Lexicon

MC-4 V1.00 Parameter Id List

The following table is for V1.00 reference only. These Parameter Id Values will change with S/W and
Protocol version changes. The MC-4 can always be queried for the correct Parameter Id numbers and
Parameter Definition Packets.
ParamId ParamId
Parameter Name
(dec) (hex)
0 0x0000
1 0x0001 PARAM.INPUTS
2 0x0002 PARAM.INPUTS.OFF
3 0x0003 PARAM.INPUTS.OFF.INPNAME
4 0x0004 PARAM.INPUTS.OFF.DIGIN
5 0x0005 PARAM.INPUTS.OFF.ANLGIN
6 0x0006 PARAM.INPUTS.OFF.ANLGTRIM
7 0x0007 PARAM.INPUTS.OFF.TRIMMODE
8 0x0008 PARAM.INPUTS.OFF.VIDEOIN
9 0x0009 PARAM.INPUTS.OFF.CH2EFFCT
10 0x000A PARAM.INPUTS.OFF.DDEFFCT
11 0x000B PARAM.INPUTS.OFF.DTSEFFCT
12 0x000C PARAM.INPUTS.OFF.MSRCMODE
13 0x000D PARAM.INPUTS.OFF.ANLGBYPASS
14 0x000E PARAM.INPUTS.OFF.TRIGGER1
15 0x000F PARAM.INPUTS.OFF.COMPONENTIN
16 0x0010 PARAM.INPUTS.OFF.SVID_16_9
17 0x0011 PARAM.INPUTS.OFF.SVIDOSD_4_3
18 0x0012 PARAM.INPUTS.OFF.COMPNTOSD
19 0x0013 PARAM.INPUTS.OFF._51_AD_EFFECT
20 0x0014 PARAM.INPUTS.DVD1
21 0x0015 PARAM.INPUTS.DVD1.INPNAME
22 0x0016 PARAM.INPUTS.DVD1.DIGIN
23 0x0017 PARAM.INPUTS.DVD1.ANLGIN
24 0x0018 PARAM.INPUTS.DVD1.ANLGTRIM
25 0x0019 PARAM.INPUTS.DVD1.TRIMMODE
26 0x001A PARAM.INPUTS.DVD1.VIDEOIN
27 0x001B PARAM.INPUTS.DVD1.CH2EFFCT
28 0x001C PARAM.INPUTS.DVD1.DDEFFCT
29 0x001D PARAM.INPUTS.DVD1.DTSEFFCT
30 0x001E PARAM.INPUTS.DVD1.MSRCMODE
31 0x001F PARAM.INPUTS.DVD1.ANLGBYPASS
32 0x0020 PARAM.INPUTS.DVD1.TRIGGER1
33 0x0021 PARAM.INPUTS.DVD1.COMPONENTIN
34 0x0022 PARAM.INPUTS.DVD1.SVID_16_9
35 0x0023 PARAM.INPUTS.DVD1.SVIDOSD_4_3
36 0x0024 PARAM.INPUTS.DVD1.COMPNTOSD
37 0x0025 PARAM.INPUTS.DVD1._51_AD_EFFECT
38 0x0026 PARAM.INPUTS.DVD2
MC-4 Serial Communications Protocol
43
