XL 1200
PR-2910/PR-2910M
This product manual contains important information about the safe installation and use of this
projector. Please read and follow these instructions carefully and keep this manual in a safe place
for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XL 1200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XL 1200

Summary of Contents for PR Lighting XL 1200

  • Page 1 XL 1200 PR-2910/PR-2910M This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
  • Page 2 INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU ERROR MESSAGES REPLACING GOBOS DMX PROTOCOL LED INDICATION MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING...

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.

  • Page 4: Install The Projector

    Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning. Always ensure that the structure that you are going to mount the projector is secure and is strong enough to support a weight of XL 1200.

  • Page 5: Power Supply-Mains

    Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. The body of the plug is not connected in any way. The XL 1200 accepts digital control signals in protocol DMX512 (1990).

  • Page 6: Dmx Terminator

    TO SET THE DMX START ADDRESS Each XL 1200 must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller.
  • Page 7 Press button UP and DOWN, you can set the address; Press button ENTER to confirm; In the same time. The GREEN LED will flash one time. It means the setting has been enabled. Press button FUNC, it will return to the upper menu one by one. 7/26...

  • Page 8: Operation Menu

    Hold Last Value Fixture type= XL 1200 Config Settings Fixture type= XL 700 Fixture type= XL 575 Fixture type= XL 1200 FS Fixture type= Factory Settings Fixture type XL 1200 Wash (Press button (WARNING：Never change Fixture type= DOWN/UP/ENTER at the same...
  • Page 9 Dimmer Invert Iris Invert Iris Invert Iris Invert Zoom Invert Zoom Invert Zoom Invert CMY Invert CMY Invert CMY Invert CTO Invert CTO Invert CTO Invert Defaults Defaults Defaults Restore Defaults Display On Always Display Mode Display Off After Delay Display Invert Display Invert Display Invert...
  • Page 10 Pan and Tilt = Pan and Tilt XX ℃ Head Sensor= Head Sensor XX ℃ Display Board = Display Board X.X.X Driver Board 1 = Driver Board 1 X.X.X Driver Board 2 = Driver Board 2 X.X.X Driver Board 3 = Software Version Driver Board 3 X.X.X...

  • Page 11: Error Messages

    ERROR MESSAGES In the course of launch, XL 1200 examines automatically whether there are errors and if there are, it will display information as follows: Display Message Sensor Err S1-M1 Colour wheel (1# drive board motor 1) error Sensor Err S1-M2...

  • Page 12: Dmx Protocol

    DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode mode 000-010 Black 011-025 Open Strobe 026-225 Strobe speed from slow to fast 226-255 Open 000-007 Black Dimmer 008-255 Dimming from dark to light (0-100%) Dimmer Fine 000-255 Dimmer in 16 Bit precision 000-016 White 017-035...
  • Page 13 152-157 Rainbow rotation speed 5 158-163 Rainbow rotation speed 6 164-169 Rainbow rotation speed 7 170-175 Rainbow rotation speed 8 176-181 Rainbow rotation speed 9 182-187 Rainbow rotation speed 10 188-195 Stop in current position Rainbow reverse rotation speed 196-201 1(slowest) 202-207 Rainbow reverse rotation speed 2...
  • Page 14 208-210 Gobo 4 shake 1(slowest) 211-213 Gobo 4 shake 2 214-216 Gobo 4 shake 3 217-219 Gobo 4 shake 4（fastest） 220-222 Gobo 5 shake 1(slowest) 223-225 Gobo 5 shake 2 226-228 Gobo 5 shake 3 229-231 Gobo 5 shake 4（fastest） 232-234 Gobo 6 shake 1(slowest) 235-237...
  • Page 15 043-064 Gobo 2 065-085 Gobo 3 086-106 Gobo 4 107-127 Gobo 5 128-134 Rotation speed 1 (slowest) 135-142 Rotation speed 2 143-149 Rotation speed 3 150-156 Rotation speed 4 (fastest) 157-163 Reverse rotation speed 1 (slowest) 164-170 Reverse rotation speed 2 171-177 Reverse rotation speed 3 178-184...
  • Page 16 248-255 Rotation speed 8 (fastest) 000-020 White Effect Wheel 021-255 Wheel full into beam gradually 000-125 Rotation speed from slow to fast Effect Wheel 126-141 Stop in current position Rotation Reverse rotation speed from slow to 142-255 fast Focus 000-255 Linearly focusing Focus Fine 000-255...

  • Page 17: Led Indication

    LED INDICATION DMX signal OK Green No DMX signal Flash DMX signal error Yellow Setting the panel Blue Power Running self test mode Red/Green Green Reserved MAINTENANCE If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must be replaced.

  • Page 18: Troubleshooting

    TROUBLESHOOTING PROBLEM ACTION Check the fuse on the power socket. The projector doesn’t switch on Replace the lamp. The lamp comes on but the projector Make sure that the projector is correctly configurated. doesn’t respond to the controller Replace or repair the DMX cable. The projector only functions intermittently Make sure the fan is working and not dirty.

  • Page 19: Technical Data

    TECHNICAL DATA VOLTAGES: Electronical ballast（PR-2910）: 100V/120V/200V/220V/230V/240V AC，50/60Hz Magnetic ballast（PR-2910M）: 230V AC，50/60Hz Options: 200/220/240V AC，50/60Hz POWER CONSUMPTION: Electronical ballast（PR-2910）: 1500W@220V Magnetic ballast（PR-2910M）: 1600W@220V LAMP: PHILIPS MSR Gold 1200 SA/2 DE Colour Temperature 7500°K Socket SFc10-4，double ended Manufacturers Rated Lamp Life 750 Hours replacement OSRAM HMI 1200 W/S Colour Temperature...
  • Page 20 Frost linearly adjustable 0-100% EFFECT FILTERS: 1 interchangeable gobo effect wheel scrolling at variable speeds FOCUS: DMX controlled focus DIMMER: 0-100% linearly adjustable SHUTTER: Double shutter blades, 0.3~12 F.P.S Macros HEAD MOVEMENT: Pan 450º, Tilt 270º with auto position correction BEAM ANGLE: 12°～40°...
  • Page 21 See at below LIGHT OUTPUT: 40° （ lux ） 1850 34° （ lux ） 2690 12° （ lux ） 23250 5810 2580 1450 DISTANCE (m) 12° DIAMETER (m) 1.07 2.14 3.21 4.28 5.35 34° DIAMETER (m) 3.03 6.06 9.09 12.12 15.15 40°...
  • Page 22 22/26...
  • Page 23 23/26...

  • Page 24: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK POWER SUPPLY 190010098 MAINS FILTER 193020008 20A 115/250VAC THERMOSTAT 190010074 150℃ CAPACITOR**** 140010043 70µF/370V BALLAST**** 040070059 230V/50-60Hz, 575W BALLAST 040070079 1200W 90~264V AC IGNITOR**** 040090045 575~1200W 6~8KV IGNITOR 040090043 575~1200W LAMP 100050064 MSR 1200 SA/2 DE TILT DRIVE BELT 290151241...
  • Page 25 25/26...
  • Page 26 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 321010233 Last Revision: 20080826 26/26...
