Appendix C: MC-4 IR Codes

KEY FUNCTION
1 STANDBY
2 ON
3 FP
4 BLUE
5 LIGHT
6 OSD
7 STAT
8 UP_ARROW
9 LEFT_ARROW_DONE
10 Reserved
11 RIGHT_ARROW_SELECT
12 DN_ARROW
13 MUTE
14 MODE_INCR
15 MODE_DECR
16 VOL_INCR
17 VOL_DECR
18 MAIN_DVD_1
19 MAIN_DVD_2
20 MAIN_SAT
21 MAIN_VCR
22 MAIN_TV
23 MAIN_CD
24 MAIN_TUNER
25 MAIN_AUX
26 Reserved
27 Reserved
28 Reserved
29 Reserved
30 LOGIC7_LOGO
31 DOLBY_LOGO
32 DTS_LOGO
33 THX_LOGO
34 MUSIC
35 TV_L_LOGO
36 MAIN_TOGGLE_7_5
37 MAIN_2_CHANNEL
38 Reserved
39 Reserved
40 Reserved
41 Reserved
DATA
FUNCTION
(hex)
0x19 MAIN_OFF
0x18 Reserved
0x04 BAL_CENTER
0x03 TRIGGER1_OFF
None LIGHT
0x02 TRIGGER1_ON
0x1C INPUT_STATUS
0x01 FADER_FRONT
0x0A BAL_LEFT
Reserved
0x08 BAL_RIGHT
0x1D FADER_REAR
0x15 FULL_MUTE
0x1A VOL_N15DB
0x1B VOL_N30DB
0x17 VOL_03DB
0x16 VOL_N03DB
0x20 BASS_INCR
0x21 TREBLE_INCR
0x24 TILT_INCR
0x25 LOUDNESS_ON
0x23 BASS_DECR
0x26 TREBLE_DECR
0x2A TILT_DECR
0x2B LOUDNESS_OFF
Reserved
Reserved
Reserved
Reserved
0x0D PANORAMA
0x0C DOLBY_EX_TOGGLE
0x0F DTS_ES_TOGGLE
0x0B THX_EX_TOGGLE
0x10 MUSIC_SURROUND
0x0E MONO_LOGIC
0x1E MAIN_SRC_MODE
0x1F BYPASS
Reserved
Reserved
Reserved
Reserved
MC-4 Serial Communications Protocol
DATA
FUNCTION
(hex)
0x99 ZONE_OFF
0x98 Reserved
0x84 ZONE_BAL_CENTER
0x83 EQ_OFF
None LIGHT
0x82 Reserved
0x9C ZONE_STATUS
0x81 SUB_ADJ_INCR
0x8A ZONE_BAL_LEFT
Reserved
0x88 ZONE_BAL_RIGHT
0x9D SUB_ADJ_DECR
0x95 ZONE_MUTE
0x9A ZONE_VOL_N15DB
0x9B ZONE_VOL_N30DB
0x97 ZONE_VOL_INCR
0x96 ZONE_VOL_DECR
0xA0 ZONE_DVD_1
0xA1 ZONE_DVD_2
0xA4 ZONE_SAT
0xA5 ZONE_VCR
0xA3 ZONE_TV
0xA6 ZONE_CD
0xAA ZONE_TUNER
0xAB ZONE_AUX
Reserved
Reserved
Reserved
Reserved
0x8D Reserved
0x8C Reserved
0x8F Reserved
0x8B Reserved
0x90 Reserved
0x8E Reserved
0x9E Reserved
0x9F Reserved
Reserved
Reserved
Reserved
Reserved
DATA
(hex)
0x59
0x58
0x44
0x43
None
0x42
0x5C
0x41
0x4A
0x48
0x5D
0x55
0x5A
0x5B
0x57
0x56
0x60
0x61
0x64
0x65
0x63
0x66
0x6A
0x6B
0x4D
0x4C
0x4F
0x4B
0x50
0x4E
0x5E
0x5F
