Lexicon MC-4 V1.00 - SERIAL PROTOCOL DEFINITIONS REV 1-6 Manual page 28

Lexicon
6.3.20.2 System Status Response Packet
6.3.20.3 Data Description
System Volume:
Data Type:
Max:
Min:
Current Input:
Data Type:
Definition/Conversion: MC-4 Input Ids
Current Effect Id:
Data Type:
Definition/Conversion: MC-4 Mode Ids
Current Input Sample Rate:
Data Type:
Application Header:
Command MC_RESP_SYS_STATUS 0x94
Data Count 10
Application Data:
Data[0] System Volume
Data[1] Current Input
Data[2] Current Effect Id
Data[3] Current Input Sample Rate nn
Data[4] Current Input Format
Data[5] Mute Active
Data[6] Effect Bypass
Data[7] Left/Right Balance
Data[8] Front/Back Balance
Data[9] Video Sync
Signed 8 bit integer (2's compliment)
+12 (0x0C) (12 dB)
-80 (0xB0) (-80 dB)
Unsigned 8 bit integer
Unsigned 8 bit integer
Unsigned 8 bit integer.
SAMPLE RATE
RATE_UNKNOWN
RATE_44
RATE_48
RATE_88
RATE_96
MC-4 Serial Communications Protocol
0x0A
nn
nn
nn
nn
nn
nn
nn
nn
nn
(Appendix F page 40)
(Appendix E page 39)
0
1
2
3
4
28
