PR Lighting AQUA XLED 6019 User Manual

Hide thumbs Also See for AQUA XLED 6019:
Table of Contents

Advertisement

Quick Links

Download this manual
AQUA XLED 6019
PR-8229
This product manual contains important information about the safe installation and use of this product. Please
read and follow these instructions carefully before installing and using the product and keep this manual in a
safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA XLED 6019 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting AQUA XLED 6019

Summary of Contents for PR Lighting AQUA XLED 6019

  • Page 1 AQUA XLED 6019 PR-8229 This product manual contains important information about the safe installation and use of this product. Please read and follow these instructions carefully before installing and using the product and keep this manual in a safe place for future reference.

  • Page 2: Table Of Contents

    Any damage caused by improper use will not be assumed by the manufacturer and / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Index 1. Safetyand Warnings

    NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Goggles Warning Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector. Should there be any damage ●...

  • Page 4: Instructions

    There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord ● supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure a projector is disconnected from power ●...

  • Page 5: Appearance

    lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. TROUBLESHOOTING ● PROBLEM ACTION Check the fuse on the power socket.  A projector doesn’t switch on Check the light source.  The lamp is on but a projector doesn’t respond to Make sure that the fixture’s start address is right ...
  • Page 6 Remarks: 1. The distance between the top of the mounting bar and the top of the head; 2. The Distance between the top of the feet and the top the head; 3. The head’s rotating diameter( the minimum distance between neighboring projectors on the truss) Warning: For safety, please run the safety cord through...
  • Page 7 Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each projector be connected with power separately so that they may be individually switched on and off. Note: If projectors are connected in series, please connect POWERIN port of the 1 projector with the Power Mains, then connect its POWER OUT with POWER IN of the 2 projector, and so on till all fixtures are connected.

  • Page 8: Setupand Configuration

    5. SETUPAND CONFIGURATION FRONT PANELOPERATION ● To browse through or change the function setup, press button ENTER more than 3 seconds to unlock the screen (after power-on, press ENTER key). Then press MENU key to enter the menus. Each main menu has its own sub-menu. Each menu stands for specified function of the fixture, please see the details in the following SECTION 6- OPERATION MENU: 1.

  • Page 9: Operation Menu

    6. OPERATION MENU Menu Sub-menu Options/Values Options/Values DMX address 026CH 098CH DMX channel 251CH 321CH Artnet Control mode DMX+Artnet sACN DMX+sACN Linear Square Dimmer mode I-Square S-Shape Slow Dimmer speed Fast Config. 400HZ 1200HZ 2000HZ 4000HZ LED refresh rate 6000HZ 8000HZ 16000HZ 24000HZ...
  • Page 10 Lime 000-255 Auto Fan mode Quiet Full speed Pan inversion NO/YES Tilt inversion NO/YES PAN 0~255 Calibration Tilt 0~255 System calibration Focus 0~255 Rotate 0~255 Chinese Languages English Display inversion Signal lockup NO/YES Display lockup NO/YES Factory defaults NO/YES Ethernet 002.000.000.001 255.000.000.000 Ethernet...

