
3A 30 37
: 0 7
DATA28
Serial Number
04 00
MC-4 Serial Communications Protocol
DATA2
SW LVL
04 00
DATA9
EFFECT
COUNT
23
Time Time
Stamp Stamp
32 37
2 7
Time Time
Stamp Stamp
00 00
DATA29 EOP
Serial Number (MSB)
00 F2
41
