6.3.23.2 Data Description
Value:
Data Type:
Max:
Min:
6.3.23.3 MC-4 Response
The MC-4 will assign the value from the packet to the front/back balance.
6.3.23.4 Data Validation
If a value is passed that exceeds the maximum value of that parameter, the MC-4 will ignore the
command and transmit a NAK command with an error code DC_INVALID_DATA.

6.3.24 MC-4 Set Active Effect by Id

This command requests the MC-4 to set the active effect to the value in this packet.
6.3.24.1 Command Packet Description
6.3.24.2 Data Description
EffectId:
Data Type:
Definition/Conversion: MC-4 Mode Ids
6.3.24.3 MC-4 Response
The MC-4 will load the desired effect.
6.3.24.4 Data Validation
If a value is passed that exceeds the maximum value of that parameter, the MC-4 will ignore the
command and transmit a NAK command with an error code DC_INVALID_DATA.

6.3.25 MC-4 Get Input Name by Id

This command is a request to MC-4 for the custom input name. MC-4 will respond with "Input Name
Packet".
6.3.25.1 Command Packet Description
Signed 8 bit integer (2's compliment)
+16 (0x10) (Full Front)
-16 (0xF0) (Full Back)
Application Header:
Command MC_CMD_SET_EFFECT
Data Count 1
Application Data:
Data[0] EffectId
Unsigned 8 bit integer
Application Header:
Command MC_CMD_GET_INPUT_NAME
Data Count 1
Application Data:
Data[0] InputId
MC-4 Serial Communications Protocol
0x43
0x01
nn
(Appendix E page 39)
0x47
0x01
nn
