6.3.21.2 Data Description
Value:
Data Type:
Max:
Min:
6.3.21.3 MC-4 Response
The MC-4 will assign the value from the packet to the system volume.
6.3.21.4 Data Validation
If a value is passed that exceeds the maximum value of that parameter, the MC-4 will ignore the
command and transmit a DC_NAK command with an error code DC_INVALID_DATA.

6.3.22 MC-4 Set Main Balance

Commands MC-4 to set the system balance to the value in this packet.
6.3.22.1 Command Packet Description
Application Header:
Command
Data Count
Application Data:
Data[0]
6.3.22.2 Data Description
Value:
Data Type:
Max:
Min:
6.3.22.3 MC-4 Response
The MC-4 will assign the value from the packet to the system balance.
6.3.22.4 Data Validation
If a value is passed that exceeds the maximum value of that parameter, the MC-4 will ignore the
command and transmit a DC_NAK command with an error code DC_INVALID_DATA.

6.3.23 MC-4 Set Fader

Commands MC-4 to set the front/back balance to the value in this packet.
6.3.23.1 Packet Description
Application Header:
Command
Data Count
Application Data:
Data[0]
Signed 8 bit integer (2's compliment)
+12 (0x0C) (12 dB)
-80 (0xB0) (-80 dB)
DC_CMD_SET_SYS_BALANCE
1
Value
Signed 8 bit integer (2's compliment)
+16 (0x10) (Full Right)
-16 (0xF0) (Full Left)
MC_CMD_SET_FRONT_BACK_BALANCE
1
Value
MC-4 Serial Communications Protocol
0x41
0x01
nn
0x42
0x01
nn