  • Page 11: Dmx Protocol

    7. DMX PROTOCOL 26 channel mode (DMX,ArtNet,sACN) DMX channel Value Function Description 0-255 0°-540° 0-255 Pan Fine 16bit adjustable 0-255 Tilt 0°-205° 0-255 Tilt Fine 16bit adjustable 0-255 Pan &Tilt speed From fast to slow 0-255 Zoom 3°-45° 0-255 zoom Fine 0-255 lens rotation 0°-540°...
  • Page 12 156-205 strobe macro 1 From slow to fast（from dark to bright） 206-255 strobe macro 2 From slow to fast（from dark to bright） 14CH 0-255 60W red （from dark to bright） 15CH 0-255 60W green （from dark to bright） 16CH 0-255 60W blue （from dark to bright）...
  • Page 13 81-95 macro6 96-110 macro7 111-125 macro8 126-140 macro9 141-155 macro10 156-170 macro11 171-185 macro12 186-200 macro13 201-215 macro14 216-230 macro15 231-245 macro16 246-255 Macro loop macro1-macro16 loop 0-127 clockwise rotation from slow to fast 24CH 0-255 Secondary LED macro speed 128-255anti-clockwise rotation from slow to fast 0-255 Color macro...
  • Page 14 151-155 Dark amber R=255,G=166,B=000,L=000 156-160 Orange R=255,G=122,B=000,L=000 161-165 Light rose R=255,G=141,B=031,L=000 166-170 Medium rose R=217,G=130,B=028,L=000 171-175 Dark pink R=255,G=109,B=033,L=000 176-180 Magenta R=255,G=020,B=015,L=000 181-185 peacock blue R=051,G=255,B=051,L=000 186-190 Steelblue R=206,G=255,B=056,L=000 191-195 Light blue R=074,G=255,B=082,L=000 196-200 Dark blue R=000,G=186,B=255,L=000 201-205 Leave green R=206,G=255,B=000,L=000 206-210 Dark green...
  • Page 15 98 channel mode （DMX，ARTNET,SACN,D+A,D+S, while mixing mode, channel 1-22 controlled by DMX) DMX channel Value Function Description 0-255 0°-540° 0-255 Pan Fine 16bit adjustable 0-255 Tilt 0°-205° 0-255 Tilt Fine 16bit adjustable 0-255 Pan &Tilt speed From fast to slow 0-255 Zoom 3°-45°...
  • Page 16 36-50 macro3 51-65 macro4 66-80 macro5 81-95 macro6 96-110 macro7 111-125 macro8 126-140 macro9 141-155 macro10 156-170 macro11 171-185 macro12 186-200 macro13 201-215 macro14 216-230 macro15 231-245 macro16 246-255 Macro loop macro1-macro16 loop 0-127 clockwise rotation from slow to fast 17CH 0-255 Secondary LED macro speed...
  • Page 17 91-95 Dark amber R=255,G=065,B=000,L=000 96-100 sunrise red R=255,G=083,B=002,L=000 101-105 Light pink R=255,G=112,B=000,L=141 106-110 Medium pink R=255,G=087,B=000,L=107 111-115 Carnation pink R=255,G=107,B=000,L=130 116-120 Lavender blue R=243,G=117,B=039,L=197 121-125 Sky blue R=000,G=255,B=135,L=000 126-130 Turquoise blue R=000,G=194,B=130,L=000 131-135 Dark yellow R=041,G=219,B=000,L=000 136-140 Spring yellow R=245,G=202,B=000,L=000 141-145 Light amber R=237,G=163,B=000,L=000...
  • Page 18 52-68 6500K R=255,G=129,B=081,L=255 69-85 6000K R=255,G=121,B=073,L=255 86-102 5600K R=255,G=106,B=066,L=255 103-119 5000K R=255,G=090,B=055,L=255 120-136 4500K R=255,G=071,B=043,L=255 137-153 4000K R=255,G=055,B=034,L=255 154-170 3500K R=255,G=029,B=024,L=255 171-187 3200K R=255,G=011,B=019,L=255 188-204 3000K R=255,G=004,B=016,L=255 205-221 2700K R=255,G=000,B=009,L=203 222-238 2500K R=255,G=000,B=004,L=172 239-255 2000K R=255,G=000,B=000,L=105 23CH 0-255 LED1 Red Dark to light 24CH 0-255...
  • Page 19 128-192 Continual clockwise rotation From slow to fast 193-255 Continual anti- clockwise rotation From slow to fast 0-255 Reset 0-200 201-215 Effect motor reset Stay at the value more than 5s 216-230 Pan and Tilt motor reset Stay at the value more than 5s 231-245 All reset Stay at the value more than 5s...
  • Page 20 216-230 macro15 231-245 macro16 246-255 Macro loop macro1-macro16 loop 0-127 clockwise rotation from slow to fast 18CH 0-255 60W LED macro speed 128-255anti-clockwise rotation from slow to fast 0-255 Color macro 0-45 Cyan 46-50 R=000,G=255,B=255,L=000 Yellow 51-55 R=255,G=255,B=000,L=000 Purple 56-60 R=255,G=000,B=255,L=000 claybank 61-65...
  • Page 21 196-200 dark blue R=000,G=186,B=255,L=000 201-205 Leave green R=206,G=255,B=000,L=000 206-210 dark green R=084,G=255,B=013,L=000 211-215 amaranth R=227,G=041,B=056,L=000 216-220 Dark golden amber R=255,G=058,B=000,L=000 221-225 light lavender R=255,G=197,B=061,L=000 226-230 Primary green R=077,G=255,B=000,L=000 231-235 sapphirine R=000,G=255,B=087,L=000 236-240 apricot R=255,G=143,B=013,L=000 241-245 Light golden R=253,G=171,B=026,L=000 246-250 Dark orange R=222,G=084,B=000,L=000 251-255 Fire red...
  • Page 22 24CH 0-255 LED20 Red Dark to light 25CH 0-255 LED20 Green Dark to light 26CH 0-255 LED20 Blue Dark to light ........ 249CH 0-255 LED95 Red Dark to light 250CH 0-255 LED95 Green Dark to light 251CH 0-255...
  • Page 23 6-55 Synchronized strobe From slow to fast 56-105 Pulse strobe From slow to fast 106-155 Random strobe From slow to fast 156-205 strobe macro 1 From slow to fast（from dark to bright） 206-255 strobe macro 2 From slow to fast（from dark to bright） 13CH 0-255 All secondary LED dimmer...
  • Page 24 146-150 straw color R=230,G=160,B=000,L=069 151-155 dark amber R=255,G=166,B=000,L=000 156-160 orange R=255,G=122,B=000,L=000 161-165 Light rose R=255,G=141,B=031,L=000 166-170 Medium rose R=217,G=130,B=028,L=000 171-175 Dark pink R=255,G=109,B=033,L=000 176-180 Magenta R=255,G=020,B=015,L=000 181-185 peacock blue R=051,G=255,B=051,L=000 186-190 Steelblue R=206,G=255,B=056,L=000 191-195 light blue R=074,G=255,B=082,L=000 196-200 dark blue R=000,G=186,B=255,L=000 201-205 Leave green...

  • Page 25: Errors

    239-255 2000K R=255,G=000,B=000,L=105 18CH 0-255 LED1 Red Dark to light 19CH 0-255 LED1 Green Dark to light 20CH 0-255 LED1 Blue Dark to light 21CH 0-255 LED1 Limon Dark to light ........

  • Page 26: Technicaldata

    9. TECHNICALDATA ELECTRIC PARAMETERS Rate voltage :100V~240VAC，50/60Hz Input power :1425W@110V 1400W @ 220VAC Nominal current: 6A@ 220VAC Power factor : PF>0.9 THE SPECIFICATIONS OFTHE LIGHT SOURCE RGBL LED 19X60W RGB LED 76X0.5W Rated life: 50000hrs OPTICS CRI 80+ θ Beam angle ( 1/2 Peak) ：4.5°...
  • Page 27 WORKING TEMPERATURE ﹣20°- 40° SIZES( unit: mm) Base installation( unit: mm) Photometric...

  • Page 28: Circuit Diagram

    10. CIRCUIT DIAGRAM...
  • Page 30 PR LIGHTING LTD. 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320021676 Old Version:20241211 New Version:20250226...
