6.3.21 MC-4 Set System Volume

This command is a request to the MC-4 to set the system volume with the value in this packet.
6.3.21.1 Command Packet Description
Unsigned 8 bit integer.
DATA STREAM TYPE
DATA_TYPE_UNKNOWN
DATA_TYPE_BYPASS
DATA_TYPE_ANALOG
DATA_TYPE_PCM
DATA_TYPE_DD
DATA_TYPE_DTS
DATA_TYPE_NOISE
Boolean.
System Mute is Active
System is unmuted.
Boolean
Effect Bypass is Active
Effect Bypass is Inactive
Signed 8 bit integer (2's compliment)
16 (0x10) (Full Right)
-16 (0xF0) (Full Left)
Signed 8 bit integer (2's compliment)
16 (0x10) (Full Front)
-16 (0xF0) (Full Back)
Boolean.
MC-4 has detected Video Sync for current video input
MC-4 can not detect Video Sync for the current video input
Application Header:
Command MC_CMD_SET_SYS_VOLUME
Data Count 1
Application Data:
Data[0] Value
MC-4 Serial Communications Protocol
0
1
2
3
4
5
6
0x40
0x01
nn
29
