Display String:
Data Type:
Max Length:
6.3.10.3 MC-4 Response
The display string is sent to the OSD and Front Panel Display. The MC-4 will ACK when
completed with this command.
6.3.10.4 Data Validation:
If a string length exceeds the 40 character maximum, the string will be truncated before
displaying and the MC-4 will transmit a DC_NAK command with an error code
DC_INVALID_DATA.

6.3.11 MC-4 Get Parameter Definition by Id

Request to MC-4 for a Parameter Definition by Parameter Id. MC-4 will respond with "MC-4 Parameter
Definition Packet".
6.3.11.1 Command Packet Description
6.3.11.2 Data Description
ParamId:
Data Type:
Max Value:
6.3.11.3 Data Validation:
If the ParamId is not a valid Id, the MC-4 will respond with a NAK packet and error code
DC_ INVALID_PARAM_ID.
Null (0x00) terminated ASCII character string.
40 Characters.
Application Header:
Command MC_GET_PARAM_BY_ID
Data Count 2
Application Data:
Data[0] ParamId(LSB)
Data[1] ParamId(MSB)
Unsigned 16 bit Integer
Max Parameter Count as reported by the MC-4 Unit Configuration
Response Packet
MC-4 Serial Communications Protocol
0x35
0x02
nn
nn
(6.3.14.2 page 22).
