XLED 1537
PR-8120L
This product manual contains important information about the safe installation and use of this product. Please
read and follow these instructions carefully before installing and using the product and keep this manual in a
safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
Advertisement
Table of Contents
Related Manuals for PR Lighting XLED 1537
Summary of Contents for PR Lighting XLED 1537
- Page 1 XLED 1537 PR-8120L This product manual contains important information about the safe installation and use of this product. Please read and follow these instructions carefully before installing and using the product and keep this manual in a safe place for future reference.
- Page 2 Any damage caused by improper use will not be assumed by the manufacturer and / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.
-
Page 3: Safety And Warnings
SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Goggles Protective High Warning Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector. - Page 4 There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●...
- Page 5 Remove dust or grease from the lenses. The project image appears to have a halo Carefully clean the lamp, optical lenses and other components. Check if lens are in good condition(not cracked) Heavily Defective Beam Clean dust or grease on the lens. 3.
- Page 6 WARNING: The projector MUST be lifted or carried by the HANDLES instead of clamps. ● .For safety the safety cord should afford 10 times the Projector’s weight. ● POWER CONNECTION ● Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before power connection, please ensure the power supplied must match what the nameplate says.
- Page 7 In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.
-
Page 8: Master/Slave Mode
The setup of it is below: Enter into the projector’s menu. Select the menu “Config Settings” via the bottoms of UP and DOWN Select DMX control Mode---- Wireless First (Note: do not select XLR ONLY),then wireless indication in the front panel will be on, meaning wireless control function is activated. Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. - Page 9 Extended Mode View Channel 001 Strobe XLR Only XLR First Wireless Only Signal Select Wireless First Wireless → XLR Normal timeout Loss of DMX Hold Last Off Delay Display Mode On Always Invert OFF Disp. Config Display Inv. Invert ON English Language Set Chinese...
-
Page 10: Dmx Protocol
************ RDM Device Label RDM Label ANSI E1.20 RDM Basic Fan XXX×/√ Fan Status Head Fan XXX×/√ Strobe XXX Manual Ctrl Dimmer XXX Service … Factory Test Change Mode? Confirm/Cancel DMX Mode Preset Memory Change Mode? Confirm/Cancel User Memory 1 Change Mode? Master Mode User Memory 2... - Page 11 001-255 Fading rainbow effect from slow to fast No colors Colors 001-255 255 colors Area 1 Red 000-255 Linear adjustment(0-100%) Area 1 Green 000-255 Linear adjustment(0-100%) Area 1 Blue 000-255 Linear adjustment(0-100%) Area 1 White 000-255 Linear adjustment(0-100%) Area 2 Red 000-255 Linear adjustment(0-100%) Area 2 Green...
- Page 12 000-255 Front color-blue Front blue color dimmer (0-100%) 000-255 Front color-white Front white color dimmer (0-100%) 000-255 Back color-red Back red color dimmer (0-100%) 000-255 Back color-green Back green color dimmer (0-100%) 000-255 Back color-red Back blue color dimmer (0-100%) 000-255 Back color-white Back white color dimmer (0-100%)
-
Page 13: Technical Data
Note：Priority sequences of the DMX channel: Animation > Color temperature > Color Macro > Color effect > single color dimmer of RGBW 8. ERROR MESSAGES AND THE CORRECTIONS The software control system can detect any errors during reset. If the screen shows , please use ENTER key to see the errors displayed ERRORS... - Page 14 COLOR TEMPERATURE Color temperature linearly adjustable(2700K ~10000K) STROBE Electronic strobe:0.3-25 F.P.S. BEAM ANGLE Beam Angle(1/2 peak) θ : 13° ~52° 1/10 Peak) θ: 27° ~70° Field Angle( CONTROL DMX512, 5 pins interfaces RDM protocol 25 in short mode,29channels in standard mode, and 41 channels in extended mode Master/Salve Synchronous Control Mode Static scene Standalone mode...
-
Page 15: Light Output
LIGHT OUTPUT 52°Lux 13°Lux DISTANCE (m) 13°DIAMETER(m) 0 52°DIAMETER(m) 10. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM ●... -
Page 16: Component Order Codes
11. COMPONENT ORDER CODES... -
Page 17: Code Number
NAME CODE NUMBER REMARKS FIRST LENS 070070052 SECONDARY LENS 070070053 MOTOR 030040162 MOTOR 030040174 030060118 PWM SPEED ADJUSTING 030060074C... - Page 18 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N:320021038A Old Version: 20210520 New Version:20220219...
